Sample; Smpload - Yamaha A4000 Owner's Manual

2. SAMPLE

SAMPLE allows samples to be loaded into the sampler's
memory from floppy disk, hard disk, or other media to which
they have been saved. When a sample on a SCSI disk is
selected, the sound of the sample can be directly monitored
from disk by pressing the [AUDITION] button (this function
may not work properly with some SCSI devices).
Press the [DISK] button and then the [F2] button to go to the
SAMPLE display.
1 display page is provided: SmpLoad (Sample Load).
• The capacity of the wave memory may be exceeded when loading
a number of voices. We recommend installing SIMM expansion
memory to avoid this problem.

SmpLoad

[DISK] Button [F2]Button
This function can be used to load a single sample or sample
bank (including all the samples it contains), or all samples/
sample banks within a selected volume.
Cursor q
Cursor
q
Knob 1 Knob 2
Turn
Cursor Disk
action
Press
Tree View —
action
Knob 1
[ Turn] Cursor
Positions the cursor.
[ Press] Tree View
Calls the Tree View display (page 83).
Knob 2
[ Turn] Disk
Selects the floppy disk, hard disk, or other storage media
from which a sample or sample bank is to be loaded.
When a disk is selected, all volumes it contains are listed
below the disk name, and all samples and sample banks
contained in the selected volume are listed on the right
side of the display. When a hard disk, CD-ROM drive or
similar storage device is selected, the SCSI ID number or
IDE M/S (Master/Slave) status of the device is shown to
the right of the disk name.
[Range] All installed/connected disks.
• If a connected SCSI or IDE device (hard disk, ZIP
drive, etc.) cannot be selected, go to the disk select
display (DISK-DISK-Disk) and check the mount/
unmount status and SCSI ID settings of the device
(page 173).
to select "DISK-SmpLoad"
Knob 3 Knob 4 Knob 5
—

Sample

—
DELETE LOAD LOAD ALL
Knob 3
[ Press] DELETE
Deletes the selected sample from the disk. A confirma-
tion display will appear when the knob is pressed. Press
Knob 5 (>YES) to actually execute the delete operation.
Knob 4
[ Turn] Sample
Selects the sample or sample bank to be loaded.
Samples cannot be selected if a non-native disk or a
multi-segment floppy disk is selected.
[Range] All samples and sample banks in the selected
volume.
[ Press] LOAD
Initiates loading of the selected sample or sample bank.
A confirmation display will appear when the knob is
pressed. Press Knob 5 (>YES) to actually execute the
load operation.
If a sample with the same name as one being loaded
exists in memory a display allowing you to choose how to
handle the situation will appear (see page 170).
• When a sample bank is loaded all samples con-
tained in that sample bank are loaded.
Knob 5
[ Press] LOAD ALL
All samples and sample banks in the currently selected
volume will be loaded. When the knob is pressed a confir-
mation display will appear. Press Knob 5 (>YES) to actu-
ally execute the load operation.
If a sample with the same name as one being loaded
exists in memory a display allowing you to choose how to
handle the situation will appear (see page 170).
Cursor w
Cursor
w
Knob 1 Knob 2
Turn
Cursor Volume
action
Press
Tree View —
action
Knob 1
Same function as Cursor
Knob 2
[ Turn] Volume
Selects the volume containing the sample to be loaded.
[Range] All volumes on the selected disk.
• When a volume is selected the program list is
updated to show all the programs in the selected vol-
ume.
A5000/A4000 •
DISK-SAMPLE
Knob 3 Knob 4 Knob 5
— Sample —
DELETE LOAD LOAD ALL
q
(page 169).
169
Chapter 7 DISK Mode
