Icom IC-9700 Service Manual Addendum page 4

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R22 7030016110 S.RES RMC1/16S-473JTH (47 k)
R23 7030016110 S.RES RMC1/16S-473JTH (47 k)
R24 7030015970 S.RES RMC1/16S-103JTH (10 k)
R25 7030016090 S.RES RMC1/16S-223JTH (22 k)
R26 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R27 7030016020 S.RES RMC1/16S-104JTH (100 k)
R30 7030016020 S.RES RMC1/16S-104JTH (100 k)
R31 7030016020 S.RES RMC1/16S-104JTH (100 k)
R32 7030016020 S.RES RMC1/16S-104JTH (100 k)
R33 7030016020 S.RES RMC1/16S-104JTH (100 k)
R34 7030016020 S.RES RMC1/16S-104JTH (100 k)
R35 7030016020 S.RES RMC1/16S-104JTH (100 k)
R36 7030016090 S.RES RMC1/16S-223JTH (22 k)
R37 7030016090 S.RES RMC1/16S-223JTH (22 k)
R38 7030016090 S.RES RMC1/16S-223JTH (22 k)
R39 7030016020 S.RES RMC1/16S-104JTH (100 k)
R40 7030016020 S.RES RMC1/16S-104JTH (100 k)
R41 7030016020 S.RES RMC1/16S-104JTH (100 k)
R101 7030015970 S.RES RMC1/16S-103JTH (10 k)
R102 7030015970 S.RES RMC1/16S-103JTH (10 k)
R103 7030015970 S.RES RMC1/16S-103JTH (10 k)
R104 7030015970 S.RES RMC1/16S-103JTH (10 k)
R105 7030016110 S.RES RMC1/16S-473JTH (47 k)
R106 7030016110 S.RES RMC1/16S-473JTH (47 k)
R107 7030015970 S.RES RMC1/16S-103JTH (10 k)
R108 7030016250 S.RES RMC1/16S-220JTH (22)
R109 7030016150 S.RES RMC1/16S-100JTH (10)
R110 7030016150 S.RES RMC1/16S-100JTH (10)
R111 7030016150 S.RES RMC1/16S-100JTH (10)
R112 7030016150 S.RES RMC1/16S-100JTH (10)
R113 7030016150 S.RES RMC1/16S-100JTH (10)
R114 7030016150 S.RES RMC1/16S-100JTH (10)
R115 7030016150 S.RES RMC1/16S-100JTH (10)
R116 7030016150 S.RES RMC1/16S-100JTH (10)
R117 7030016150 S.RES RMC1/16S-100JTH (10)
R118 7030016150 S.RES RMC1/16S-100JTH (10)
R119 7030016150 S.RES RMC1/16S-100JTH (10)
R120 7030016150 S.RES RMC1/16S-100JTH (10)
R121 7030016150 S.RES RMC1/16S-100JTH (10)
R122 7030016150 S.RES RMC1/16S-100JTH (10)
R123 7030016150 S.RES RMC1/16S-100JTH (10)
R124 7030016150 S.RES RMC1/16S-100JTH (10)
R125 7030015970 S.RES RMC1/16S-103JTH (10 k)
R126 7030016250 S.RES RMC1/16S-220JTH (22)
R127 7030016250 S.RES RMC1/16S-220JTH (22)
R128 7030016250 S.RES RMC1/16S-220JTH (22)
R129 7030016250 S.RES RMC1/16S-220JTH (22)
R130 7030016250 S.RES RMC1/16S-220JTH (22)
R131 7030016250 S.RES RMC1/16S-220JTH (22)
R132 7030016250 S.RES RMC1/16S-220JTH (22)
R133 7030016250 S.RES RMC1/16S-220JTH (22)
R134 7030016250 S.RES RMC1/16S-220JTH (22)
R135 7030016250 S.RES RMC1/16S-220JTH (22)
R136 7030016250 S.RES RMC1/16S-220JTH (22)
R137 7030016250 S.RES RMC1/16S-220JTH (22)
R138 7030016250 S.RES RMC1/16S-220JTH (22)
R139 7030016250 S.RES RMC1/16S-220JTH (22)
R140 7030015970 S.RES RMC1/16S-103JTH (10 k)
R141 7030016500 S.RES RMC1/16S-562JTH (5.6 k)
R150 7030016060 S.RES RMC1/16S-105JTH (1 M)
R151 7030015930 S.RES RMC1/16S-471JTH (470)
R152 7030016090 S.RES RMC1/16S-223JTH (22 k)
R153 7030016090 S.RES RMC1/16S-223JTH (22 k)
R154 7030016090 S.RES RMC1/16S-223JTH (22 k)
R155 7030016090 S.RES RMC1/16S-223JTH (22 k)
R156 7030016560 S.RES RMC1/16SJPTH
R157 7030016090 S.RES RMC1/16S-223JTH (22 k)
R158 7030015970 S.RES RMC1/16S-103JTH (10 k)
R159 7030015970 S.RES RMC1/16S-103JTH (10 k)
R160 7030015970 S.RES RMC1/16S-103JTH (10 k)
R161 7030015970 S.RES RMC1/16S-103JTH (10 k)
R162 7030015970 S.RES RMC1/16S-103JTH (10 k)
R163 7030016020 S.RES RMC1/16S-104JTH (100 k)
R164 7030016470 S.RES RMC1/16S-390JTH (39)
R165 7030016250 S.RES RMC1/16S-220JTH (22)
R166 7030016250 S.RES RMC1/16S-220JTH (22)
R167 7030016250 S.RES RMC1/16S-220JTH (22)
R168 7030016560 S.RES RMC1/16SJPTH
R169 7030016250 S.RES RMC1/16S-220JTH (22)
R171 7030016500 S.RES RMC1/16S-562JTH (5.6 k)
R172 7030015990 S.RES RMC1/16S-683JTH (68 k)
R173 7030015970 S.RES RMC1/16S-103JTH (10 k)
R181 7030016110 S.RES RMC1/16S-473JTH (47 k)
R182 7030016110 S.RES RMC1/16S-473JTH (47 k)
R183 7030016110 S.RES RMC1/16S-473JTH (47 k)
R184 7030016110 S.RES RMC1/16S-473JTH (47 k)
R185 7030016110 S.RES RMC1/16S-473JTH (47 k)
R186 7030016110 S.RES RMC1/16S-473JTH (47 k)
R191 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R192 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R201 7030016220 S.RES RMC1/16S-563JTH (56 k)
R202 7030016090 S.RES RMC1/16S-223JTH (22 k)
R203 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R204 7030016110 S.RES RMC1/16S-473JTH (47 k)
R210 7030016150 S.RES RMC1/16S-100JTH (10)
R211 7030016150 S.RES RMC1/16S-100JTH (10)
R212 7030016150 S.RES RMC1/16S-100JTH (10)
R213 7030016150 S.RES RMC1/16S-100JTH (10)
R214 7030016150 S.RES RMC1/16S-100JTH (10)
R215 7030016150 S.RES RMC1/16S-100JTH (10)
R216 7030016150 S.RES RMC1/16S-100JTH (10)
R217 7030016150 S.RES RMC1/16S-100JTH (10)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 163.0/68.0 R218 7030016150 S.RES RMC1/16S-100JTH (10)
T 160.3/68.0 R219 7030016150 S.RES RMC1/16S-100JTH (10)
T 158.5/68.0 R220 7030016150 S.RES RMC1/16S-100JTH (10)
T 155.7/43.4 R221 7030016150 S.RES RMC1/16S-100JTH (10)
T 168.4/43.5 R222 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/62.8 R223 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/64.6 R224 7030016150 S.RES RMC1/16S-100JTH (10)
T 176.8/60.1 R225 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/57.4 R251 7030016300 S.RES RMC1/16S-332JTH (3.3 k)
T 176.8/58.3 R252 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 150.1/45.4 R253 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
T 174.6/63.7 R254 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
T 150.3/58.7 R301 7030016560 S.RES RMC1/16SJPTH
T 150.3/57.8 R302 7030016560 S.RES RMC1/16SJPTH
T 150.3/59.6 R303 7030016560 S.RES RMC1/16SJPTH
T 156.0/68.0 R304 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 157.0/68.0 R305 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
T 155.0/68.0 R306 7030016250 S.RES RMC1/16S-220JTH (22)
T 160.5/43.4 R307 7030016250 S.RES RMC1/16S-220JTH (22)
T 167.5/43.5 R308 7030016250 S.RES RMC1/16S-220JTH (22)
T 167.0/68.0 R309 7030016250 S.RES RMC1/16S-220JTH (22)
T 154.0/68.0 R311 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 168.0/68.0 R312 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 170.2/43.5 R313 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 158.7/43.4 R314 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 150.6/49.9 R315 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/74.8 R316 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
T 145.3/74.3 R317 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/73.7 R318 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/73.2 R319 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/72.6 R320 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 145.3/72.1 R321 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/71.5 R322 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 145.3/71.0 R323 7030016150 S.RES RMC1/16S-100JTH (10)
T 147.3/70.4 R331 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/69.9 R332 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/69.3 R333 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/68.8 R334 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/68.2 R335 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/67.7 R336 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/67.1 R337 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/66.6 R371 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 150.3/60.5 R372 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/62.4 R373 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/61.9 R374 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 147.3/61.3 R375 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/60.7 R376 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/60.2 R377 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 145.3/59.6 R378 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/59.1 R379 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/58.5 R380 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/58.0 R381 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/57.4 R382 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.4/56.9 R383 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 145.3/56.3 R384 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 147.3/55.8 R385 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 145.3/55.2 R386 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 173.7/46.6 R394 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 159.6/43.4 R395 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 165.0/44.5 R396 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 163.2/44.5 R397 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 136.3/78.3 R411 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 137.2/78.3 R412 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 138.1/78.3 R413 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 139.0/78.3 R414 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 135.8/93.9 R421 7030016050 S.RES RMC1/16S-102JTH (1 k)
T 136.7/93.9 R422 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 179.8/37.3 R423 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 186.6/39.3 R431 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 179.4/39.8 R432 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 186.6/38.3 R433 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 179.4/38.8 R434 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 186.6/40.3 R435 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 174.6/59.2 R440 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/61.0 R441 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/61.9 R442 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/60.1 R443 7030016150 S.RES RMC1/16S-100JTH (10)
T 169.6/68.0 R444 7030016150 S.RES RMC1/16S-100JTH (10)
T 174.6/58.3 R445 7030016150 S.RES RMC1/16S-100JTH (10)
T 182.8/34.6 R446 7030016150 S.RES RMC1/16S-100JTH (10)
T 182.8/33.0 R447 7030016150 S.RES RMC1/16S-100JTH (10)
T 183.9/34.6 R506 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 153.6/74.4 R507 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 153.6/73.5 R508 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 153.6/72.6 R509 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 164.5/73.0 R514 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 164.5/71.7 R515 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 164.5/70.5 R516 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 165.8/73.3 R518 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 167.5/69.6 R520 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 183.2/58.7 R522 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 183.2/59.6 R527 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 183.2/60.5 R529 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 181.9/58.2 R531 7030016250 S.RES RMC1/16S-220JTH (22)
T 123.5/79.2 R532 7030016250 S.RES RMC1/16S-220JTH (22)
T 125.5/79.0 R533 7030016150 S.RES RMC1/16S-100JTH (10)
T 126.4/79.0 R534 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 127.7/79.0 R535 7030016150 S.RES RMC1/16S-100JTH (10)
T 128.6/79.0 R536 7030016150 S.RES RMC1/16S-100JTH (10)
T 130.4/79.0 R537 7030016150 S.RES RMC1/16S-100JTH (10)
T 131.3/79.0 R538 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 132.5/79.0 R539 7410001140 S.ARR EXB28V104JX
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-3a
DESCRIPTION M .
LOCATION
T 132.8/93.9
T 131.0/93.9
T 130.1/93.9
T 128.9/93.9
T 128.0/93.9
T 126.2/93.9
T 125.3/93.9
T 123.9/93.9
T 164.0/78.4
T 168.9/75.4
T 166.4/75.4
T 166.5/81.0
T 97.7/92.4
T 108.4/104.5
T 106.1/112.7
T 91.6/92.4
T 92.5/92.4
T 105.0/73.6
T 105.9/73.6
T 106.8/73.6
T 107.7/73.6
T 193.6/40.2
T 202.9/45.0
T 202.9/45.9
T 192.6/53.5
T 193.5/54.4
T 202.9/48.6
T 211.0/31.8
T 209.5/31.8
T 208.0/31.8
T 206.3/37.0
T 187.5/45.8
T 187.5/49.8
T 187.5/52.3
T 110.8/102.3
T 112.1/102.3
T 113.4/102.3
T 111.6/112.9
T 112.9/113.2
T 113.8/113.2
T 108.4/102.7
T 196.8/54.2
T 195.8/54.2
T 88.1/98.8
T 88.1/99.7
T 93.4/92.4
T 94.3/92.4
T 92.6/112.7
T 194.8/54.2
T 88.1/97.9
T 95.9/92.4
T 107.0/112.7
T 104.3/112.7
T 105.2/112.7
T 103.4/112.7
T 91.7/112.7
T 90.8/112.7
T 108.4/103.6
T 108.4/105.4
T 108.4/106.3
T 108.4/107.2
T 202.9/50.9
T 201.8/50.9
T 202.7/54.1
T 201.4/54.8
T 88.1/100.6
T 94.4/112.7
T 93.5/112.7
T 102.5/112.7
T 101.6/112.7
T 100.5/112.7
T 99.6/112.7
T 91.7/129.9
T 104.7/92.4
T 105.6/92.4
T 106.5/92.4
T 107.1/94.1
T 107.6/92.4
T 108.2/94.1
T 108.7/92.4
T 109.3/94.1
T 147.0/102.2
T 147.0/104.2
T 147.0/106.2
T 147.0/108.2
T 142.0/107.9
T 142.0/110.6
T 122.0/106.5
T 139.9/114.7
T 120.1/102.5
T 119.2/102.5
T 121.1/107.5
T 139.0/112.5
T 125.0/104.5
T 125.0/105.5
T 125.0/107.5
T 138.1/112.5
T 125.0/109.5
T 125.0/103.5
T 125.0/102.4
T 118.9/109.3
T 122.1/97.0
H/V
