Installing or Replacing Parts and Accessories

removing and replacing the front bezel

You must remove the front bezel from the chassis to upgrade, remove or replace an optical drive.
removing the front bezel
1. To remove the front bezel:
❏
Tower system: Firmly grasp the finger grip at the top of the bezel and pull forward until
the bezel snaps open.
❏
Rack-mounted system: Remove the metal cover, then depress the blue release tabs inside
the chassis and rotate the bezel away from the chassis.
Removing the Front Bezel
2. Lift the bezel off of the chassis.
replacing the front bezel
1. Insert the bezel latches into the matching slots on the system chassis.
Replacing the Front Bezel
2. Close the bezel and push toward the front of the system until it snaps into place.
3. Rack-mounted system only: Replace the metal cover.
2–10 technical reference guide
