Icom IC-9700 Service Manual Addendum page 20

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[PA-C UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R421 7030016110 S.RES RMC1/16S-473JTH (47 k)
R422 7030016130 S.RES RMC1/16S-150JTH (15)
R423 7030016020 S.RES RMC1/16S-104JTH (100 k)
R424 7030015970 S.RES RMC1/16S-103JTH (10 k)
R432 7030016560 S.RES RMC1/16SJPTH
R505 7030015910 S.RES RMC1/16S-101JTH (100)
R506 7030015910 S.RES RMC1/16S-101JTH (100)
R507 7030015910 S.RES RMC1/16S-101JTH (100)
R508 7030015910 S.RES RMC1/16S-101JTH (100)
R509 7030015910 S.RES RMC1/16S-101JTH (100)
R510 7030015910 S.RES RMC1/16S-101JTH (100)
R513 7030016250 S.RES RMC1/16S-220JTH (22)
R514 7030016250 S.RES RMC1/16S-220JTH (22)
R515 7030016250 S.RES RMC1/16S-220JTH (22)
R516 7030016250 S.RES RMC1/16S-220JTH (22)
R517 7030016250 S.RES RMC1/16S-220JTH (22)
C1 4030023090 S.CER 0402B102K500CT
C2 4030023090 S.CER 0402B102K500CT
C3 4030023090 S.CER 0402B102K500CT
C4 4030023090 S.CER 0402B102K500CT
C5 4030023090 S.CER 0402B102K500CT
C8 4030022860 S.CER 0402N470J500CT
C9 4030023090 S.CER 0402B102K500CT
C10 4030023010 S.CER 0402B104K160CT
C11 4030023090 S.CER 0402B102K500CT
C14 4030022860 S.CER 0402N470J500CT
C16 4030022860 S.CER 0402N470J500CT
C17 4030023720 S.CER 0603N470J500CT
C20 4030023090 S.CER 0402B102K500CT
C21 4030023090 S.CER 0402B102K500CT
C22 4030022870 S.CER 0402N471J500CT
C23 4030022630 S.CER 0402N100C500CT
C24 4030022630 S.CER 0402N100C500CT
C25 4030022870 S.CER 0402N471J500CT
C26 4030023090 S.CER 0402B102K500CT
C29 4030022860 S.CER 0402N470J500CT
C30 4030022860 S.CER 0402N470J500CT
C31 4030023090 S.CER 0402B102K500CT
C33 4030022860 S.CER 0402N470J500CT
C34 4030022860 S.CER 0402N470J500CT
C35 4030022860 S.CER 0402N470J500CT
C41 4030023090 S.CER 0402B102K500CT
C42 4030023090 S.CER 0402B102K500CT
C51 4030022870 S.CER 0402N471J500CT
C52 4030023090 S.CER 0402B102K500CT
C53 4030023010 S.CER 0402B104K160CT
C54 4030022860 S.CER 0402N470J500CT
C55 4030019560 S.CER GRM21BB31C106KE15L
C56 4030019120 S.CER GRM188B31E105KA75D
C57 4030023090 S.CER 0402B102K500CT
C58 4030022860 S.CER 0402N470J500CT
C59 4030022860 S.CER 0402N470J500CT
C60 4030022860 S.CER 0402N470J500CT
C61 4030020740 S.CER GRM31A5C2J180JW01D
C62 4030024580 S.CER GRM31A5C2J1R0CW01D
C71 4030022870 S.CER 0402N471J500CT
C72 4030023090 S.CER 0402B102K500CT
C75 4030023010 S.CER 0402B104K160CT
C76 4030023090 S.CER 0402B102K500CT
C77 4030022860 S.CER 0402N470J500CT
C81 4030023850 S.CER 0603B102K500CT
C82 4030023730 S.CER 0603N471J500CT
C83 4510011410 S.ELE 25 CE 470 LX
C84 4030023820 S.CER 0603B104K250CT
C87 4030025270 S.CER 1111C6R8CW501X
C88 4030023090 S.CER 0402B102K500CT
C89 4030024460 S.CER GQM22M5C2H1R5BB01L
C91 4030025220 S.CER GQM22M5C2H6R0CB01L
C92 4030022870 S.CER 0402N471J500CT
C93 4030023010 S.CER 0402B104K160CT
C94 4030021000 S.CER GRM31A5C2J100JW01D
C95 4030021430 S.CER GQM22M5C2H4R0CB01L
C96 4030025520 S.CER GQM22M5C2H1R0BB01L
C97 4030024460 S.CER GQM22M5C2H1R5BB01L
C98 4030022380 S.CER GQM22M5C2H3R0BB01L
C101 4030023090 S.CER 0402B102K500CT
C102 4030022870 S.CER 0402N471J500CT
C103 4030023010 S.CER 0402B104K160CT
C104 4030019560 S.CER GRM21BB31C106KE15L
C106 4030023090 S.CER 0402B102K500CT
C107 4030022870 S.CER 0402N471J500CT
C108 4030023010 S.CER 0402B104K160CT
C109 4030022580 S.CER 0402N7R0C500CT
C110 4030024550 S.CER 0402N3R5B500CT
C113 4030022660 S.CER 0402N120J500CT
C114 4030023290 S.CER 0603N2R0B500CT
C115 4030023310 S.CER 0603N3R0B500CT
C117 4030023330 S.CER 0603N4R0B500CT
C119 4030021000 S.CER GRM31A5C2J100JW01D
C121 4030024580 S.CER GRM31A5C2J1R0CW01D
C123 4030022370 S.CER GQM22M5C2H2R0BB01L
C131 4030023090 S.CER 0402B102K500CT
C132 4030022640 S.CER 0402N101J500CT
C133 4030022640 S.CER 0402N101J500CT
C141 4030023090 S.CER 0402B102K500CT
C142 4030022870 S.CER 0402N471J500CT
C143 4030023010 S.CER 0402B104K160CT
C144 4030022550 S.CER 0402N4R0B500CT
C145 4030022870 S.CER 0402N471J500CT
C146 4030022540 S.CER 0402N3R0B500CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[PA-C UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 20.6/45.9 C161 4030022540 S.CER 0402N3R0B500CT
T 22.2/44.3 C162 4030022520 S.CER 0402N1R0B500CT
T 16.6/44.5 C163 4030022570 S.CER 0402N6R0C500CT
T 16.6/46.1 C164 4030022620 S.CER 0402N0R5B500CT
T 14.7/38.3 C165 4030022570 S.CER 0402N6R0C500CT
T 16.2/11.8 C166 4030022620 S.CER 0402N0R5B500CT
T 16.7/16.1 C167 4030024550 S.CER 0402N3R5B500CT
T 16.7/17.0 C191 4030023090 S.CER 0402B102K500CT
T 16.7/17.9 C192 4030022870 S.CER 0402N471J500CT
T 16.7/18.8 C193 4030022870 S.CER 0402N471J500CT
T 16.7/19.7 C195 4030023090 S.CER 0402B102K500CT
T 16.7/20.6 C196 4030023090 S.CER 0402B102K500CT
T 16.7/21.5 C201 4030022790 S.CER 0402N2R5B500CT
T 16.7/22.4 C202 4030022530 S.CER 0402N2R0B500CT
T 16.7/23.3 C203 4030022720 S.CER 0402N1R5B500CT
T 16.7/24.2 C204 4030022590 S.CER 0402N8R0C500CT
C205 4030022790 S.CER 0402N2R5B500CT
C221 4030022530 S.CER 0402N2R0B500CT
T 152.5/13.7 C222 4030022530 S.CER 0402N2R0B500CT
T 158.0/19.1 C223 4030022550 S.CER 0402N4R0B500CT
T 154.0/19.1 C224 4030022720 S.CER 0402N1R5B500CT
T 149.6/15.3 C225 4030024550 S.CER 0402N3R5B500CT
T 155.8/30.9 C226 4030022620 S.CER 0402N0R5B500CT
T 145.4/41.8 C227 4030024550 S.CER 0402N3R5B500CT
T 145.4/42.7 C231 4030023090 S.CER 0402B102K500CT
T 145.4/43.6 C232 4030022870 S.CER 0402N471J500CT
T 157.3/31.6 C233 4030019560 S.CER GRM21BB31C106KE15L
T 154.0/9.3 C234 4030022870 S.CER 0402N471J500CT
T 150.7/9.1 C235 4030022530 S.CER 0402N2R0B500CT
T 120.4/12.4 C236 4030022530 S.CER 0402N2R0B500CT
T 153.6/35.6 C237 4030022530 S.CER 0402N2R0B500CT
T 147.3/44.9 C238 4030022530 S.CER 0402N2R0B500CT
T 149.7/44.9 C241 4030022550 S.CER 0402N4R0B500CT
T 149.7/45.8 C242 4030022630 S.CER 0402N100C500CT
T 161.6/45.8 C243 4030022560 S.CER 0402N5R0B500CT
T 161.6/44.9 C244 4030022560 S.CER 0402N5R0B500CT
T 163.2/44.9 C245 4030022790 S.CER 0402N2R5B500CT
T 151.2/42.7 C251 4030022680 S.CER 0402N150J500CT
T 159.2/42.7 C252 4030022700 S.CER 0402N180J500CT
T 150.5/34.7 C253 4030022580 S.CER 0402N7R0C500CT
T 141.8/5.3 C254 4030022680 S.CER 0402N150J500CT
T 142.4/4.4 C255 4030022900 S.CER 0402N680J500CT
T 142.9/3.5 C261 4030022520 S.CER 0402N1R0B500CT
T 157.1/34.0 C263 4030022520 S.CER 0402N1R0B500CT
T 156.6/38.6 C264 4030022530 S.CER 0402N2R0B500CT
T 118.2/45.3 C266 4030022570 S.CER 0402N6R0C500CT
T 119.1/45.3 C268 4030022570 S.CER 0402N6R0C500CT
T 119.1/43.7 C269 4030022630 S.CER 0402N100C500CT
T 108.8/41.2 C271 4030022870 S.CER 0402N471J500CT
T 115.7/41.2 C272 4030022870 S.CER 0402N471J500CT
T 109.9/40.9 C273 4030019120 S.CER GRM188B31E105KA75D
T 114.2/47.6 C274 4030022870 S.CER 0402N471J500CT
T 115.9/47.6 C275 4030022870 S.CER 0402N471J500CT
T 65.9/38.6 C276 4030022870 S.CER 0402N471J500CT
T 65.9/37.7 C277 4030022870 S.CER 0402N471J500CT
T 139.3/49.9 C278 4030023010 S.CER 0402B104K160CT
T 139.3/46.1 C279 4030022870 S.CER 0402N471J500CT
T 93.4/13.5 C280 4030021580 S.CER GRM188B31E225KA12D
T 93.4/14.4 C281 4030023170 S.CER 0402B332K500CT
T 104.2/4.3 C282 4030021580 S.CER GRM188B31E225KA12D
T 105.1/4.3 C283 4030022060 S.CER GRM188B30J106ME47D
T 119.2/2.7 C284 4030021400 S.CER GRM188B30J226MEA0D
T 122.4/12.4 C285 4030022060 S.CER GRM188B30J106ME47D
T 118.4/11.6 C286 4030021400 S.CER GRM188B30J226MEA0D
T 133.8/10.9 C287 4030022870 S.CER 0402N471J500CT
T 124.4/12.4 C288 4030023010 S.CER 0402B104K160CT
T 106.5/18.8 C289 4030022870 S.CER 0402N471J500CT
T 90.7/17.3 C291 4030022530 S.CER 0402N2R0B500CT
T 90.9/30.1 C292 4030022530 S.CER 0402N2R0B500CT
T 94.3/30.1 C293 4030022870 S.CER 0402N471J500CT
T 91.6/17.3 C296 4030022530 S.CER 0402N2R0B500CT
T 89.8/17.3 C297 4030022530 S.CER 0402N2R0B500CT
T 109.1/15.1 C298 4030022870 S.CER 0402N471J500CT
T 135.5/24.6 C301 4030023010 S.CER 0402B104K160CT
T 139.4/22.3 C302 4030021580 S.CER GRM188B31E225KA12D
T 141.8/35.9 C303 4030023010 S.CER 0402B104K160CT
T 138.5/41.5 C304 4030022060 S.CER GRM188B30J106ME47D
T 78.3/27.0 C305 4030023010 S.CER 0402B104K160CT
T 77.4/27.0 C306 4030022640 S.CER 0402N101J500CT
T 79.2/27.0 C307 4030022060 S.CER GRM188B30J106ME47D
T 79.4/25.1 C308 4030023010 S.CER 0402B104K160CT
T 76.7/20.8 C309 4030022640 S.CER 0402N101J500CT
T 75.8/20.9 C311 4030022540 S.CER 0402N3R0B500CT
T 77.6/20.9 C312 4030022720 S.CER 0402N1R5B500CT
T 75.8/15.3 C313 4030022720 S.CER 0402N1R5B500CT
T 74.6/15.9 C314 4030022540 S.CER 0402N3R0B500CT
T 71.9/20.4 C320 4030022630 S.CER 0402N100C500CT
T 71.8/29.8 C321 4030022640 S.CER 0402N101J500CT
T 71.8/27.5 C322 4030022870 S.CER 0402N471J500CT
T 71.8/32.4 C323 4030022870 S.CER 0402N471J500CT
T 77.1/33.6 C324 4030023030 S.CER 0402B103K250CT
T 80.6/35.9 C325 4030022640 S.CER 0402N101J500CT
T 87.5/33.2 C326 4030022870 S.CER 0402N471J500CT
T 84.5/16.9 C327 4030022870 S.CER 0402N471J500CT
T 88.1/12.0 C328 4030023090 S.CER 0402B102K500CT
T 81.1/12.6 C329 4030022630 S.CER 0402N100C500CT
T 77.0/9.1 C330 4030022630 S.CER 0402N100C500CT
T 75.3/9.1 C331 4030022870 S.CER 0402N471J500CT
T 77.0/8.2 C332 4030022630 S.CER 0402N100C500CT
T 75.0/11.6 C333 4030022630 S.CER 0402N100C500CT
T 69.2/8.9 C334 4030022630 S.CER 0402N100C500CT
T 75.0/13.2 C335 4030022630 S.CER 0402N100C500CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-19a
DESCRIPTION M .
LOCATION
T 66.3/13.6
T 64.7/13.2
T 65.1/14.4
T 64.2/14.4
T 64.2/16.2
T 62.8/16.8
T 61.6/17.3
T 58.7/15.0
T 58.7/14.1
T 60.3/15.8
T 63.9/8.4
T 66.5/5.0
T 57.1/18.6
T 56.1/17.9
T 55.7/19.1
T 54.7/17.3
T 54.7/18.2
T 47.3/11.9
T 46.1/12.3
T 46.1/11.4
T 43.7/11.9
T 43.7/10.3
T 42.5/11.9
T 40.8/9.7
T 35.0/9.2
T 34.2/10.2
T 34.2/12.3
T 41.3/12.3
T 40.0/7.2
T 35.8/13.9
T 39.6/13.4
T 41.3/14.0
T 37.0/7.0
T 30.0/10.8
T 31.0/8.9
T 28.0/8.2
T 28.5/9.4
T 26.5/10.0
T 25.6/9.1
T 25.1/10.4
T 24.2/9.5
T 24.7/8.3
T 51.8/25.6
T 53.1/24.2
T 50.2/26.5
T 49.8/30.9
T 50.2/32.1
T 51.4/34.8
T 40.4/25.0
T 42.8/26.4
T 42.5/24.7
T 44.6/27.4
T 47.8/32.8
T 48.6/28.4
T 45.0/34.7
T 45.0/35.6
T 43.8/35.1
T 42.5/34.7
T 41.3/34.5
T 39.9/34.7
T 38.7/34.7
T 37.5/34.7
T 35.7/33.6
T 35.7/34.9
T 36.6/30.6
T 36.6/29.7
T 36.1/28.5
T 48.6/26.5
T 50.2/25.6
T 47.0/29.3
T 47.0/30.4
T 48.6/30.4
T 46.1/33.7
T 21.0/26.6
T 23.6/23.5
T 21.0/25.0
T 31.2/26.8
T 30.0/26.7
T 29.1/26.7
T 46.5/24.7
T 48.5/24.2
T 47.6/24.2
T 118.4/54.0
T 115.7/51.7
T 113.9/51.2
T 110.4/50.8
T 76.7/56.5
T 97.7/50.8
T 92.0/50.8
T 99.5/52.8
T 99.5/53.7
T 103.1/50.8
T 105.5/50.8
T 109.3/53.6
T 104.5/57.3
T 96.4/60.0
T 103.2/59.5
T 84.7/52.9
T 90.1/52.9
T 90.1/48.6
T 81.4/52.9
T 81.4/48.7
H/V
