Bit Position 47
Width (bits) 1
Value '0'
Description start bit

4.11. Timings

All timing diagrams use the schematics and abbreviations listed in Table 4-16.
The difference between the P-bit and Z-bit is that a P-bit is actively driven to HIGH by the card respectively host
output driver, while Z-bit is driven to (respectively kept) HIGH by the pull-up resistors R
Actively-driven P-bits are less sensitive to noise. All timing values are defined in Table 4-17.

4.11.1. Command and Response

Both host command and card responses are clocked out with the rising edge of the host clock.
Card identification and card operation conditions timing
The timing for CMD2 and ACMD41 is given bellow. The command is followed by a period of two Z bits (allowing
time for direction switching on the bus) and then by P bits pushed up by the responding card. The card response to
the host command starts after N
SanDisk Secure Digital (SD) Card Product Manual, Rev. 1.9 © 2003 SANDISK CORPORATION
Table 4-15. R6 Response
46 [45:40]
1 6
'0' x
transmission bit Command
index
('000011')
Table 4-16. Timing Diagram Symbols
S Start Bit (= 0)
T Transmitter Bit (Host = 1, Card = 0)
P One-cycle Pull-up (= 1)
E End Bit (=1)
Z High Impedance State (-> = 1)
D Data Bits
X Don't Care Data Bits (from Card)
* Repeater
CRC Cyclic Redundancy Check Bits (7 Bits)
Card Active
Host Active
clock cycles.
ID
Secure Digital (SD) Card Protocol Description
[39:8] Argument Field
16 16
x
New published RCA [15:0] card status bits:
[31:16] of the card 23,22,19,12:0
(see Table 4-28)
[7:1] 0
7 1
x x '1'
CRC7 end bit
respectively R
CMD DAT
.
