Compaq Armada 4200 Reference Manual page 151

appendix
C
ONNECTOR
14
1
Pin Signal
1 Strobe*
2 Data Bit 0
3 Data Bit 1
4 Data Bit 2
5 Data Bit 3
6 Data Bit 4
7 Data Bit 5
8 Data Bit 6
9 Data Bit 7
10 Acknowledge*
11 Busy
12 Paper Out
C
P
IN
Parallel Connector
Pin
13
14
15
16
17
18
19
20
21
22
23
24
25
A
SSIGNMENTS
Signal
Select
Auto Linefeed*
Error*
Initialize Printer*
Select In*
Ground
Ground
Ground
External FDD Detect
External FDD Detect
Ground
Ground
External FDD +5V
Connector Pin Assignments C-1
25
13
