Icom IC-9700 Service Manual Addendum page 105

[PA-A UNIT]
REF PARTS
NO. NO.
C504 4030021000 S.CER GRM31A5C2J100JW01D
C505 4030021200 S.CER GRM31A5C2J120JW01D
C506 4030021210 S.CER GRM31A5C2J150JW01D
C507 4030024640 S.CER GRM31A5C2J2R0CW01D
C508 4030020740 S.CER GRM31A5C2J180JW01D
C509 4030024670 S.CER GRM31A5C2J9R0DW01D
C601 4030023090 S.CER 0402B102K500CT
C602 4030023090 S.CER 0402B102K500CT
C612 4030023090 S.CER 0402B102K500CT
C651 4030023090 S.CER 0402B102K500CT
C652 4030023090 S.CER 0402B102K500CT
C661 4030023090 S.CER 0402B102K500CT
C662 4030023090 S.CER 0402B102K500CT
C691 4030023030 S.CER 0402B103K250CT
C701 4030023090 S.CER 0402B102K500CT
C702 4030023090 S.CER 0402B102K500CT
C703 4030023090 S.CER 0402B102K500CT
C704 4030023090 S.CER 0402B102K500CT
C705 4030023090 S.CER 0402B102K500CT
C706 4030023010 S.CER 0402B104K160CT
C1101 4030022880 S.CER 0402N560J500CT
C1102 4030022670 S.CER 0402N121J500CT
C1103 4030022700 S.CER 0402N180J500CT
C1104 4030023140 S.CER 0402B271K500CT
C1105 4030022810 S.CER 0402N330J500CT
C1121 4030023030 S.CER 0402B103K250CT
C1122 4030023030 S.CER 0402B103K250CT
C1123 4030023030 S.CER 0402B103K250CT
C1124 4030023030 S.CER 0402B103K250CT
C1151 4030022860 S.CER 0402N470J500CT
C1152 4030022580 S.CER 0402N7R0C500CT
C1153 4030022580 S.CER 0402N7R0C500CT
C1154 4030022750 S.CER 0402N221J500CT
C1155 4030022900 S.CER 0402N680J500CT
C1161 4030023030 S.CER 0402B103K250CT
C1162 4030023030 S.CER 0402B103K250CT
C1163 4030023030 S.CER 0402B103K250CT
C1164 4030022490 S.CER GRM155B31C105MA12D
C1165 4030022490 S.CER GRM155B31C105MA12D
C1171 4030022570 S.CER 0402N6R0C500CT
C1172 4030022840 S.CER 0402N390J500CT
C1173 4030022860 S.CER 0402N470J500CT
C1174 4030022770 S.CER 0402N270J500CT
C1175 4030022770 S.CER 0402N270J500CT
C1176 4030022770 S.CER 0402N270J500CT
C1177 4030022860 S.CER 0402N470J500CT
C1178 4030022840 S.CER 0402N390J500CT
C1179 4030022570 S.CER 0402N6R0C500CT
C1191 4030022700 S.CER 0402N180J500CT
C1192 4030022700 S.CER 0402N180J500CT
RL401 6310000170 S.REL EE2-3NUH-L
J1 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M)
J101 6510032350 S.CON 20279-001E-01
J1201 6510032350 S.CON 20279-001E-01
EP1 6910024660 S.BEA MPZ2012S102AT
EP2 6910024660 S.BEA MPZ2012S102AT
EP3 6910024660 S.BEA MPZ2012S102AT
EP4 6910018460 S.BEA MMZ1005Y102C-T
EP5 6910018460 S.BEA MMZ1005Y102C-T
EP11 6910018460 S.BEA MMZ1005Y102C-T
EP12 6910018460 S.BEA MMZ1005Y102C-T
EP13 6910018460 S.BEA MMZ1005Y102C-T
EP14 6910018460 S.BEA MMZ1005Y102C-T
EP101 6910019900 S.BEA MPZ1608S601AT
EP211 6910018460 S.BEA MMZ1005Y102C-T
EP215 6910024660 S.BEA MPZ2012S102AT
EP301 6910020710 E.O OT-047 M3
EP302 6910020710 E.O OT-047 M3
EP311 6910018460 S.BEA MMZ1005Y102C-T
EP701 6910024660 S.BEA MPZ2012S102AT
EP702 6910024660 S.BEA MPZ2012S102AT
EP1161 6910019900 S.BEA MPZ1608S601AT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M .
LOCATION
T 104.8/29.7
T 123.4/39.1
T 121.8/37.5
T 125.6/13.4
T 129.5/19.4
T 142.1/14.3
T 146.5/5.9
T 142.9/4.9
T 138.6/43.8
T 154.7/15.2
T 153.9/19.4
T 143.7/49.3
T 138.3/50.3
T 140.0/47.1
T 121.9/60.5
T 133.3/54.7
T 130.3/56.6
T 136.1/58.4
T 142.8/23.7
T 143.7/23.7
T 99.5/12.0
T
T 96.0/12.0
T
T 92.5/12.0
T 91.9/14.8
T
T
T
T 86.1/12.0
T
T
T 83.1/10.8
T 82.6/12.0
T 82.2/14.5
T 78.6/12.0
T 78.6/18.5
T 74.3/14.0
T 74.8/19.0
T
T
T
T 76.9/10.2
T
T
T
T
T
T
T
T 110.2/17.5
T
T 18.8/31.1
T
T 12.9/27.2
T 12.9/25.4
T 12.9/23.7
T
T
T
T
T
T
T 29.1/32.2
T 35.0/29.7
T 49.5/32.4
T 53.7/38.6
T 121.3/62.1
T 136.1/52.0
T 76.5/18.5
H/V
98.3/11.6
93.7/11.6
91.3/11.6
90.2/5.6
87.9/9.5
84.9/11.6
84.0/11.6
76.3/6.8
75.7/6.1
76.0/11.1
74.0/5.8
71.7/6.7
71.1/7.3
69.5/8.9
70.1/8.3
61.8/7.1
58.4/7.1
5.0/20.0
55.8/7.5
11.5/22.3
11.5/21.3
11.5/15.3
11.5/14.3
11.5/13.3
11.5/12.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
