KEY
1) Rear shock absorber
2) Passenger right footrest
(snaps closed/open)
3) Tail light
4) Glove/tool kit compartment
5) Passenger seat (glove/tool
kit compartment cover)
4 5 6 7
3
2
1
6) Passenger grab strap
7) Engine Control Unit
8) Right side panel
9) Fuel tank
10) Coolant expansion tank cap
11) Fuel tank filler cap
12) Air cleaner
8 9 10 11 12
23 22 21 20
13) Right rear-view mirror
14) Front brake fluid reservoir
15) Secondary fuse carrier (15 A)
16) Right side fairing
17) Horn
18) Lower fairing
19) Expansion tank
13
19 18
20) Rear brake fluid reservoir
21) Rear brake master cylinder
22) Rear brake lever
23) Rider right footrest
