Icom IC-9700 Service Manual Addendum page 11

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C3145 4030022520 S.CER 0402N1R0B500CT
C3146 4030023030 S.CER 0402B103K250CT
C3147 4030023030 S.CER 0402B103K250CT
C3151 4030023030 S.CER 0402B103K250CT
C3152 4030022850 S.CER 0402N391J500CT
C3153 4030023030 S.CER 0402B103K250CT
C3154 4030023030 S.CER 0402B103K250CT
C3155 4030023010 S.CER 0402B104K160CT
C3156 4030022540 S.CER 0402N3R0B500CT
C3161 4030023030 S.CER 0402B103K250CT
C3162 4030023010 S.CER 0402B104K160CT
C3163 4030023030 S.CER 0402B103K250CT
C3164 4030023010 S.CER 0402B104K160CT
C3171 4030019120 S.CER GRM188B31E105KA75D
C3172 4030019120 S.CER GRM188B31E105KA75D
C3181 4030022640 S.CER 0402N101J500CT
C3182 4030022640 S.CER 0402N101J500CT
C3183 4030022640 S.CER 0402N101J500CT
C3184 4030022640 S.CER 0402N101J500CT
C3185 4030022640 S.CER 0402N101J500CT
C3186 4030022640 S.CER 0402N101J500CT
C3187 4030023030 S.CER 0402B103K250CT
C3191 4030022540 S.CER 0402N3R0B500CT
C3192 4030022540 S.CER 0402N3R0B500CT
C3193 4030022580 S.CER 0402N7R0C500CT
C3195 4030022540 S.CER 0402N3R0B500CT
C3196 4030022540 S.CER 0402N3R0B500CT
C3201 4030022560 S.CER 0402N5R0B500CT
C3202 4030022560 S.CER 0402N5R0B500CT
C3203 4030022600 S.CER 0402N9R0C500CT
C3204 4030022660 S.CER 0402N120J500CT
C3205 4030022560 S.CER 0402N5R0B500CT
C3206 4030022560 S.CER 0402N5R0B500CT
C3341 4030023030 S.CER 0402B103K250CT
C3342 4030023030 S.CER 0402B103K250CT
C3343 4030023030 S.CER 0402B103K250CT
C3345 4030022520 S.CER 0402N1R0B500CT
C3346 4030023030 S.CER 0402B103K250CT
C3347 4030023030 S.CER 0402B103K250CT
C3351 4030023030 S.CER 0402B103K250CT
C3352 4030022850 S.CER 0402N391J500CT
C3353 4030023030 S.CER 0402B103K250CT
C3354 4030023030 S.CER 0402B103K250CT
C3355 4030023010 S.CER 0402B104K160CT
C3356 4030022540 S.CER 0402N3R0B500CT
C3361 4030023030 S.CER 0402B103K250CT
C3362 4030023010 S.CER 0402B104K160CT
C3363 4030023030 S.CER 0402B103K250CT
C3364 4030023010 S.CER 0402B104K160CT
C3371 4030019120 S.CER GRM188B31E105KA75D
C3372 4030019120 S.CER GRM188B31E105KA75D
C3381 4030022640 S.CER 0402N101J500CT
C3382 4030022640 S.CER 0402N101J500CT
C3383 4030022640 S.CER 0402N101J500CT
C3384 4030022640 S.CER 0402N101J500CT
C3385 4030022640 S.CER 0402N101J500CT
C3386 4030022640 S.CER 0402N101J500CT
C3387 4030023030 S.CER 0402B103K250CT
C3391 4030022540 S.CER 0402N3R0B500CT
C3392 4030022540 S.CER 0402N3R0B500CT
C3393 4030022580 S.CER 0402N7R0C500CT
C3395 4030022540 S.CER 0402N3R0B500CT
C3396 4030022540 S.CER 0402N3R0B500CT
C3401 4030024550 S.CER 0402N3R5B500CT
C3402 4030024550 S.CER 0402N3R5B500CT
C3403 4030022540 S.CER 0402N3R0B500CT
C3405 4030024550 S.CER 0402N3R5B500CT
C3406 4030024550 S.CER 0402N3R5B500CT
C3407 4030024550 S.CER 0402N3R5B500CT
C3408 4030024550 S.CER 0402N3R5B500CT
C3501 4030019560 S.CER GRM21BB31C106KE15L
C3502 4030019560 S.CER GRM21BB31C106KE15L
C3511 4030019560 S.CER GRM21BB31C106KE15L
C3512 4030019560 S.CER GRM21BB31C106KE15L
C7101 4030022580 S.CER 0402N7R0C500CT
C7102 4030017630 S.CER C1005 CH 1H 120J-T
C7103 4030022580 S.CER 0402N7R0C500CT
C7104 4030022580 S.CER 0402N7R0C500CT
C7105 4030022520 S.CER 0402N1R0B500CT
C7106 4030017630 S.CER C1005 CH 1H 120J-T
C7107 4030022540 S.CER 0402N3R0B500CT
C7108 4030022560 S.CER 0402N5R0B500CT
C7151 4030022810 S.CER 0402N330J500CT
C7152 4030022690 S.CER 0402N151J500CT
C7153 4030022700 S.CER 0402N180J500CT
C7154 4030022870 S.CER 0402N471J500CT
C7155 4030022810 S.CER 0402N330J500CT
C7201 4030024500 S.CER C1005 JB 1C 224K-T
C7202 4030024500 S.CER C1005 JB 1C 224K-T
C7203 4030024500 S.CER C1005 JB 1C 224K-T
C7204 4030024500 S.CER C1005 JB 1C 224K-T
C7205 4030024500 S.CER C1005 JB 1C 224K-T
C7206 4030024500 S.CER C1005 JB 1C 224K-T
C7207 4030024500 S.CER C1005 JB 1C 224K-T
C7208 4030024500 S.CER C1005 JB 1C 224K-T
C7209 4030024500 S.CER C1005 JB 1C 224K-T
C7210 4030024500 S.CER C1005 JB 1C 224K-T
C7211 4030024500 S.CER C1005 JB 1C 224K-T
C7212 4030023010 S.CER 0402B104K160CT
C7213 4030024500 S.CER C1005 JB 1C 224K-T
C7214 4030023010 S.CER 0402B104K160CT
C7215 4030024500 S.CER C1005 JB 1C 224K-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 18.9/22.7 C7216 4030024500 S.CER C1005 JB 1C 224K-T
T 19.3/24.2 C7217 4030024500 S.CER C1005 JB 1C 224K-T
T 19.6/25.6 C7218 4030024500 S.CER C1005 JB 1C 224K-T
T 16.7/27.3 C7219 4030024500 S.CER C1005 JB 1C 224K-T
T 17.9/29.4 C7220 4030024500 S.CER C1005 JB 1C 224K-T
T 18.0/32.1 C7221 4030019560 S.CER GRM21BB31C106KE15L
T 14.4/33.3 C7222 4030019560 S.CER GRM21BB31C106KE15L
T 51.0/24.7 C7223 4030024500 S.CER C1005 JB 1C 224K-T
T 12.3/32.9 C7224 4030023010 S.CER 0402B104K160CT
T 17.4/41.5 C7225 4030019560 S.CER GRM21BB31C106KE15L
T 22.0/45.1 C7226 4030019560 S.CER GRM21BB31C106KE15L
T 21.1/41.0 C7227 4030019560 S.CER GRM21BB31C106KE15L
T 22.0/43.3 C7231 4030023030 S.CER 0402B103K250CT
T 24.8/28.1 C7301 4030022860 S.CER 0402N470J500CT
T 23.6/32.7 C7302 4030022580 S.CER 0402N7R0C500CT
T 17.5/46.6 C7303 4030022900 S.CER 0402N680J500CT
T 15.0/46.6 C7304 4030022680 S.CER 0402N150J500CT
T 15.0/59.8 C7305 4030022840 S.CER 0402N390J500CT
T 17.5/59.8 C7306 4030022590 S.CER 0402N8R0C500CT
T 12.2/46.1 C7307 4030022590 S.CER 0402N8R0C500CT
T 14.1/43.0 C7308 4030022770 S.CER 0402N270J500CT
T 16.3/61.4 C7321 4030022670 S.CER 0402N121J500CT
T 17.6/51.5 C7322 4030022690 S.CER 0402N151J500CT
T 18.5/51.5 C7323 4030022570 S.CER 0402N6R0C500CT
T 19.0/52.7 C7324 4030022560 S.CER 0402N5R0B500CT
T 17.6/54.8 C7353 4030023030 S.CER 0402B103K250CT
T 18.5/54.8 C7354 4030023010 S.CER 0402B104K160CT
T 14.9/51.5 C7402 4030023030 S.CER 0402B103K250CT
T 15.8/51.5 C7404 4030023010 S.CER 0402B104K160CT
T 14.5/52.7 C7421 4030022670 S.CER 0402N121J500CT
T 14.5/53.6 C7422 4030022690 S.CER 0402N151J500CT
T 14.9/54.8 C7423 4030022570 S.CER 0402N6R0C500CT
T 15.8/54.8 C7424 4030022560 S.CER 0402N5R0B500CT
T 40.0/21.6 C7451 4030022860 S.CER 0402N470J500CT
T 44.6/22.4 C7452 4030022580 S.CER 0402N7R0C500CT
T 40.2/23.7 C7453 4030022900 S.CER 0402N680J500CT
T 43.4/28.4 C7454 4030022680 S.CER 0402N150J500CT
T 41.9/28.8 C7455 4030022840 S.CER 0402N390J500CT
T 40.6/29.1 C7456 4030022590 S.CER 0402N8R0C500CT
T 38.8/26.2 C7457 4030022590 S.CER 0402N8R0C500CT
T 36.8/27.4 C7458 4030022770 S.CER 0402N270J500CT
T 34.1/27.5 C7501 4030023010 S.CER 0402B104K160CT
T 32.8/23.9 C7502 4030023010 S.CER 0402B104K160CT
T 48.7/28.0 C7503 4030020120 S.CER C1005 JB 0J 225M-T
T 33.3/21.8 C7504 4030023010 S.CER 0402B104K160CT
T 32.8/36.5 C7505 4030023010 S.CER 0402B104K160CT
T 37.5/40.2 C7506 4030023010 S.CER 0402B104K160CT
T 36.6/36.1 C7507 4030019560 S.CER GRM21BB31C106KE15L
T 37.5/38.4 C7508 4030020120 S.CER C1005 JB 0J 225M-T
T 43.3/39.1 C7509 4030019560 S.CER GRM21BB31C106KE15L
T 43.3/43.7 C7510 4030023030 S.CER 0402B103K250CT
T 36.5/42.2 C7511 4030023030 S.CER 0402B103K250CT
T 34.0/42.2 C7512 4030023030 S.CER 0402B103K250CT
T 34.0/53.7 C7651 4030023030 S.CER 0402B103K250CT
T 36.5/53.7 C7653 4030023010 S.CER 0402B104K160CT
T 31.8/43.2 C7701 4030019560 S.CER GRM21BB31C106KE15L
T 27.8/42.1 C7702 4030023010 S.CER 0402B104K160CT
T 35.3/55.3 C7703 4030023010 S.CER 0402B104K160CT
T 36.8/46.3 C7706 4030023030 S.CER 0402B103K250CT
T 37.7/46.3 C7707 4030023030 S.CER 0402B103K250CT
T 38.1/47.5 C7752 4030023010 S.CER 0402B104K160CT
T 36.8/49.6 C7753 4030023010 S.CER 0402B104K160CT
T 37.7/49.6 C7758 4030023030 S.CER 0402B103K250CT
T 32.0/46.2 C7759 4030023030 S.CER 0402B103K250CT
T 32.9/46.3 C7760 4030023030 S.CER 0402B103K250CT
T 32.5/47.5 C7801 4030023030 S.CER 0402B103K250CT
T 32.0/49.7 C7803 4030023010 S.CER 0402B104K160CT
T 32.9/49.6 C7805 4030019560 S.CER GRM21BB31C106KE15L
T 33.9/47.1 C7852 4030023010 S.CER 0402B104K160CT
T 33.9/48.8 C7854 4030023030 S.CER 0402B103K250CT
T 25.0/20.7 C7931 4030023010 S.CER 0402B104K160CT
T 25.0/25.8 C7932 4030023010 S.CER 0402B104K160CT
T 43.6/32.5 C7933 4030023010 S.CER 0402B104K160CT
T 43.6/37.6 C7934 4030023090 S.CER 0402B102K500CT
T 64.0/44.7 C8051 4030023010 S.CER 0402B104K160CT
T 64.0/45.6 C8052 4030023010 S.CER 0402B104K160CT
T 60.8/44.4 C8053 4030023010 S.CER 0402B104K160CT
T 62.6/45.2 C8054 4030023010 S.CER 0402B104K160CT
T 60.8/46.1 C8061 4030023030 S.CER 0402B103K250CT
T 59.9/44.4 C8062 4030023030 S.CER 0402B103K250CT
T 59.4/46.5 C8063 4030023030 S.CER 0402B103K250CT
T 59.0/44.4 C8064 4030023030 S.CER 0402B103K250CT
T 58.5/47.4 C8071 4030019560 S.CER GRM21BB31C106KE15L
T 57.4/46.1 C8101 4030023010 S.CER 0402B104K160CT
T 56.9/47.4 C8102 4030023010 S.CER 0402B104K160CT
T 56.5/46.1 C8105 4030023030 S.CER 0402B103K250CT
T 55.6/46.1 C8106 4030023030 S.CER 0402B103K250CT
B 36.2/69.5 C8109 4030019560 S.CER GRM21BB31C106KE15L
B 36.9/68.9 C8151 4030023090 S.CER 0402B102K500CT
B 37.5/68.2 C8152 4030023090 S.CER 0402B102K500CT
B 38.2/67.6 C8153 4030023090 S.CER 0402B102K500CT
B 38.8/66.9 C8154 4030023090 S.CER 0402B102K500CT
B 39.5/66.3 C8155 4030023090 S.CER 0402B102K500CT
B 40.1/65.6 C8161 4030023010 S.CER 0402B104K160CT
B 40.8/65.0 C8162 4030023010 S.CER 0402B104K160CT
B 41.4/64.3 C8163 4030023010 S.CER 0402B104K160CT
B 42.1/63.7 C8164 4030023010 S.CER 0402B104K160CT
T 42.3/59.3 C8165 4030023010 S.CER 0402B104K160CT
T 43.5/59.3 C8166 4030023010 S.CER 0402B104K160CT
B 45.2/64.8 C8167 4030023010 S.CER 0402B104K160CT
B 45.9/65.4 C8171 4030019560 S.CER GRM21BB31C106KE15L
B 39.3/73.3 C8172 4030019560 S.CER GRM21BB31C106KE15L
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-10a
DESCRIPTION M .
LOCATION
B 46.5/66.1
B 39.9/74.0
B 47.2/66.7
B 41.6/75.5
B 48.7/68.2
T 32.6/77.4
T 50.8/65.7
B 46.7/73.6
T 35.1/69.1
T 45.3/61.6
T 30.0/73.3
T 29.3/71.0
T 56.0/48.6
T 22.2/58.5
T 21.8/57.3
T 22.7/57.3
T 21.2/56.0
T 22.7/53.8
T 21.2/50.9
T 21.6/49.5
T 22.5/50.4
T 16.9/62.9
T 16.3/64.4
T 19.1/64.9
T 17.5/64.9
T 11.5/68.9
T 12.6/80.5
T 22.0/68.9
T 24.0/80.5
T 35.7/58.6
T 34.6/59.8
T 30.8/56.8
T 31.5/56.2
T 29.0/53.6
T 29.5/52.4
T 28.6/52.4
T 29.6/51.0
T 28.0/51.0
T 29.5/46.9
T 30.0/45.6
T 28.2/46.4
T 26.5/99.0
T 25.2/104.3
T 25.4/100.4
T 25.2/95.2
T 38.2/95.3
T 38.2/104.1
T 22.7/106.9
T 25.0/99.5
T 22.7/105.1
T 65.2/71.7
T 65.7/75.5
T 59.9/71.1
B 57.5/99.6
B 57.5/100.5
B 58.1/107.5
B 64.3/97.6
B 67.7/99.6
B 64.7/94.6
B 69.2/99.3
B 57.5/90.6
B 61.2/87.1
B 58.7/89.6
B 60.7/89.8
B 62.7/93.6
B 65.2/89.6
B 66.2/89.6
B 56.3/107.5
B 69.7/87.4
B 70.2/88.6
T 47.4/113.5
T 47.4/110.0
T 45.6/110.1
T 45.6/107.9
B 77.0/85.7
B 73.7/89.0
B 76.9/91.6
B 73.2/96.4
B 77.0/86.6
B 73.7/87.4
B 74.5/91.6
B 72.7/94.4
B 75.8/106.7
B 77.5/98.3
B 73.7/101.0
B 76.5/98.3
B 71.5/100.6
B 77.7/100.1
B 69.2/90.1
B 70.6/102.3
B 67.3/102.6
B 70.5/94.4
B 70.5/96.1
B 70.1/90.1
B 66.7/97.6
B 65.7/93.6
B 70.5/92.8
B 71.0/97.3
B 67.3/101.6
B 70.6/104.0
B 71.6/107.3
B 72.0/84.5
H/V
