Wiring Diagrams

If any of the original wires as supplied with the
appliance must be replaced, it must be replaced
with CSA type SEW (200 C) or its equivalent.
o
This heater does not require a 120V A.C.
supply for operation. In case of a power failure,
the burner switch and the optional remote control/
thermostat will continue to operate. However, a
120V A.C. power supply is needed for the fan/
blower operation.
Grey
Red
Hampton® H35U Direct Vent Freestanding Gas Stove
Caution: Ensure that the wires do
not touch any hot surfaces and are
away from sharp edges.
CAUTION:
to disconnection when servicing
controls. Wiring errors can cause
improper and dangerous operation.
(To THTP)
(To TH)
Cut here
(OPTIONAL REMOTE)
Receiver
Remote OFF
ON
Label all wires prior
Neutral
Live
Black
Fan Thermodisc
(normally open)
DC
SPARKER
Green
Red
White
To Thermocouple IN
Remote
installation
WARNING: Electrical Grounding
Instructions
This appliance is equipped with a
three pronged (grounding) plug for
your protection against shock hazard
and should be plugged directly into
a properly grounded three-prong
receptacle. Do not cut or remove the
grounding prong from this plug.
Green
Fan
Black
White
Ground
Green
ON OFF
Black
Rotary Speed
Control
Gas In
