Icom IC-9700 Service Manual Addendum page 14

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
EP9330 6910015970 S.BEA MMZ1608B 301CT-AS
EP9331 6910015970 S.BEA MMZ1608B 301CT-AS
EP9332 6910015970 S.BEA MMZ1608B 301CT-AS
EP9333 6910015970 S.BEA MMZ1608B 301CT-AS
EP9335 6910015970 S.BEA MMZ1608B 301CT-AS
EP9501 6910019900 S.BEA MPZ1608S601AT
EP9502 6910019900 S.BEA MPZ1608S601AT
EP9503 6910019900 S.BEA MPZ1608S601AT
EP9504 6910019900 S.BEA MPZ1608S601AT
EP9505 6910019900 S.BEA MPZ1608S601AT
EP9506 6910019900 S.BEA MPZ1608S601AT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M .
LOCATION
T 146.3/16.1
T 145.1/16.1
T 143.9/16.1
T 142.7/16.1
T 140.6/16.1
T 173.3/117.0
T 173.3/114.8
T 173.3/112.6
T 173.3/110.4
T 173.3/108.2
T 173.5/105.4
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-13a
