General Setup

[General] is selected on the setup main screen in step 3. See "Setup
Operation" (page 28).
General Setup Menu screen
<Setting item>
Sound
1
Balance / Fader *
2
Rear Speaker*
2
Subwoofer*
1, 2, 3, 5
Subwoofer Level*
2, 3
Subwoofer Phase*
1, 4, 5
MX HD*
4, 5
EQ Presets*
4, 5
Dual HD EQ*
5
X-Over*
Time Correction (TCR)
Defeat
Source Volume Setup
6
Caller Level*
6
Microphone Level*
6
Ring Tone Level*
Key Sound Feedback
Mute While Backing Up
Microphone EC/NR
Default Sound Settings
Language (Language)
Picture Quality
7
Video*
8
Camera*
Navigation
Display/Key
Screen/Lighting
Screen Color (X308U/INE-W987HD only)
Illumination Color (X308U/INE-W987HD only)
Screen Color (Off-Road on/off ) (X409 only)
Text Scroll
Artwork Position
General
Format
About
Demo Mode
9
Off-Road SWRC Settings* (X409 only)
Vehicle
Steering wheel
Installation Status
9
Inclinometer* (X409 only)
*1 You can make this setting in the Sound Setup screen of the Shortcut
Setup. For details, see "Sound Setup Function" (page 19).
*2 You can also make the setting in the Bal./Fad. screen.
For details on how to adjust, see "Setting the Balance/Fader/Rear
Speaker/Subwoofer" (page 32).
*3 This setting is only available when "Subwoofer" is set to "On" (
*4 When the Defeat setting is "On, " you cannot perform the set up.
*5 When "BASS ENGINE SQ" is selected in the Shortcut Setup, this
setting is disabled.
*6 Not displayed when Apple CarPlay is used/Android smartphone which
installed Android Auto App is connected.
*7 "Video" can be selected while a video is playing.
*8 The camera names are not displayed when Camera Select (page 45) is
set to "Off. "
*9 Not displayed when Off-Road Mode is set to Off.
The following steps 1 to 3 are common to each "Setting
item" of General Setup. See each section for details.
1
Select the desired item.
2
To switch the setting, touch [ ], [ ], [ ], [ ], or mark the
checkboxes "Off" ( ) or "On" (
• If " " appears, there is a further hierarchy. Touch the desired
item.
3
Touch [ ] to return to the main source screen.
• To return to the previous List screen, touch [ ] in the previous
page. For details, see "About Basic Operation for List Screen"
(page 18).

Sound Setup

[Sound] is selected on the General Setup Menu screen in step 1. See
"General Setup" (page 31).
You can set up items related to the sound quality.
• X409 is designed exclusively for a certain car model. The Initial setting
for sound setup items may differ from the description of Owner's
Manual.
).
).
