Access Control List Commands - SMC Networks 8748L2 Management Manual

C L
OMMAND INE
Authenticator State Machine
State
Reauth Count
Backend State Machine
State
Request Count
Identifier(Server)
Reauthentication State Machine
State
Console#

Access Control List Commands

Access Control Lists (ACL) provide packet filtering for IP frames (based
on address, protocol, Layer 4 protocol port number or TCP control code)
or any frames (based on MAC address or Ethernet type). To filter packets,
first create an access list, add the required rules, specify a mask to modify
the precedence in which the rules are checked, and then bind the list to a
specific port.
Access Control Lists
An ACL is a sequential list of permit or deny conditions that apply to IP
addresses, MAC addresses, or other more specific criteria. This switch tests
ingress or egress packets against the conditions in an ACL one by one. A
packet will be accepted as soon as it matches a permit rule, or dropped as
soon as it matches a deny rule. If no rules match for a list of all permit
rules, the packet is dropped; and if no rules match for a list of all deny
rules, the packet is accepted.
There are three filtering modes:
• Standard IP ACL mode (STD-ACL) filters packets based on the source
IP address.
• Extended IP ACL mode (EXT-ACL) filters packets based on source
or destination IP address, as well as protocol type and protocol port
4-112
I
NTERFACE
Authenticated
0
Idle
0
2
Initialize
