Touch Screen Operation

You can operate the system by using the touch panel on the screen.
• Be sure to touch the onscreen button lightly with the pad of your finger
to avoid scratching the display.
Touch operation
Touch a button or list item on the screen lightly.
• If you touch a button and there is no reaction, remove your finger.
• Onscreen buttons that cannot be operated are dimmed.
Swipe operation
Move your finger lightly with a swipe.
Drag & Drop operation
Touch and hold the desired item, then drag it to its new location by
moving your finger, then release your finger to place the item.
• It is not possible to narrow the screen with two fingers (pinch in) or
spread the screen (pinch out). (Except Navigation map screen)

Switching Sources

Press the (AUDIO) button to change the source.
Switching sources using the
During audio/visual playback, press the
repeatedly to switch to the desired source.
1
Radio USB/iPod* Factory Media (USB/iPod)*
1, 3 1
DVD* Pandora* Bluetooth Pandora*
2 3, 5
Factory SiriusXM* AUX*
CarPlay Music/Google Play Music*
*1 When no USB flash drive/iPod/HDMI device/Smartphone/Bluetooth
compatible device/SiriusXM Tuner is connected, this option is not
available. When using Apple CarPlay, some option may not available.
*2 Not displayed when your car does not support the source or "Setting the
Source Category" (page 47) is set to "Aftermarket. " This is also not
displayed when the iDataLink module is not connected.
*3 The name set for "HDMI Setup" (page 44), "Setting the Auxiliary
(AUX) Name" (page 43), is displayed.
*4 When Bluetooth Pandora is set to "Off ", this option is not available.
(page 44)
*5 When AUX is set to "Off, " this option is not available. (page 43)
When the iDataLink module (sold separately) is connected, the
Auxiliary (AUX) mode is not available.
*6 Available when Apple CarPlay is used/Android™ smartphone which
installed Android Auto App is connected.
Switching Sources from the Menu screen
1
Press the MENU button.
The menu screen is displayed.
The Audio source selecting area
2
Touch your desired source in the Audio source selecting
area.
• In the menu screen, you can change the Audio source directly or change
the order in which sources change. For details, see "About the Menu
Screen" (page 21).
(AUDIO) button
(AUDIO) button
2
HDMI/
1, 4 1
SiriusXM* or
1
Bluetooth Audio* Apple
6
Radio
17
