Multi-Tech FaxFinder Quick Start

3. Connect FaxFinder to POTS Line

Plug one end of the phone cable into the FaxFinder's POTS jack
and the other end into your standard telephone line jack. The POTS
Line cable is included with your FaxFinder.

4. Connect FaxFinder to Ethernet Network.

Plug one end of your RJ45 ethernet cable into the FaxFinder's
ethernet jack and the other end into your network ethernet hub. This
ethernet cable is not included with your FaxFinder unit.
Caution: Before connecting to the Ethernet Network, make
sure that the network to which you are connecting
the FaxFinder is not a 192.168.2.x subnet.
If it is a 192.168.2.x subnet, connect from the
Admin PC to the FaxFinder using an RJ45
crossover cable until the FaxFinder's IP address
has been configured. Thereafter, connect the
FaxFinder into the network with an ordinary RJ45
cable.

5. Do Power-On Test

Test your FaxFinder by turning it on (an on-off switch is located on
the back panel). When you apply power, the FaxFinder performs a
diagnostic self-test. The Status indicator flashes when the test is
complete and the unit is ready. If this does not happen, check that
the power switch is on, the power supply is solidly connected, and
the AC outlet is live.
Server Installation
9
