7.3.7. Transferring the Project Data
Place Sysmac Studio online and transfer the connection settings and project data to the
Controller.
Regardless of the operating mode of the CPU Unit, devices or machines may
perform unexpected operation when you transfer any of the following data from
Sysmac Studio: a user program, configuration data, setup data or device
variables.
Always confirm safety at the destination node before you transfer the project
data.
1
Turn ON Controller, Switching
hub and Control power supply
for Driver.
*Do not turn ON Main power
supply for Driver.
2
Select Check All Programs
from the Project Menu.
3
The Build Tab Page is
displayed.
Check that "0 Errors" and "0
Warnings" are displayed.
4
Select Rebuild Controller from
the Project Menu.
5
The dialog box on the right is
displayed. Check the contents
and click Yes.
6
Check that "0 Errors" and "0
Warnings" are displayed on the
Build Tab Page.
7．EtherNet/IP Connection Procedure
