Table 3-6. LACP Port Counter Information (Continued)
Field
Marker Received
LACPDUs Unknown
Pkts
LACPDUs Illegal Pkts Number of frames that carry the Slow Protocols Ethernet
Web – Click Port, LACP, Port Counters Information. Select a member
port to display the corresponding information.

Figure 3-43. Displaying LACP Port Counters Information

Description
Number of valid Marker PDUs received by this channel
group.
Number of frames received that either (1) Carry the Slow
Protocols Ethernet Type value, but contain an unknown
PDU, or (2) are addressed to the Slow Protocols group
MAC Address, but do not carry the Slow Protocols
Ethernet Type.
Type value, but contain a badly formed PDU or an illegal
value of Protocol Subtype.
P C
ORT ONFIGURATION
3-91
