Icom IC-9700 Service Manual Addendum page 12

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C8175 4030022050 S.CER GRM21BR61C226ME44L
C8176 4030022050 S.CER GRM21BR61C226ME44L
C8201 4030023030 S.CER 0402B103K250CT
C8202 4030023030 S.CER 0402B103K250CT
C8203 4030023030 S.CER 0402B103K250CT
C8204 4030023030 S.CER 0402B103K250CT
C8207 4030023010 S.CER 0402B104K160CT
C8208 4030023010 S.CER 0402B104K160CT
C8209 4030023010 S.CER 0402B104K160CT
C8210 4030023010 S.CER 0402B104K160CT
C8213 4030019560 S.CER GRM21BB31C106KE15L
C8251 4030023030 S.CER 0402B103K250CT
C8252 4030023030 S.CER 0402B103K250CT
C8253 4030023030 S.CER 0402B103K250CT
C8257 4030023010 S.CER 0402B104K160CT
C8258 4030023010 S.CER 0402B104K160CT
C8259 4030023010 S.CER 0402B104K160CT
C8263 4030019560 S.CER GRM21BB31C106KE15L
C8301 4030023090 S.CER 0402B102K500CT
C8302 4030023010 S.CER 0402B104K160CT
C8303 4030019560 S.CER GRM21BB31C106KE15L
C8351 4030023090 S.CER 0402B102K500CT
C8352 4030023090 S.CER 0402B102K500CT
C8354 4030023010 S.CER 0402B104K160CT
C8355 4030023010 S.CER 0402B104K160CT
C8357 4030019560 S.CER GRM21BB31C106KE15L
C8501 4030023030 S.CER 0402B103K250CT
C8506 4030023010 S.CER 0402B104K160CT
C8510 4030019560 S.CER GRM21BB31C106KE15L
C8511 4030019560 S.CER GRM21BB31C106KE15L
C8512 4030023010 S.CER 0402B104K160CT
C8513 4030023030 S.CER 0402B103K250CT
C8521 4030023030 S.CER 0402B103K250CT
C8522 4030023030 S.CER 0402B103K250CT
C8526 4030023010 S.CER 0402B104K160CT
C8527 4030023010 S.CER 0402B104K160CT
C8552 4030023030 S.CER 0402B103K250CT
C8554 4030023010 S.CER 0402B104K160CT
C8555 4030019560 S.CER GRM21BB31C106KE15L
C8571 4030023030 S.CER 0402B103K250CT
C8572 4030023010 S.CER 0402B104K160CT
C8601 4030023030 S.CER 0402B103K250CT
C8602 4030023010 S.CER 0402B104K160CT
C8603 4030023090 S.CER 0402B102K500CT
C8604 4030023010 S.CER 0402B104K160CT
C8605 4030023090 S.CER 0402B102K500CT
C8606 4030022630 S.CER 0402N100C500CT
C8607 4030023010 S.CER 0402B104K160CT
C8609 4030023010 S.CER 0402B104K160CT
C8610 4030023030 S.CER 0402B103K250CT
C8611 4030023030 S.CER 0402B103K250CT
C8622 4030023030 S.CER 0402B103K250CT
C8623 4030023010 S.CER 0402B104K160CT
C8624 4030022600 S.CER 0402N9R0C500CT
C8625 4030022590 S.CER 0402N8R0C500CT
C8626 4030022590 S.CER 0402N8R0C500CT
C8627 4030022600 S.CER 0402N9R0C500CT
C8628 4030022700 S.CER 0402N180J500CT
C8629 4030022700 S.CER 0402N180J500CT
C8641 4030023030 S.CER 0402B103K250CT
C8642 4030023030 S.CER 0402B103K250CT
C8643 4030023010 S.CER 0402B104K160CT
C8644 4030022570 S.CER 0402N6R0C500CT
C8645 4030022540 S.CER 0402N3R0B500CT
C8646 4030022540 S.CER 0402N3R0B500CT
C8647 4030022570 S.CER 0402N6R0C500CT
C8648 4030022560 S.CER 0402N5R0B500CT
C8649 4030022590 S.CER 0402N8R0C500CT
C8661 4030023030 S.CER 0402B103K250CT
C8662 4030023030 S.CER 0402B103K250CT
C8663 4030023010 S.CER 0402B104K160CT
C8664 4030022530 S.CER 0402N2R0B500CT
C8665 4030022530 S.CER 0402N2R0B500CT
C8666 4030022530 S.CER 0402N2R0B500CT
C8667 4030022530 S.CER 0402N2R0B500CT
C8668 4030024550 S.CER 0402N3R5B500CT
C8670 4030022660 S.CER 0402N120J500CT
C8671 4030022660 S.CER 0402N120J500CT
C8672 4030022740 S.CER 0402N220J500CT
C8692 4030023010 S.CER 0402B104K160CT
C8693 4030023010 S.CER 0402B104K160CT
C8694 4030023030 S.CER 0402B103K250CT
C8701 4030024500 S.CER C1005 JB 1C 224K-T
C8702 4030022630 S.CER 0402N100C500CT
C8703 4030023230 S.CER 0402B562K500CT
C8704 4030022600 S.CER 0402N9R0C500CT
C8705 4030023090 S.CER 0402B102K500CT
C8706 4030023090 S.CER 0402B102K500CT
C8707 4030023090 S.CER 0402B102K500CT
C8708 4030023090 S.CER 0402B102K500CT
C8709 4030023090 S.CER 0402B102K500CT
C8710 4030023090 S.CER 0402B102K500CT
C8711 4030023090 S.CER 0402B102K500CT
C8712 4030023090 S.CER 0402B102K500CT
C8713 4030023090 S.CER 0402B102K500CT
C8714 4030019560 S.CER GRM21BB31C106KE15L
C8715 4030023090 S.CER 0402B102K500CT
C8716 4030019560 S.CER GRM21BB31C106KE15L
C8717 4030023090 S.CER 0402B102K500CT
C8718 4030023090 S.CER 0402B102K500CT
C8720 4030023030 S.CER 0402B103K250CT
C8721 4030023030 S.CER 0402B103K250CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
B 69.8/107.3 C8732 4030022770 S.CER 0402N270J500CT
B 69.7/84.5 C8734 4030022770 S.CER 0402N270J500CT
B 76.1/90.6 C8735 4030022770 S.CER 0402N270J500CT
B 74.8/94.4 C8736 4030022770 S.CER 0402N270J500CT
B 76.1/101.5 C8801 4030023010 S.CER 0402B104K160CT
B 59.5/87.2 C8802 4030023010 S.CER 0402B104K160CT
B 73.5/90.6 C8803 4030023010 S.CER 0402B104K160CT
B 75.7/94.4 C8804 4030023010 S.CER 0402B104K160CT
B 76.1/102.4 C8805 4030022700 S.CER 0402N180J500CT
B 59.5/86.3 C8806 4030023010 S.CER 0402B104K160CT
B 77.0/88.3 C8811 4030023010 S.CER 0402B104K160CT
B 71.7/89.8 C8812 4030023010 S.CER 0402B104K160CT
B 73.2/102.8 C8813 4030023010 S.CER 0402B104K160CT
B 67.2/105.3 C8821 4030023010 S.CER 0402B104K160CT
B 71.7/87.4 C8822 4030023010 S.CER 0402B104K160CT
B 73.9/104.4 C9001 4030023030 S.CER 0402B103K250CT
B 65.7/105.0 C9002 4030023030 S.CER 0402B103K250CT
B 65.6/107.5 C9003 4030023030 S.CER 0402B103K250CT
B 77.2/103.6 C9004 4030023090 S.CER 0402B102K500CT
B 76.3/103.6 C9005 4030023090 S.CER 0402B102K500CT
B 78.7/107.6 C9006 4030023030 S.CER 0402B103K250CT
B 73.7/98.4 C9007 4030023030 S.CER 0402B103K250CT
B 63.0/89.6 C9008 4030023030 S.CER 0402B103K250CT
B 74.1/99.6 C9009 4030023030 S.CER 0402B103K250CT
B 62.6/88.3 C9010 4030023030 S.CER 0402B103K250CT
B 62.0/107.5 C9011 4030023030 S.CER 0402B103K250CT
B 59.7/90.8 C9012 4030023030 S.CER 0402B103K250CT
B 58.7/88.1 C9013 4030023090 S.CER 0402B102K500CT
B 54.5/107.5 C9014 4030023090 S.CER 0402B102K500CT
B 75.8/108.4 C9101 4030023030 S.CER 0402B103K250CT
B 56.2/102.9 C9102 4030023030 S.CER 0402B103K250CT
B 57.1/102.9 C9103 4030023030 S.CER 0402B103K250CT
B 75.6/97.3 C9104 4030023090 S.CER 0402B102K500CT
B 73.5/92.6 C9105 4030023090 S.CER 0402B102K500CT
B 74.7/97.3 C9106 4030023030 S.CER 0402B103K250CT
B 75.9/92.6 C9107 4030023030 S.CER 0402B103K250CT
B 66.7/91.6 C9108 4030023030 S.CER 0402B103K250CT
B 67.7/90.1 C9109 4030023030 S.CER 0402B103K250CT
B 63.7/107.5 C9110 4030023030 S.CER 0402B103K250CT
B 67.1/87.4 C9111 4030023030 S.CER 0402B103K250CT
B 67.1/88.3 C9112 4030023030 S.CER 0402B103K250CT
T 110.9/37.2 C9113 4030023090 S.CER 0402B102K500CT
T 107.1/36.0 C9114 4030023090 S.CER 0402B102K500CT
T 107.1/36.9 C9115 4030023090 S.CER 0402B102K500CT
T 107.1/35.1 C9116 4030023090 S.CER 0402B102K500CT
T 108.5/40.5 C9151 4030023030 S.CER 0402B103K250CT
T 109.7/40.9 C9152 4030023030 S.CER 0402B103K250CT
T 105.9/36.5 C9201 4030023030 S.CER 0402B103K250CT
T 107.3/38.9 C9202 4030023030 S.CER 0402B103K250CT
T 102.3/39.5 C9203 4030022630 S.CER 0402N100C500CT
T 102.8/40.7 C9204 4030022630 S.CER 0402N100C500CT
T 100.6/39.5 C9205 4030022630 S.CER 0402N100C500CT
T 103.6/34.5 C9206 4030022630 S.CER 0402N100C500CT
T 97.4/34.7 C9207 4030022630 S.CER 0402N100C500CT
T 97.0/35.9 C9208 4030023090 S.CER 0402B102K500CT
T 95.5/36.4 C9209 4030023090 S.CER 0402B102K500CT
T 94.3/36.8 C9210 4030023030 S.CER 0402B103K250CT
T 95.5/34.6 C9211 4030023030 S.CER 0402B103K250CT
T 95.5/35.5 C9212 4030023030 S.CER 0402B103K250CT
T 78.8/37.7 C9213 4030023030 S.CER 0402B103K250CT
T 80.2/39.1 C9214 4030023030 S.CER 0402B103K250CT
T 78.5/42.5 C9215 4030023030 S.CER 0402B103K250CT
T 80.5/46.7 C9216 4030023030 S.CER 0402B103K250CT
T 80.5/47.6 C9217 4030023030 S.CER 0402B103K250CT
T 80.1/49.0 C9218 4030023090 S.CER 0402B102K500CT
T 81.0/49.9 C9219 4030023090 S.CER 0402B102K500CT
T 78.9/47.6 C9301 4030022750 S.CER 0402N221J500CT
T 78.9/48.5 C9302 4030022750 S.CER 0402N221J500CT
T 89.1/61.9 C9303 4030022750 S.CER 0402N221J500CT
T 87.7/63.3 C9304 4030022750 S.CER 0402N221J500CT
T 84.4/64.1 C9305 4030022750 S.CER 0402N221J500CT
T 84.8/67.4 C9306 4030022750 S.CER 0402N221J500CT
T 83.6/67.0 C9307 4030022750 S.CER 0402N221J500CT
T 83.1/65.8 C9308 4030022750 S.CER 0402N221J500CT
T 82.2/64.9 C9310 4030022750 S.CER 0402N221J500CT
T 83.6/68.2 C9311 4030023030 S.CER 0402B103K250CT
T 62.5/70.8 C9312 4030022740 S.CER 0402N220J500CT
T 66.3/70.8 C9321 4030023010 S.CER 0402B104K160CT
T 66.6/68.8 C9322 4030023010 S.CER 0402B104K160CT
T 84.7/42.8 C9323 4030023010 S.CER 0402B104K160CT
T 84.4/49.1 C9325 4030022750 S.CER 0402N221J500CT
T 87.1/74.7 C9326 4030022750 S.CER 0402N221J500CT
T 74.7/58.1 C9327 4030022750 S.CER 0402N221J500CT
T 73.4/56.4 C9328 4030022750 S.CER 0402N221J500CT
T 74.6/56.8 C9329 4030022750 S.CER 0402N221J500CT
T 73.4/57.3 C9330 4030022750 S.CER 0402N221J500CT
T 72.3/54.4 C9331 4030022750 S.CER 0402N221J500CT
T 71.8/59.7 C9332 4030022750 S.CER 0402N221J500CT
T 72.3/52.4 C9333 4030022750 S.CER 0402N221J500CT
T 69.6/50.8 C9334 4030022750 S.CER 0402N221J500CT
T 65.6/61.8 C9335 4030022750 S.CER 0402N221J500CT
T 66.9/50.8 C9336 4030022740 S.CER 0402N220J500CT
T 66.0/50.8 C9337 4030023030 S.CER 0402B103K250CT
T 62.9/54.1 C9401 4030023010 S.CER 0402B104K160CT
T 61.9/56.3 C9501 4030023090 S.CER 0402B102K500CT
T 72.0/50.4 C9502 4030023090 S.CER 0402B102K500CT
T 62.9/58.5 C9503 4030023090 S.CER 0402B102K500CT
T 73.2/59.7 C9504 4030023090 S.CER 0402B102K500CT
T 60.7/49.7 C9506 4030023090 S.CER 0402B102K500CT
T 60.7/50.6
T 60.1/55.2
T 60.0/57.5 RL2241 6310000150 S.REL AGN200S09ZK1
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-11a
DESCRIPTION M .
LOCATION
T 59.3/54.0
T 59.2/58.7
T 57.7/54.0
T 57.6/58.7
T 10.0/110.1
T 11.2/111.7
T 13.8/112.2
T 17.1/112.2
T 18.1/110.3
T 19.1/109.0
T 23.5/112.8
T 20.8/113.0
T 26.4/112.6
T 13.8/115.7
T 19.3/114.8
T 26.6/5.6
T 24.3/3.8
T 23.0/5.6
T 21.3/7.7
T 20.3/7.7
T 19.3/7.7
T 18.3/7.7
T 17.3/7.7
T 16.3/7.7
T 15.3/7.7
T 14.3/7.7
T 13.3/7.7
T 12.3/7.7
T 11.3/7.7
T 131.8/5.6
T 130.0/5.6
T 128.2/5.6
T 126.5/7.7
T 125.5/7.7
T 124.5/7.7
T 123.5/7.7
T 122.5/7.7
T 121.5/7.7
T 120.5/7.7
T 119.5/7.7
T 118.5/7.7
T 117.5/7.7
T 117.0/18.2
T 118.0/18.2
T 119.0/18.2
T 113.0/128.5
T 116.7/123.7
T 181.4/5.6
T 179.4/5.6
T 177.9/7.7
T 177.4/18.2
T 176.9/7.7
T 176.4/18.2
T 175.9/7.7
T 175.4/18.2
T 174.9/7.7
T 174.4/18.2
T 173.9/7.7
T 173.4/18.2
T 172.9/7.7
T 171.9/7.7
T 170.9/7.7
T 169.9/7.7
T 168.9/7.7
T 167.9/7.7
T 166.9/7.7
T 177.3/37.0
T 175.5/37.0
T 173.7/37.0
T 171.9/37.0
T 170.1/37.0
T 168.3/37.0
T 166.5/37.0
T 164.7/37.0
T 141.1/7.1
T 139.7/7.1
T 138.8/7.1
T 156.3/5.9
T 154.8/5.9
T 153.3/5.9
T 178.2/37.0
T 176.4/37.0
T 174.6/37.0
T 172.8/37.0
T 171.0/37.0
T 169.2/37.0
T 167.4/37.0
T 165.6/37.0
T 163.8/37.0
T 162.9/37.0
T 162.0/37.0
T 138.4/18.1
T 137.5/18.1
T 186.6/21.1
T 173.3/115.9
T 173.3/113.7
T 173.3/111.5
T 172.8/109.3
T 173.8/106.6
T 195.5/133.0
H/V
