Icom IC-9700 Service Manual Addendum page 8

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R8624 7030016580 S.RES RMC1/16S-6R8JTH (6.8)
R8641 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R8642 7030016370 S.RES RMC1/16S-271JTH (270)
R8643 7030016050 S.RES RMC1/16S-102JTH (1 k)
R8644 7030016600 S.RES RMC1/16S-8R2JTH (8.2)
R8661 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R8662 7030016490 S.RES RMC1/16S-391JTH (390)
R8663 7030016050 S.RES RMC1/16S-102JTH (1 k)
R8664 7030016650 S.RES RMC1/16S-5R6JTH (5.6)
R8665 7030015910 S.RES RMC1/16S-101JTH (100)
R8692 7030015970 S.RES RMC1/16S-103JTH (10 k)
R8693 7030015900 S.RES RMC1/16S-470JTH (47)
R8694 7030015900 S.RES RMC1/16S-470JTH (47)
R8695 7030015900 S.RES RMC1/16S-470JTH (47)
R8700 7030012340 S.RES RR0510P-821-D
R8701 7030006461 S.RES ERA3YED 152V (1.5 k)
R8702 7030008061 S.RES ERA3YED 222V (2.2 k)
R8703 7030008250 S.RES RR0510P-562-D (5.6 k)
R8704 7030009190 S.RES RR0510P-332-D (3.3 k)
R8705 7410001240 S.ARR EXB28V220JX
R8706 7030017610 S.RES RMC1/16SK221FTH (220)
R8707 7030017610 S.RES RMC1/16SK221FTH (220)
R8708 7030017610 S.RES RMC1/16SK221FTH (220)
R8709 7030017610 S.RES RMC1/16SK221FTH (220)
R8712 7030017610 S.RES RMC1/16SK221FTH (220)
R8713 7030017610 S.RES RMC1/16SK221FTH (220)
R8716 7030016560 S.RES RMC1/16SJPTH
R8719 7030016560 S.RES RMC1/16SJPTH
R8801 7030016470 S.RES RMC1/16S-390JTH (39)
R8802 7030016270 S.RES RMC1/16S-151JTH (150)
R8803 7030016270 S.RES RMC1/16S-151JTH (150)
R8804 7030015900 S.RES RMC1/16S-470JTH (47)
R8805 7030016370 S.RES RMC1/16S-271JTH (270)
R8806 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R8807 7030016300 S.RES RMC1/16S-332JTH (3.3 k)
R8808 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R8811 7030015970 S.RES RMC1/16S-103JTH (10 k)
R8812 7030015900 S.RES RMC1/16S-470JTH (47)
R8813 7030016050 S.RES RMC1/16S-102JTH (1 k)
R8814 7030015970 S.RES RMC1/16S-103JTH (10 k)
R8821 7030015970 S.RES RMC1/16S-103JTH (10 k)
R9006 7030015910 S.RES RMC1/16S-101JTH (100)
R9007 7030015910 S.RES RMC1/16S-101JTH (100)
R9008 7030015910 S.RES RMC1/16S-101JTH (100)
R9009 7030015910 S.RES RMC1/16S-101JTH (100)
R9010 7030015910 S.RES RMC1/16S-101JTH (100)
R9106 7030015910 S.RES RMC1/16S-101JTH (100)
R9107 7030015910 S.RES RMC1/16S-101JTH (100)
R9108 7030015910 S.RES RMC1/16S-101JTH (100)
R9109 7030015910 S.RES RMC1/16S-101JTH (100)
R9110 7030015910 S.RES RMC1/16S-101JTH (100)
R9116 7030015910 S.RES RMC1/16S-101JTH (100)
R9203 7030016250 S.RES RMC1/16S-220JTH (22)
R9204 7030016250 S.RES RMC1/16S-220JTH (22)
R9205 7030016250 S.RES RMC1/16S-220JTH (22)
R9206 7030016250 S.RES RMC1/16S-220JTH (22)
R9207 7030016250 S.RES RMC1/16S-220JTH (22)
R9210 7030015910 S.RES RMC1/16S-101JTH (100)
R9211 7030015910 S.RES RMC1/16S-101JTH (100)
R9212 7030015910 S.RES RMC1/16S-101JTH (100)
R9213 7030015910 S.RES RMC1/16S-101JTH (100)
R9214 7030015910 S.RES RMC1/16S-101JTH (100)
R9215 7030015910 S.RES RMC1/16S-101JTH (100)
R9301 7030016520 S.RES RMC1/16S-270JTH (27)
R9302 7030016520 S.RES RMC1/16S-270JTH (27)
R9303 7030016520 S.RES RMC1/16S-270JTH (27)
R9304 7030016520 S.RES RMC1/16S-270JTH (27)
R9305 7030016520 S.RES RMC1/16S-270JTH (27)
R9306 7030016520 S.RES RMC1/16S-270JTH (27)
R9307 7030016520 S.RES RMC1/16S-270JTH (27)
R9308 7030016520 S.RES RMC1/16S-270JTH (27)
R9309 7030015910 S.RES RMC1/16S-101JTH (100)
R9310 7030016560 S.RES RMC1/16SJPTH
R9311 7030015910 S.RES RMC1/16S-101JTH (100)
R9312 7030016250 S.RES RMC1/16S-220JTH (22)
R9325 7030016520 S.RES RMC1/16S-270JTH (27)
R9326 7030016520 S.RES RMC1/16S-270JTH (27)
R9327 7030016520 S.RES RMC1/16S-270JTH (27)
R9328 7030016520 S.RES RMC1/16S-270JTH (27)
R9329 7030016520 S.RES RMC1/16S-270JTH (27)
R9330 7030016520 S.RES RMC1/16S-270JTH (27)
R9331 7030016520 S.RES RMC1/16S-270JTH (27)
R9332 7030016520 S.RES RMC1/16S-270JTH (27)
R9333 7030016560 S.RES RMC1/16SJPTH
R9334 7030016560 S.RES RMC1/16SJPTH
R9335 7030016520 S.RES RMC1/16S-270JTH (27)
R9336 7030016250 S.RES RMC1/16S-220JTH (22)
R9337 7030015910 S.RES RMC1/16S-101JTH (100)
R9401 7030015910 S.RES RMC1/16S-101JTH (100)
R9402 7030015910 S.RES RMC1/16S-101JTH (100)
R9403 7030016520 S.RES RMC1/16S-270JTH (27)
R9404 7030016520 S.RES RMC1/16S-270JTH (27)
R9405 7030016520 S.RES RMC1/16S-270JTH (27)
R9406 7030016520 S.RES RMC1/16S-270JTH (27)
R9407 7030016520 S.RES RMC1/16S-270JTH (27)
R9408 7030016520 S.RES RMC1/16S-270JTH (27)
R9409 7030016110 S.RES RMC1/16S-473JTH (47 k)
R9410 7030016110 S.RES RMC1/16S-473JTH (47 k)
R9411 7030016110 S.RES RMC1/16S-473JTH (47 k)
R9412 7030016110 S.RES RMC1/16S-473JTH (47 k)
R9413 7030016110 S.RES RMC1/16S-473JTH (47 k)
R9414 7030016110 S.RES RMC1/16S-473JTH (47 k)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 98.9/37.7 R9415 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 80.2/38.2 R9501 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 81.8/39.1 R9502 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 78.6/39.1 R9601 7410001140 S.ARR EXB28V104JX
T 79.7/40.0 R9602 7410001130 S.ARR EXB28V102JX
T 87.7/62.4 R9603 7410001140 S.ARR EXB28V104JX
T 86.5/63.7 R9604 7410001130 S.ARR EXB28V102JX
T 89.1/63.5 R9605 7410001140 S.ARR EXB28V104JX
T 89.1/65.1 R9606 7410001130 S.ARR EXB28V102JX
T 63.8/70.3
T 88.2/43.0
T 89.6/52.6 C1 4030023010 S.CER 0402B104K160CT
T 87.7/52.6 C2 4030023010 S.CER 0402B104K160CT
T 85.3/52.2 C3 4030023010 S.CER 0402B104K160CT
T 68.2/49.6 C101 4030023010 S.CER 0402B104K160CT
T 73.9/55.3 C102 4030022680 S.CER 0402N150J500CT
T 72.1/56.1 C103 4030022680 S.CER 0402N150J500CT
T 68.7/50.8 C104 4030023010 S.CER 0402B104K160CT
T 67.8/50.8 C105 4030023010 S.CER 0402B104K160CT
T 69.6/61.5 C106 4030023010 S.CER 0402B104K160CT
T 62.0/49.2 C107 4030023010 S.CER 0402B104K160CT
T 62.0/51.2 C108 4030023010 S.CER 0402B104K160CT
T 61.5/54.0 C109 4030023010 S.CER 0402B104K160CT
T 60.6/54.0 C110 4030023010 S.CER 0402B104K160CT
T 60.5/58.7 C111 4030023010 S.CER 0402B104K160CT
T 61.5/58.7 C112 4030023010 S.CER 0402B104K160CT
T 56.9/55.2 C113 4030023010 S.CER 0402B104K160CT
T 56.8/57.5 C114 4030023010 S.CER 0402B104K160CT
T 10.0/111.7 C115 4030023010 S.CER 0402B104K160CT
T 9.1/111.7 C116 4030023010 S.CER 0402B104K160CT
T 8.7/113.0 C117 4030023010 S.CER 0402B104K160CT
T 11.7/110.5 C118 4030023010 S.CER 0402B104K160CT
T 11.7/109.6 C119 4030023010 S.CER 0402B104K160CT
T 12.9/112.2 C120 4030023010 S.CER 0402B104K160CT
T 15.0/111.8 C121 4030023010 S.CER 0402B104K160CT
T 19.0/110.3 C122 4030023010 S.CER 0402B104K160CT
T 23.5/109.0 C123 4030023010 S.CER 0402B104K160CT
T 28.6/110.5 C124 4030023010 S.CER 0402B104K160CT
T 20.8/109.0 C125 4030023010 S.CER 0402B104K160CT
T 23.4/115.2 C126 4030023010 S.CER 0402B104K160CT
T 16.2/114.4 C127 4030023010 S.CER 0402B104K160CT
T 19.3/9.8 C128 4030023010 S.CER 0402B104K160CT
T 18.3/9.8 C129 4030023010 S.CER 0402B104K160CT
T 17.3/9.8 C130 4030023010 S.CER 0402B104K160CT
T 16.3/9.8 C131 4030023010 S.CER 0402B104K160CT
T 15.3/9.8 C132 4030019560 S.CER GRM21BB31C106KE15L
T 124.5/9.8 C133 4030019560 S.CER GRM21BB31C106KE15L
T 123.5/9.8 C134 4030023010 S.CER 0402B104K160CT
T 122.5/9.8 C135 4030023010 S.CER 0402B104K160CT
T 121.5/9.8 C136 4030023010 S.CER 0402B104K160CT
T 120.5/9.8 C137 4030023010 S.CER 0402B104K160CT
T 119.0/16.1 C138 4030023010 S.CER 0402B104K160CT
T 177.9/9.8 C139 4030023010 S.CER 0402B104K160CT
T 177.4/16.1 C140 4030023010 S.CER 0402B104K160CT
T 176.9/9.8 C141 4030023010 S.CER 0402B104K160CT
T 176.4/16.1 C142 4030023010 S.CER 0402B104K160CT
T 175.9/9.8 C143 4030023010 S.CER 0402B104K160CT
T 174.4/16.1 C144 4030023010 S.CER 0402B104K160CT
T 173.9/9.8 C145 4030023010 S.CER 0402B104K160CT
T 173.4/16.1 C146 4030023010 S.CER 0402B104K160CT
T 172.9/9.8 C147 4030023010 S.CER 0402B104K160CT
T 171.9/9.8 C148 4030023010 S.CER 0402B104K160CT
T 170.9/9.8 C149 4030023010 S.CER 0402B104K160CT
T 177.3/35.0 C150 4030019560 S.CER GRM21BB31C106KE15L
T 175.5/35.0 C151 4030019560 S.CER GRM21BB31C106KE15L
T 173.7/35.0 C152 4030023010 S.CER 0402B104K160CT
T 171.9/35.0 C153 4030023010 S.CER 0402B104K160CT
T 170.1/35.0 C154 4030023010 S.CER 0402B104K160CT
T 168.3/35.0 C155 4030023010 S.CER 0402B104K160CT
T 166.5/35.0 C156 4030023010 S.CER 0402B104K160CT
T 164.7/35.0 C157 4030023010 S.CER 0402B104K160CT
T 142.1/9.2 C158 4030023010 S.CER 0402B104K160CT
T 141.1/9.2 C159 4030023090 S.CER 0402B102K500CT
T 139.7/9.2 C160 4030022560 S.CER 0402N5R0B500CT
T 138.8/9.2 C171 4030022950 S.CER 0402B273K100CT
T 178.2/35.0 C172 4030023010 S.CER 0402B104K160CT
T 176.4/35.0 C181 4030023010 S.CER 0402B104K160CT
T 174.6/35.0 C186 4030022560 S.CER 0402N5R0B500CT
T 172.8/35.0 C191 4030023010 S.CER 0402B104K160CT
T 171.0/35.0 C192 4030023010 S.CER 0402B104K160CT
T 169.2/35.0 C201 4030023010 S.CER 0402B104K160CT
T 167.4/35.0 C202 4030023030 S.CER 0402B103K250CT
T 165.6/35.0 C251 4030019120 S.CER GRM188B31E105KA75D
T 163.8/35.0 C301 4030023010 S.CER 0402B104K160CT
T 162.9/35.0 C302 4030023010 S.CER 0402B104K160CT
T 162.0/35.0 C303 4030023010 S.CER 0402B104K160CT
T 138.4/15.6 C304 4030023010 S.CER 0402B104K160CT
T 137.5/15.6 C305 4030023010 S.CER 0402B104K160CT
T 183.6/21.9 C306 4030023010 S.CER 0402B104K160CT
T 184.1/28.2 C307 4030023010 S.CER 0402B104K160CT
T 184.6/21.9 C308 4030023010 S.CER 0402B104K160CT
T 185.1/28.2 C309 4030023010 S.CER 0402B104K160CT
T 186.1/28.2 C310 4030019560 S.CER GRM21BB31C106KE15L
T 187.6/21.9 C311 4030019560 S.CER GRM21BB31C106KE15L
T 188.1/28.2 C312 4030023010 S.CER 0402B104K160CT
T 188.6/21.9 C313 4030023010 S.CER 0402B104K160CT
T 183.6/19.7 C314 4030023010 S.CER 0402B104K160CT
T 184.1/30.4 C315 4030023010 S.CER 0402B104K160CT
T 184.6/19.7 C316 4030023010 S.CER 0402B104K160CT
T 185.1/30.4 C331 4030023010 S.CER 0402B104K160CT
T 187.6/19.7 C411 4030022640 S.CER 0402N101J500CT
T 188.1/30.4 C412 4030022640 S.CER 0402N101J500CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-7a
DESCRIPTION M .
LOCATION
T 188.6/19.7
T 196.8/121.0
T 199.2/121.0
T 196.9/24.5
T 196.9/27.5
T 199.7/24.5
T 199.7/27.5
T 161.7/22.4
T 164.7/22.4
B 166.3/47.9
B 166.3/47.0
B 168.1/45.0
T 172.1/43.5
T 163.6/40.3
T 166.7/41.9
T 171.1/43.5
B 168.0/49.3
B 164.2/63.4
B 163.3/63.4
B 169.2/62.3
B 168.7/63.2
B 158.9/59.3
B 159.8/59.3
B 163.1/58.8
B 166.5/61.5
B 165.6/59.2
B 166.5/59.2
B 166.8/55.0
B 169.9/55.8
B 158.5/53.8
B 158.5/52.9
B 158.5/50.7
B 158.5/49.7
B 158.5/48.5
B 165.2/46.1
B 162.7/50.9
B 163.7/51.3
B 153.3/47.1
B 154.7/46.3
B 154.7/45.4
B 162.9/46.2
B 170.1/44.7
B 170.5/46.5
B 157.9/62.2
T 173.7/43.7
B 151.0/65.0
B 153.6/65.9
B 156.1/59.2
B 157.6/58.6
B 159.4/61.9
B 164.6/61.2
B 166.8/57.1
B 166.8/56.2
B 157.2/55.9
B 158.5/51.8
B 156.0/51.8
B 167.8/52.1
B 166.2/51.6
B 166.2/50.6
B 161.8/50.8
B 163.4/48.2
B 160.5/47.5
B 152.3/62.7
T 121.6/82.6
T 124.6/79.0
T 129.5/79.0
T 133.4/79.0
T 143.9/79.0
T 131.9/93.9
T 127.1/93.9
T 161.7/43.9
T 151.3/50.8
T 179.8/30.2
T 181.9/33.0
T 159.9/75.2
B 141.9/51.7
T 167.4/70.5
T 169.9/70.5
T 181.9/60.1
T 179.1/57.4
T 168.5/80.7
T 88.5/103.6
T 88.5/96.6
T 96.8/92.4
T 100.2/93.2
T 108.0/101.5
T 108.0/108.5
T 97.8/112.7
T 96.9/112.7
T 95.7/112.2
T 88.3/110.6
T 188.1/43.3
T 191.4/41.5
T 196.2/40.6
T 189.5/44.3
T 200.6/49.8
T 188.7/52.8
T 109.6/111.4
T 202.9/46.8
T 202.9/47.7
H/V
