Chapter 4 — Label Design
Select Normal/Inverse Printing
Normally, an image is printed in black on a transparent background, just
as it was created. Using I
switched. The size of the background is decided by the actual size of the
image including "invisible" background. A
needed when changing back from
NORIMAGE | NI
INVIMAGE| I I
Default:
Reset to default by:
Summary
To create an image fi eld, the following formatting instructions must be
given (in most cases default values may substitute missing parameters).
Image selection by means of variable input, and printing instructions are
explained in Chapters 4.9 and 5.2 respectively.
Purpose
X/Y Position
Alignment
Direction
Magnifi cation
Appearance
Image name
Example:
PP 200,500:AN 3:DIR 3:MAG 2,2:II:PM "GLOBE.1" ↵
38 Intermec Direct Protocol v7.80 Programmer's Reference Manual
, the black and transparent parts can be
NVIMAGE
NORIMAGE
PRINTFEED (PF)
Instruction
PP (PRPOS)
AN (ALIGN)
DIR
MAG
II (INVIMAGE)
NI (NORIMAGE)
PM (PRIMAGE)
NORIMAGE
printing.
INVIMAGE
Default
0/0
1
1
1,1
off
on
n.a.
statement is only
Remarks
Number of dots
Select ALIGN 1- 9
Select DIR 1- 4
Height 1-4, Width
1-4
Black/white inversed
Normal (revokes
INVIMAGE)
Full name incl.
extension
