Docking Base Connector
Pin Signal
61 CD Reset*
62 PEB +5V
63 Sec IDE Data 2
64 Sec IDE Data 3
65 Sec IDE Data 6
66 Sec IDE Data 7
67 Sec IDE Data 10
68 Sec IDE Data 11
69 Sec IDE Data 14
70 Ground
71 Sec IDE IO Read*
72 Ground
73 Port84 Enable*
74 Ground
75 Sec IDE Data Address 1
76 Ground
77 Sec IDE Chip Sel (300
range)
78 Ground
79 Ground
80 PEB ID*
81 Game Port 3
82 Ground
83 MBATT
84 WT_MCLK
85 WT_MSD
86 RSTB*
87 Ground
88 +VBAT
89 +VBAT
90 +VBAT
Continued
Pin
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
Signal
Sec IDE Data 0
Sec IDE Data 1
Sec IDE Data 4
Sec IDE Data 5
Sec IDE Data 8
Sec IDE Data 9
Sec IDE Data 12
Sec IDE Data 13
Sec IDE Data 15
Sec IDE IO Write*
Sec IDE IO Ready
IRQ14
No Connection
Sec IDE Data Address 0
Sec IDE Data Address 2
CDPDIAG
Sec IDE Chip Sel (100 range)
CDDASP*
Ground
Game Port 2
Game Port 0
Game Port 1
External Audio Select*
2
I C Clock
2
I C Data
Exp Ro
Ground
Exp Lo
Ground
Ground
Connector Pin Assignments C-5
