[SD UNIT]
REF
PARTS
DESCRIPTION
NO.
NO.
R1
7030015050 S.RES RMC1/16-221JTP (220)
R2
7030014940 S.RES RMC1/16-270JTP (27)
R3
7030014940 S.RES RMC1/16-270JTP (27)
R4
7030014940 S.RES RMC1/16-270JTP (27)
R5
7030014940 S.RES RMC1/16-270JTP (27)
R6
7030014940 S.RES RMC1/16-270JTP (27)
R8
7030014940 S.RES RMC1/16-270JTP (27)
R9
7030015050 S.RES RMC1/16-221JTP (220)
C1
4030023820 S.CER 0603B104K250CT
C2
4030019560 S.CER GRM21BB31C106KE15L
J1
6510032800 S.CON CIM-J44N (R41-A455A)
J2
6510031540 S.CON 12FHJ-SM1-TB (LF) (SN)
EP7
6910019900 S.BEA MPZ1608S601AT1
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M
.
LOCATION
T
3.3/7.8
T
35.1/13.9
T
35.1/15.1
T
35.1/18.7
T
35.1/19.9
T
35.1/17.5
T
35.1/12.7
T
35.1/10.3
T
32.6/16.0
T
31.1/15.6
T
19.8/9.3
T
4.0/11.2
T
35.1/16.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
