AMX AXT-CP4 Schematic Diagram

NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
shall be confidential except UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
This drawing may not be copied, ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
RELEASED TO PRODUCTION
A
REL DATE REL APPR REV APPR
9/25/01 RDR
DRAWN
TM
ENGR SERV
PICTORIAL
ENGINEER
AXT-CP4
PROD ENGR
TABLE TOP TOUCHPANEL
MATL SUP
QUALITY SIZE SCALE: DWG. NO.
D FULL 95-5921-10
THIRD ANGLE
PROJECTION
95-5921-10_Pictorial - AXT-CP4
DATE APPROVED
09-25-01
REV.
A
SHEET 1 OF 1
