Icom IC-9700 Service Manual Addendum page 134

• DISPLAY UNIT (B-8828C: BOTTOM VIEW)
4
R44 R43 R42 R41
R34 R33 R32 R31
3
5
GND
MAINDAK
MAINDBK
5V
1
7
DISPLAY
B-8828C
J71
RIT BOARD
R71 C71
J71
J71
C73 R73
C72 R72
R24 R23 R22 R21
R2
R3
MAIN DIAL
J201
R204 R203
R202 R201
C201
6
The actual configuration of the PC board can be seen by viewing the top and bottom BOARD LAYOUT pages together.
