instruction manual
4" Color Touch Panels
(Firmware version G3)
Touc h Pa n els an d A cc e ss o r ie s

Advertisement

Table of Contents
loading

Related Manuals for AMX AXD-CP4/PB

Summary of Contents for AMX AXD-CP4/PB

  • Page 1 instruction manual 4" Color Touch Panels (Firmware version G3) Touc h Pa n els an d A cc e ss o r ie s...
  • Page 2 RMA number. AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not liable for any claim made by a third party or by an AMX Dealer for a third party.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Product Information ....................1 Specifications ........................1 Cleaning the Touch Overlay....................2 Installation .........................3 Mounting Decor-style Panels .................... 3 Mounting the Decor-style panel into a pre-walled conduit box (CB-CP4) ........ 3 Mounting the Decor-style panel on a flat or solid surface ............5 Mounting the Decor-style panel on plasterboard/drywall ............
  • Page 4 Table of Contents Adjust Sensors Setup Page .................... 20 External PushButtons...................... 23 Setting the pushbutton illumination ..................23 Passive Infrared Sensor....................24 Light Sensor ........................24 Audio Tones ........................24 Programming ......................25 Serial Commands......................25 System Send_Commands ....................27 Programming Numbers ....................

  • Page 5: Product Information

    Using the TPDesign3 Touch Panel Design program, you can create custom pages with buttons, icons, sliders, bargraphs, time displays, logos, and drawings. The AXD-CP4/PB is designed for wall mounting with a Decor-style bezel and uses an optional CB-CP4 conduit/wall box for "pre- wall"...

  • Page 6: Cleaning The Touch Overlay

    Installation Cutout Cutout Template for the AXD/T-CP4 is available as an insert in the product packaging and from AMX as drawing number 62-5921-02. This file provides 1:1 cut- out dimensions for the CP4 conduit/wallbox. For a replacement cutout, please call your AMX sales representative.

  • Page 7: Installation

    Installation Installation Mounting Decor-style Panels The following paragraphs describe mounting the Decor-style touch panels using the different types of available methods and surfaces. The CP4 has an AXlink and DB-9 port on the rear of the unit. Communication can be done through either the AXlink or DB-9 cables. These steps use AXlink for both data and power.
  • Page 8 Installation 3. Thread the incoming AXlink cable through the knockout. 4. Disconnect the AXlink connector from the Central Controller and thread the terminal end of the 4-pin AXlink cable through the circular cable knockouts provided on the wallbox. 5. Attach the data and power wiring to the touch panel. 6.

  • Page 9: Mounting The Decor-Style Panel On A Flat Or Solid Surface

    Installation 14. Carefully snap-on the faceplate (A in FIG. 2 on page 3) to the main touch panel unit. Make sure the plastic buttons are flush against the faceplate and secure. 15. Reconnect the AXlink wiring to the Central Controller. The touch panel beeps when power is applied.
  • Page 10 Installation .250 MAX RADIUS ALLOWED IN THESE 4 CORNERS .125 MAX RADIUS ALLOWED IN CORNERS OF NOTCHES THESE NOTCHES ARE ONLY NEEDED IF UNIT IS INSTALLED USING DRYWALL EXPANSIONS CLIPS (2 PROVIDED) CUTOUT These four holes are only required when mounting to a solid surface.

  • Page 11: Mounting The Decor-Style Panel On Plasterboard/Drywall

    Installation 10. Fasten the main AXD unit to the surface using the surface-screws (#4 wood screws) supplied with the enclosure (FIG. 8). Refer to B in FIG. 5 on page 5 for more information. Surface mount screws (#4 wood) are inserted through the outer holes along the plastic housing Main AXD unit consists of illumination board, CP4, and...
  • Page 12 Do not remove the illumination board from the main unit. Damage to any pins prevents proper operation of the unit. The drywall clip set must be re-ordered from AMX if it is bent accidentally during an installation or removed during a re-installation.

  • Page 13: Wiring The Touch Panel

    4-pin AXlink connector DB-9 data connector AXT-CP4/PB (Rear view) AXD-CP4/PB (Rear view) FIG. 11 Rear views of the AXD and AXT touch panels Preparing captive wires You will need a wire stripper and flat-blade screwdriver to prepare and connect the captive wires.

  • Page 14: Using Axlink For Data And Power

    Installation If you install the touch panel farther away from the Central Controller than recommended in the Wiring Guidelines at 320 mA table, connect an external 12 VDC power supply to the panel, as shown in FIG. 12 and FIG. 13. Using AXlink for data and power Connect the Central Controller’s AXlink connector to the AXlink connector on the touch panel for data and12 VDC power, as shown in FIG.

  • Page 15: Using The (Db-9) Rs-232 Connector For Mouse Control Or Data Communication

    Installation Using the (DB-9) RS-232 connector for mouse control or data communication The dual-function (DB-9) RS-232 connector supports most standard serial mouse control devices and RS-232 communication protocols for PC data transmission. Refer to the TPDesign or TPDesign3 Touch Panel Program instruction manual for data transmission information. The following table lists the (DB-9) RS-232 connector pinouts and FIG.
  • Page 16 Installation 4" Color Touch Panels...

  • Page 17: Designing Touch Panel Pages

    Designing Touch Panel Pages Designing Touch Panel Pages There are two ways to approach creating touch panel pages: TPDesign3 - Refer to the TPDesign3 Touch Panel Program (Version 3. 16) instruction manual for more information. On-board editor This section describes the basics of using the on-board editor to create pages and buttons. For more information, refer to the G3 Firmware Design and Reference instruction manual.

  • Page 18: Activating Edit Mode

    Designing Touch Panel Pages General Button Categories (Cont.) Status buttons Status buttons always have a dark fill with light letters and have no functionality except to display information. Operation bars Operation bars appear in the place of the Editor bar, after selecting a button or page edit operation.
  • Page 19 Designing Touch Panel Pages FIG. 16 Setup page 4. Press to enable Edit mode. The button is highlighted in the Protected Setup EDITOR EDITOR page when enabled, as shown in FIG. 17. FIG. 17 Protected Setup page with the active EDITOR button 5.

  • Page 20: Setting The Device Base

    Designing Touch Panel Pages Setting the Device Base Press the option, in the Protected Setup page (FIG. 17), to assign a base (starting) DEVICE BASE device address to the touch panel. 1. Enter the base address for the touch panel. The base address range is from 1 - 255. Standard device addresses begin at 128.

  • Page 21: Defining On-Screen And External Button Properties

    Designing Touch Panel Pages Defining On-Screen and External Button Properties External pushbuttons are configured with features similar to on-screen buttons. Their functionality can be set just as any other button on the touch panel. Use the option of the menu in the Edit bar to set button borders, page flips, PROPERTIES BUTTON button colors for channel on/off conditions, channel/variable text codes, and string/macro...

  • Page 22: Setting The Variable Text Code

    Designing Touch Panel Pages Setting the variable text code The variable text buttons set the device and button channel codes for the buttons. 1. Press to open the keypad and set the device number. 2. Enter 1, 2, 3, or 4 in the keypad. The source code uses device codes 1 - 4 to identify the touch panel.

  • Page 23: Using Tpdesign3 To Download Bitmaps, Icons, And Fonts

    Designing Touch Panel Pages 4. Go through each option and set as desired: sets the text for the button's Off and On state. TEXT OFF TEXT ON sets the icon for the button's Off and On state. ICON OFF ICON ON sets the bitmap for the button's Off and On state.

  • Page 24: Adding A Bargraph Or Joystick Button

    Designing Touch Panel Pages Adding a bargraph or joystick button Create a new button using the Add operation bar in the menu. BUTTON 1. Press in the Edit bar to open the menu. BUTTON BUTTON 2. Press in the Button menu to open the operation bar.
  • Page 25 Designing Touch Panel Pages FIG. 20 Adjust Sensors page 4. Calibrate the following sensors before the system is used. adjusts the effective sensitivity (physical detection range) of the Passive PIR SENSOR Infrared Sensor. The activation threshold range of the is 1 - 17. An PIR SENSOR adjustment to the PIR activation threshold is also achieved through the use of the IRSL AXlink Send_Command.
  • Page 26 Designing Touch Panel Pages adjustment to the Dim-Room brightness level is also achieved through the use of the BRDM AXlink Send_Command. Refer to page 29 for more information. sets the Light Sensor to automatically switch the touch panel display LIGHT DIM MODE backlight between a Normal-Room (NRM) or Dim-Room (DRM) setting (active when button is pressed).

  • Page 27: External Pushbuttons

    Designing Touch Panel Pages Illumination is dependent only on the LS and corresponding light threshold. It does not matter whether the panel is in Wake/Sleep mode or whether the Light Sensor is set to DRM or NRM. mode sets the pushbuttons to either illuminate (On) or not BUTTON ILLUMINATION (Off).

  • Page 28: Passive Infrared Sensor

    Designing Touch Panel Pages Passive Infrared Sensor The on-board infrared sensor provides motion detection that either "wakes-up" the CP4 (Infrared Wake) or sends an I/O signal to the AXlink program on the Central Controller (Infrared Push/ Release). This sensor is mostly used for the illumination/non-illumination of the LCD, external backlit pushbuttons, and use in the Push/Release control of room lights.

  • Page 29: Programming

    Programming Programming You can program the touch panel, using the commands in this section, to perform a wide variety of operations using Axcess Send_Commands and variable text commands. Use the commands described in this section to program the touch panel. Serial Commands Serial Commands are used in the AxcessX Terminal Emulator mode.
  • Page 30 Programming Serial Commands (Cont.) CHECK CAL Syntax: Enters the calibra- "CHECK CAL" tion test mode. Example: CHECK CAL Begins the calibration check mode on the touch panel. ECHO ON Syntax: Turns On charac- "ECHO ON" ter echo. Example: ECHO ON The character echo is sent back to the computer.

  • Page 31: System Send_Commands

    Programming Serial Commands (Cont.) Syntax: Restores the cur- "VER" rent version. Example: Returns the current version of the main firmware. WORKING? Syntax: Verifies the com- "WORKING?" munication Example: between the touch WORKING? panel and the Ter- minal Emulator. Response: $SC 1,"’CPAGE72-Main Page’" Responding touch panel turns its Main page the color white.
  • Page 32 Programming System Send_Commands (Cont.) AKEYB The keyboard string is set to null during power-up and stored until power-down. Opens the touch Syntax: panel keyboard “’AKEYB-<text string>’" and initializes the Variable: text string entry. text string = 0 - 59 characters Example: SEND_COMMAND TP,"’AKEYB-TOUCH HERE’"...
  • Page 33 Programming System Send_Commands (Cont.) BEEP n s The Beep button in the Protected Setup page must be set from 1 - 5 for the BEEP command. The <n> and <d> are optional such that BEEP by itself enables a standard Gives an output of tone and duration.
  • Page 34 Programming System Send_Commands (Cont.) CONT Syntax: Adjusts contrast of "’CONT-<level>’" display. Variable: level = 1 - 12 (1 = minimum; 12 = maximum) Example: SEND_COMMAND TP,"’CONT-12’" Sets display to highest contrast level. CLOCK Syntax: Sets the time and "’CLOCK <mm-dd-yy> <hh:mm:ss>’" date.
  • Page 35 Programming System Send_Commands (Cont.) IRPU The Push/Release mode set with this command corresponds to the value present on the Adjust Sensors page. The Push/Release is disabled from the Adjust Sensors page by set- Enables/Disables ting the PIR channel number to 0 (zero). the PIR Push/ Release mode.
  • Page 36 Programming System Send_Commands (Cont.) LSDM The Dim-Room mode is also set with the LIGHT DIM MODE button on the Adjust Sensors page. Enables/disables the Dim-Room Syntax: mode. "’LSDM,<n>’" Variables: n = 0, turns OFF the Dim-Room feature (disable). n = 1, turns ON the Dim-Room feature (enable). Examples: SEND_COMMAND TP,"’LSDM,0’"...
  • Page 37 Programming System Send_Commands (Cont.) PPOF Syntax: Closes a specific "’PPOF-<page name>’" popup page. Variable: page name = 1 - 50 ASCII characters Example: SEND_COMMAND TP,"’PPOF-Popup Page 1’" Closes Popup Page 1. PPON Syntax: Opens a specific "’PPON-<page name>’" popup page. Variable: page name = 1 - 50 ASCII characters Example:...
  • Page 38 TPAGEON Syntax: Activates page "’TPAGEON’" tracking. Example: SEND_COMMAND TP,’TPAGEON’ DEFINE_DEVICE TP1 = 128 (*AMX Touch Panel*) TP2 = 129 (*AMX Touch Panel*) DEFINE_VARIABLE TP1_BUFFER[100] (*Buffer for TP1*) TP2_BUFFER[100] (*Buffer for TP2*) TRASH[50] (*For Parsing Above*) DEFINE_START CREATE_BUFFER TP1,TP1_BUFFER CREATE_BUFFER TP2,TP2_BUFFER...

  • Page 39: Programming Numbers

    Programming System Send_Commands (Cont.) WAKE Syntax: Deactivates "’WAKE’" screen-saver Example: mode and resets SEND_COMMAND TP,"’WAKE’" the sleep timer. Deactivates the touch panel screen-saver mode and resets the sleep timer. XMRT Syntax: Sets the new net- "’XMRT <number>’" work communica- Variable: tion retry value for number = 1 - 15 ASCII characters the panel and...

  • Page 40: Shorthand Send Commands

    Shorthand Send Commands The shorthand commands operate control equipment just like standard Send_Commands still used in a wide variety of AMX products. However, shorthand commands are smaller byte-for-byte, and are processed more efficiently. The table below lists the shorthand Send_Commands you can use with the AXD-CP4 touch panels.
  • Page 41 Programming Shorthand Send_Commands @CBF This works only if the specified background color is not the same as the current color. Sets the OFF Syntax: feedback border "’@CBF’,<variable text address>,<color_number>" color to the speci- Variables: fied color. variable text address = 1 - 255 color number = See the Colors and Programming Numbers table on page 35.
  • Page 42 Programming Shorthand Send_Commands (Cont.) @CPP This only works if the specified background color is not the same as the current color. Sets the specified Syntax: page’s back- "’@CPP’,<color_number>,’<pop-up page name>’" ground color to Variables: the specified color. color number = See the Colors and Programming Numbers table on page 35. pop-up page name = 1 –...
  • Page 43 Programming Shorthand Send_Commands (Cont.) @PPF If a page name is empty, the current page is used. If a pop-up page is part of a group, the whole group is deactivated. Deactivates a popup page on a Syntax: touch panel page. "’@PPF-<popup page name>;<page name>’"...
  • Page 44 Programming Shorthand Send_Commands (Cont.) @RDW Syntax: Redraws the cur- "’@RDW’" rent screen. Example: SEND_COMMAND TP,"’@RDW’" Sends a message to the touch panel to redraw the screen. @SSL Syntax: Changes the "’@SSL-<string>’" Sleep string sent Variable: to the Controller string = alphanumeric characters when the touch panel activates Example:...

  • Page 45: Color Send_Commands

    Programming Color Send_Commands Use the color Send_Commands to set the colors for text, buttons, and pages. Color Send_Commands CALL You must use the variable text assignments to change button colors (see the Colors and Programming Numbers table on page 35). Sets the colors for a variable text but- Syntax:...
  • Page 46 Programming Color Send_Commands (Cont.) CFOFF Syntax: Sets the OFF "’CFOFF<variable text address>-<color_number>’" feedback fill color Variables: to the specified variable text address = 1 - 255 color. color number = See the Colors and Programming Numbers table on page 35. Example: SEND_COMMAND TP,"’CFOFF1-72’"...

  • Page 47: Variable Text Send_Commands

    Programming Variable Text Send_Commands Use variable text Send_Commands to set the borders, fonts, and text. Variable Text Send_Commands Syntax: "’!B’,<variable text address>,<ON/OFF>" Sets a specific button to On or Variables: Off. variable text address = 1 - 255 ON = 0 OFF = 1 Example: SEND_COMMAND TP,"’!B’,128,1"...
  • Page 48 Programming Variable Text Send_Commands (Cont.) FONT Syntax: "’FONT<variable text address>-<font size/style>’" Changes the font size (or style) of Variables: the text in a variable text address = The number of the variable text button (1-255). specific button. font size/style = The size or style of the font (1-255). See the Font Styles and Programming Numbers table on page 36 for more information.

  • Page 49: Shorthand Variable Text Commands

    Programming Shorthand Variable Text Commands The table below lists the shorthand variable text commands you can use with the touch panel. The shorthand command data is one-byte, non-ASCII format except for pages, passwords, text, and bitmap names. Shorthand Variable Text Commands @BMF This command allows you to program up to 12 attributes on one command line.
  • Page 50 Programming Shorthand Variable Text Commands (Cont.) @BOR Syntax: Sets the border "’@BOR’,<variable text address>,<border style>" style on a button. Variables: variable text address = 1 - 255 border style = See the Border Styles and Programming Numbers table on page 36. Example: SEND_COMMAND TP,"’@BOR’,65,11"...
  • Page 51 Programming Shorthand Variable Text Commands (Cont.) @JUS Syntax: Sets the text "’@JUS’,<variable text address>,<text alignment>" alignment on a Variables: button. variable text address = 1 - 255 text alignment = 1 - 9 as shown in the following alignment chart: Example: SEND_COMMAND TP,"’@JUS’,9,5"...

  • Page 52: Button String Commands

    Programming Button String Commands The table below lists string commands you can assign to buttons by using the touch panel editor. Select the PROPERTIES option in the Edit bar, press the target button, and enter the string command with the Touch Panel keyboard. The control system receives the string command when you press a button.
  • Page 53 Programming Button String Commands (Cont.) WORKING? Responding touch panels tell the sending touch panel to change its Main page to the color white. Verifies the com- munication Syntax: between touch "WORKING?" panels through Example: the use of the on- panel editor. •...
  • Page 54 Programming 4" Color Touch Panels...

  • Page 55: Upgrading The Firmware

    The NetLinx Studio application can perform firmware upgrades for both Axcess and NetLinx devices using the options in the NetLinx Studio Firmware sub-menu. BEFORE beginning, download the correct TSK files from the AMX.com website. Refer to the NXC-ME260 Instruction manual for detailed setup information.
  • Page 56 10. Right-click on the touch panel and select Properties to confirm the on-board firmware. Download the latest firmware file from AMX.COM > Tech Center > Downloadable FIles > Firmware Files > AXD-CP4, AXT-CP4. Then Download the TSK file to your computer.

  • Page 57: Upgrading The Firmware Through An Ip Address

    Upgrading the Firmware Selected Firmware file Device and system number of panel. Control Device Platform/Address must match the information listed in the Master Comm settings dialog box. FIG. 23 Select New Firmware File for download page 18. Click Download to open the Confirm Communication Settings dialog, where you can review and confirm your Comm Settings and Target Device information before the download begins.
  • Page 58 Upgrading the Firmware Press the Get IP button from the Tools > NetLinx Diagnostics > Networking tab > IP Address section. Note the IP Address and Gateway information. 2. Select Tools > Master Communication Settings from the Main menu. 3. Press the NetLinx radio button from within the Platform section of the Communication Settings dialog box (FIG.
  • Page 59 Upgrading the Firmware Download the latest firmware file from AMX.COM > Tech Center > Downloadable FIles > Firmware Files > AXD-CP4, AXT-CP4. Then Download the TSK file to your computer. 11. Select Tools > Firmware > Download to Axcess Device, from the Main menu, to open the Communication Settings dialog box.

  • Page 60: Upgrading The Firmware Using Softrom

    If you have not already installed the SOFTROM program, do so by logging into the AMX.com site and going to Dealers > Tech Center > Downloadable Files > Firmware Files. Scroll-down the list of products to find the AXT/D-CP4 firmware TSK files.
  • Page 61 Upgrading the Firmware 8. Press F5 to refresh the screen. Verify that the selected device has the correct firmware version. If any devices still appear with an old firmware version, repeat steps as necessary until it appears with the correct version. Firmware can be downloaded to multiple device numbers automatically.
  • Page 62 Upgrading the Firmware 4" Color Touch Panels...

  • Page 63: Replacing The Battery

    Replacing the Battery Replacing the Battery There is one lithium battery on the touch panel card, with a life of approximately 2.5 years. It protects stored commands and pages against a power outage. The battery is not used when DC power is supplied to the touch panel.

  • Page 64: Axd-Cp4 (/Pb) Battery Replacement

    Once these drywall clips are separated from their screws, the drywall clip set must be re-order from AMX before the unit can be mounted to this type of surface again. Refer to FIG. 9 on page 7 for more information.
  • Page 65 Replacing the Battery 4" Color Touch Panels...
  • Page 66 ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
