Icom IC-9700 Service Manual Addendum page 26

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[RIT UNIT]
REF PARTS
DESCRIPTION
NO. NO.
J1 6510029480 S.CON 06FH-SM1-TB (LF) (SN)
S1 2250001010 ENC TP90N00AE20-14.5F-3765A
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M .
LOCATION
T 10.0/5.0
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-25a
