SPI Protocol Definition
Table 5-3 describes all the application specific commands supported or reserved by the SD Card. All the following
commands should be preceded with APP_CMD (CMD55).
Table 5-3. Application Specific Commands Used or Reserved by the SD Card–SPI Mode
CMD SPI Mode
INDEX
ACMD6 No
ACMD13 Yes [31:0] stuff bits
ACMD17
ACMD18 Yes
ACMD19
to
ACMD21
ACMD22 Yes [31:0] stuff bits
ACMD23 Yes [31:23] stuff bits
[22:0]Number of blocks
ACMD24
ACMD25 Yes
ACMD26 Yes
ACMD38 Yes
ACMD39
to
ACMD40
ACMD41 Yes
ACMD42 Yes [31:1] stuff bits
ACMD43 Yes
...
ACMD49
ACMD51 Yes [31:0] staff bits
NOTES: (1) Refer to "SD Card Security Specification" for detailed explanation about the SD Security Features
(2) Command STOP_TRAN (CMD12) shall be used to stop the transmission in Write Multiple Block whether the pre-
erase (ACMD23) feature is used or not.

5.2.3. Responses

There are several types of response tokens. As in the SD Card mode, all are transmitted MSB first.
5-12
Argument Resp
R2
-- --
R1 SEND_NUM_WR_ BLOCKS
R1
-- --
-- --
-- --
None R1
R1
[0]set_cd
-- --
R1
SanDisk Secure Digital (SD) Card Product Manual, Rev. 1.9 © 2003 SANDISK CORPORATION
Abbreviation
SD_STATUS Send the SD Card status. The status fields are
given in Table 4-21
Reserved
-- Reserved for SD security applications1
Reserved
Send the numbers of the well-written (without
errors) blocks. Responds with 32bit+CRC data
block.
SET_WR_BLK_ Set the number of write blocks to be pre-erased
ERASE_COUNT before writing (to be used for faster Multiple Block
WR command). "1"=default (one wr block)(2).
Reserved
-- Reserved for SD security applications1
-- Reserved for SD security applications1
-- Reserved for SD security applications1
Reserved
SEND_OP_ Activates the card's initialization process.
COND
SET_CLR_CARD_ Connect[1]/Disconnect[0] the 50KOhm pull-up
DETECT resistor on CD/DAT3 (pin 1) of the card. The pull-up
may be used for card detection.
-- Reserved for SD security applications.
SEND_SCR Reads the SD Configuration Register (SCR).
Command Description
1
