Icom IC-9700 Service Manual Addendum page 7

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R2902 7030015910 S.RES RMC1/16S-101JTH (100)
R2903 7030015910 S.RES RMC1/16S-101JTH (100)
R2921 7030015980 S.RES RMC1/16S-333JTH (33 k)
R2922 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R2923 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R2924 7030016330 S.RES RMC1/16S-153JTH (15 k)
R2931 7030015980 S.RES RMC1/16S-333JTH (33 k)
R2932 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R2933 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R2934 7030016330 S.RES RMC1/16S-153JTH (15 k)
R2935 7030016270 S.RES RMC1/16S-151JTH (150)
R2936 7030015970 S.RES RMC1/16S-103JTH (10 k)
R2941 7030015910 S.RES RMC1/16S-101JTH (100)
R2942 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2951 7030015970 S.RES RMC1/16S-103JTH (10 k)
R2961 7030019670 S.RES RMC1/16K392FTP (3.9 k)
R2962 7030019790 S.RES RMC1/16K334FTP (330 k)
R2963 7030019720 S.RES RMC1/16K222FTP (2.2 k)
R2964 7030018540 S.RES RMC1/16K563FTP (56 k)
R2965 7030018540 S.RES RMC1/16K563FTP (56 k)
R2966 7030018540 S.RES RMC1/16K563FTP (56 k)
R2967 7030018540 S.RES RMC1/16K563FTP (56 k)
R2968 7030018540 S.RES RMC1/16K563FTP (56 k)
R2969 7030019680 S.RES RMC1/16K393FTP (39 k)
R2971 7030015910 S.RES RMC1/16S-101JTH (100)
R3002 7030016560 S.RES RMC1/16SJPTH
R3011 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3012 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R3013 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3014 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3015 7030016410 S.RES RMC1/16S-561JTH (560)
R3016 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3017 7030016160 S.RES RMC1/16S-820JTH (82)
R3018 7030016410 S.RES RMC1/16S-561JTH (560)
R3021 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3022 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R3023 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3024 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3025 7030016410 S.RES RMC1/16S-561JTH (560)
R3026 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3027 7030016160 S.RES RMC1/16S-820JTH (82)
R3028 7030016410 S.RES RMC1/16S-561JTH (560)
R3031 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3032 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3033 7030016130 S.RES RMC1/16S-150JTH (15)
R3041 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3042 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R3043 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3044 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3045 7030016410 S.RES RMC1/16S-561JTH (560)
R3046 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3047 7030016160 S.RES RMC1/16S-820JTH (82)
R3048 7030016410 S.RES RMC1/16S-561JTH (560)
R3052 7030016560 S.RES RMC1/16SJPTH
R3061 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3062 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3063 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3064 7030016400 S.RES RMC1/16S-564JTH (560 k)
R3071 7030016370 S.RES RMC1/16S-271JTH (270)
R3072 7030016570 S.RES RMC1/16S-180JTH (18)
R3073 7030016370 S.RES RMC1/16S-271JTH (270)
R3101 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3102 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3111 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3112 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3121 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3122 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3131 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3132 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3133 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R3134 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3135 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3141 7030016410 S.RES RMC1/16S-561JTH (560)
R3142 7030016560 S.RES RMC1/16SJPTH
R3143 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3144 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3145 7030016410 S.RES RMC1/16S-561JTH (560)
R3146 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3147 7030016270 S.RES RMC1/16S-151JTH (150)
R3148 7030016410 S.RES RMC1/16S-561JTH (560)
R3149 7030016560 S.RES RMC1/16SJPTH
R3151 7030016270 S.RES RMC1/16S-151JTH (150)
R3152 7030016020 S.RES RMC1/16S-104JTH (100 k)
R3153 7030015970 S.RES RMC1/16S-103JTH (10 k)
R3161 7030015920 S.RES RMC1/16S-221JTH (220)
R3162 7030016020 S.RES RMC1/16S-104JTH (100 k)
R3163 7030016020 S.RES RMC1/16S-104JTH (100 k)
R3181 7030016560 S.RES RMC1/16SJPTH
R3182 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3183 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3184 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3185 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3186 7030016110 S.RES RMC1/16S-473JTH (47 k)
R3341 7030016410 S.RES RMC1/16S-561JTH (560)
R3342 7030016560 S.RES RMC1/16SJPTH
R3343 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3344 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R3345 7030016410 S.RES RMC1/16S-561JTH (560)
R3346 7030016050 S.RES RMC1/16S-102JTH (1 k)
R3347 7030016270 S.RES RMC1/16S-151JTH (150)
R3348 7030016410 S.RES RMC1/16S-561JTH (560)
R3349 7030016560 S.RES RMC1/16SJPTH
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 143.0/157.3 R3351 7030016270 S.RES RMC1/16S-151JTH (150)
T 142.0/151.9 R3352 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 122.0/142.3 R3353 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 120.9/142.3 R3361 7030015920 S.RES RMC1/16S-221JTH (220)
T 126.4/143.2 R3362 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 122.9/142.3 R3363 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 133.8/141.5 R3381 7030016560 S.RES RMC1/16SJPTH
T 133.8/142.4 R3382 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 132.2/138.5 R3383 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 133.8/140.6 R3384 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 136.8/139.4 R3385 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 138.1/138.9 R3386 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 134.0/144.2 R3501 7030010570 S.RES ERJ1TYJ 4R7U (4.7)
T 133.1/144.2 R3511 7030010570 S.RES ERJ1TYJ 4R7U (4.7)
T 120.0/142.3 R7204 7030009691 S.RES ERA3YED 101V (100)
T 129.8/34.7 R7206 7030009691 S.RES ERA3YED 101V (100)
T 129.8/36.2 R7209 7030009820 S.RES RR0510P-681-D (680)
T 127.8/35.5 R7210 7030005990 S.RES RR0510P-122-D (1.2 k)
T 115.6/35.3 R7211 7030005990 S.RES RR0510P-122-D (1.2 k)
T 117.5/35.6 R7212 7030015910 S.RES RMC1/16S-101JTH (100)
T 129.8/37.5 R7301 7030016470 S.RES RMC1/16S-390JTH (39)
T 127.8/38.2 R7302 7030016520 S.RES RMC1/16S-270JTH (27)
T 115.1/37.2 R7303 7030016520 S.RES RMC1/16S-270JTH (27)
T 116.3/37.2 R7352 7030015900 S.RES RMC1/16S-470JTH (47)
T 113.5/35.9 R7353 7030015900 S.RES RMC1/16S-470JTH (47)
T 65.2/43.4 R7354 7030016150 S.RES RMC1/16S-100JTH (10)
T 59.6/39.3 R7355 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 58.4/38.9 R7356 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 60.8/39.8 R7357 7030015910 S.RES RMC1/16S-101JTH (100)
T 60.8/38.9 R7402 7030015900 S.RES RMC1/16S-470JTH (47)
T 66.8/41.0 R7403 7030015900 S.RES RMC1/16S-470JTH (47)
T 66.8/38.9 R7404 7030016150 S.RES RMC1/16S-100JTH (10)
T 70.1/39.9 R7405 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 66.8/38.0 R7406 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 59.6/33.2 R7407 7030015910 S.RES RMC1/16S-101JTH (100)
T 58.4/32.8 R7451 7030016470 S.RES RMC1/16S-390JTH (39)
T 60.8/33.7 R7452 7030016520 S.RES RMC1/16S-270JTH (27)
T 60.8/32.8 R7453 7030016520 S.RES RMC1/16S-270JTH (27)
T 66.8/34.9 R7501 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 66.8/32.8 R7510 7030015910 S.RES RMC1/16S-101JTH (100)
T 70.1/33.8 R7511 7030015900 S.RES RMC1/16S-470JTH (47)
T 66.8/31.9 R7512 7030015900 S.RES RMC1/16S-470JTH (47)
T 63.2/20.2 R7513 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 63.2/19.3 R7514 7030016510 S.RES RMC1/16S-4R7JTH (4.7)
T 71.3/23.1 R7903 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 59.6/26.7 R7904 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 58.4/27.1 R7931 7410001240 S.ARR EXB28V220JX
T 60.8/27.1 R7932 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 60.8/26.2 R8101 7030016250 S.RES RMC1/16S-220JTH (22)
T 66.8/28.3 R8102 7030016250 S.RES RMC1/16S-220JTH (22)
T 66.8/27.4 R8103 7030016250 S.RES RMC1/16S-220JTH (22)
T 70.1/26.4 R8104 7030016250 S.RES RMC1/16S-220JTH (22)
T 66.8/25.3 R8105 7030016250 S.RES RMC1/16S-220JTH (22)
T 64.2/22.5 R8106 7030016250 S.RES RMC1/16S-220JTH (22)
T 87.1/19.8 R8107 7030016560 S.RES RMC1/16SJPTH
T 87.2/15.7 R8108 7030016250 S.RES RMC1/16S-220JTH (22)
T 82.1/19.8 R8109 7030016250 S.RES RMC1/16S-220JTH (22)
T 85.5/20.0 R8110 7030016560 S.RES RMC1/16SJPTH
T 72.8/12.4 R8111 7030016250 S.RES RMC1/16S-220JTH (22)
T 74.0/12.3 R8112 7030016250 S.RES RMC1/16S-220JTH (22)
T 76.5/12.3 R8113 7030016560 S.RES RMC1/16SJPTH
T 36.4/15.7 R8114 7030016250 S.RES RMC1/16S-220JTH (22)
T 40.7/15.7 R8115 7030016150 S.RES RMC1/16S-100JTH (10)
T 46.4/15.7 R8116 7030016150 S.RES RMC1/16S-100JTH (10)
T 50.7/15.7 R8117 7030015910 S.RES RMC1/16S-101JTH (100)
T 57.1/14.8 R8118 7030016560 S.RES RMC1/16SJPTH
T 57.7/15.8 R8119 7030015910 S.RES RMC1/16S-101JTH (100)
T 52.9/11.0 R8120 7030016250 S.RES RMC1/16S-220JTH (22)
T 53.3/9.6 R8121 7030016250 S.RES RMC1/16S-220JTH (22)
T 54.5/10.1 R8122 7030016150 S.RES RMC1/16S-100JTH (10)
T 52.4/9.6 R8123 7030016150 S.RES RMC1/16S-100JTH (10)
T 51.6/6.5 R8124 7030016150 S.RES RMC1/16S-100JTH (10)
T 13.0/26.2 R8125 7030016250 S.RES RMC1/16S-220JTH (22)
T 15.5/21.2 R8126 7030016150 S.RES RMC1/16S-100JTH (10)
T 12.4/23.0 R8127 7030016250 S.RES RMC1/16S-220JTH (22)
T 12.4/24.6 R8128 7030016150 S.RES RMC1/16S-100JTH (10)
T 16.9/21.7 R8129 7030016150 S.RES RMC1/16S-100JTH (10)
T 17.3/22.7 R8130 7030016150 S.RES RMC1/16S-100JTH (10)
T 18.4/25.2 R8131 7030016150 S.RES RMC1/16S-100JTH (10)
T 17.6/26.4 R8132 7030016150 S.RES RMC1/16S-100JTH (10)
T 16.2/26.1 R8133 7030016150 S.RES RMC1/16S-100JTH (10)
T 17.9/27.8 R8134 7030016150 S.RES RMC1/16S-100JTH (10)
T 55.1/24.6 R8135 7030016150 S.RES RMC1/16S-100JTH (10)
T 56.1/24.6 R8136 7030016150 S.RES RMC1/16S-100JTH (10)
T 21.1/44.2 R8137 7030016150 S.RES RMC1/16S-100JTH (10)
T 19.1/39.1 R8138 7030016250 S.RES RMC1/16S-220JTH (22)
T 19.4/42.6 R8139 7030016560 S.RES RMC1/16SJPTH
T 16.3/45.0 R8140 7030016250 S.RES RMC1/16S-220JTH (22)
T 18.7/46.1 R8141 7030016250 S.RES RMC1/16S-220JTH (22)
T 13.8/46.1 R8142 7030016250 S.RES RMC1/16S-220JTH (22)
T 13.8/60.2 R8143 7030016250 S.RES RMC1/16S-220JTH (22)
T 18.4/59.8 R8144 7030016250 S.RES RMC1/16S-220JTH (22)
T 12.7/44.9 R8301 7030017800 S.RES RMC1/16S-202JTH (2 k)
T 40.0/22.5 R8601 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 44.9/25.2 R8604 7030016360 S.RES RMC1/16S-123JTH (12 k)
T 43.2/21.9 R8606 7030015920 S.RES RMC1/16S-221JTH (220)
T 41.6/21.9 R8607 7030016170 S.RES RMC1/16S-560JTH (56)
T 44.5/26.4 R8608 7030015900 S.RES RMC1/16S-470JTH (47)
T 43.4/26.8 R8609 7030015930 S.RES RMC1/16S-471JTH (470)
T 41.0/27.9 R8621 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
T 39.7/27.1 R8622 7030016280 S.RES RMC1/16S-331JTH (330)
T 40.0/25.7 R8623 7030016050 S.RES RMC1/16S-102JTH (1 k)
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-6a
DESCRIPTION M .
LOCATION
T 38.4/27.4
T 52.8/28.0
T 53.8/28.0
T 36.6/39.3
T 34.6/34.2
T 35.0/37.7
T 32.9/40.9
T 37.7/41.7
T 32.8/42.0
T 32.8/54.1
T 37.7/54.1
T 30.9/42.5
B 22.2/25.2
B 39.6/32.0
T 45.9/45.2
T 45.9/49.0
T 32.9/70.9
T 34.1/72.1
T 33.5/71.5
B 46.6/62.6
T 22.2/61.2
T 21.3/59.4
T 21.3/60.3
T 12.1/79.3
T 13.9/79.3
T 13.5/80.5
T 23.3/102.2
T 23.3/101.3
T 24.5/101.7
T 22.6/79.3
T 24.4/79.3
T 23.1/80.5
T 23.3/98.2
T 23.3/97.3
T 24.5/97.7
T 29.0/54.5
T 30.6/54.5
T 29.0/55.4
T 22.5/103.7
T 29.7/93.1
T 57.5/73.0
T 57.5/75.1
T 29.3/91.9
T 30.2/91.9
T 65.6/108.8
T 74.2/108.0
T 49.5/105.7
T 46.0/105.8
T 73.2/81.5
T 84.5/108.8
T 84.5/106.6
T 83.0/107.2
T 84.5/107.7
T 83.0/98.4
T 72.5/108.4
T 83.0/106.1
T 83.0/108.3
T 83.0/96.2
T 84.5/103.3
T 83.0/102.2
T 84.5/96.7
T 84.5/100.0
T 84.5/87.8
T 83.0/89.5
T 78.6/111.2
T 84.5/93.4
T 79.6/111.2
T 83.0/105.0
T 83.0/99.5
T 84.5/86.7
T 83.0/86.2
T 84.5/88.9
T 83.0/100.6
T 84.5/91.1
T 84.5/98.9
T 83.0/91.7
T 83.0/87.3
T 84.5/92.2
T 84.5/90.0
T 83.0/84.0
T 83.0/90.6
T 83.0/88.4
T 84.5/85.6
T 84.5/84.5
T 83.0/85.1
T 84.5/105.5
T 83.0/92.8
T 88.9/74.2
T 91.6/74.2
T 92.5/74.2
T 90.7/74.2
T 89.8/74.2
T 78.2/108.7
T 110.9/35.6
T 107.6/40.5
T 104.0/40.6
T 104.7/36.7
T 101.9/40.7
T 100.6/41.6
T 100.6/40.4
T 102.0/38.1
T 98.9/39.5
H/V
