BA00282R/09/EN/14.15
71288576
Products
Operating Instructions
RID14
Fieldbus indicator
with FOUNDATION Fieldbus™ protocol
Solutions
50
40
30
20
10
0
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser RID14

Summary of Contents for Endress+Hauser RID14

  • Page 1 Products Solutions Services BA00282R/09/EN/14.15 71288576 Operating Instructions RID14 Fieldbus indicator with FOUNDATION Fieldbus™ protocol...

  • Page 3: Table Of Contents

    RID14 Table of contents Table of contents 10.2 Status messages ..... . Document information ....4 10.3 Spare parts .

  • Page 4: Document Information

    Document information RID14 Document information Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
  • Page 5 RID14 Document information 1.2.3 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred. Forbidden Procedures, processes or actions that are forbidden. Indicates additional information. Reference to documentation...

  • Page 6: Safety Instructions

    Conversions to the device Unauthorized modifications to the device are not permitted and can lead to unforeseeable dangers. ‣ If, despite this, modifications are required, consult with Endress+Hauser. Repair To ensure continued operational safety and reliability, ‣ Carry out repairs on the device only if they are expressly permitted.

  • Page 7: Product Safety

    If a plastic transmitter housing is permanently exposed to certain steam and air mixtures, this can damage the housing. ‣ If you are unsure, please contact your Endress+Hauser Sales Center for clarification. ‣ If used in an approval-related area, observe the information on the nameplate.

  • Page 8: Identification

    Compare the order code on the nameplate of the device to that on the delivery papers. Made in Germany 2013 RID14 D-87484 Nesselwang Order code: RID14-XXXX/X Ser. no.: XXXXXXXXXXX Ext. ord. cd.: RID14-XXXXX 9 - 32 V IP66/67 Type 4X Ta = -40 ...+55/70/80°C FW: 1.00.00-[1...1] DevRev: X A0012565 ...
  • Page 9 RID14 Identification 3.3.1 Certification Foundation Fieldbus™ The field indicator has successfully passed all the tests and is certified and registered by the Fieldbus Foundation. The device meets all the requirements of the following specifications: • Certified in accordance with FOUNDATION Fieldbus™ specification •...

  • Page 10: Installation

    Installation RID14 Installation Incoming acceptance, transport, storage The permitted ambient and storage conditions must be observed. The precise specifications can be found in Section "Technical data". 4.1.1 Incoming acceptance On receipt of the goods, check the following points: • Are the packaging or contents damaged? •...

  • Page 11: Installation Instructions

    RID14 Installation 4.2.2 Installation location Information on conditions that must be present at the installation location to mount the device correctly can be found in Section ' T echnical data' . These include the ambient temperature, degree of protection, climate class etc.

  • Page 12: Post-Installation Check

    Installation RID14 A0011258  4 Mounting the field indicator on a pipe with the mounting bracket for pipe diameters 1.5 to 2.2" Mounting plate Mounting bracket 2 M6 nuts Post-installation check After installing the device, always run the following final checks:...

  • Page 13: Wiring

    RID14 Wiring Wiring WARNING Danger of explosion if unit is connected incorrectly in hazardous area ‣ When connecting Ex-approved devices please take special note of the instructions and connection schematics in the Ex-specific supplement to these Operating Instructions. If you have any questions, please do not hesitate to contact your E+H representative.

  • Page 14: Connection To The Foundation Fieldbus

    Wiring RID14 5.1.1 Quick wiring guide ESD - electrostatic discharge Protect the terminals from electrostatic discharge. Failure to observe this may result in destruction or malfunction of parts of the electronics. A0012751 FOUNDATION Fieldbus A0012569  6 Terminal assignment Terminal Terminal assignment FOUNDATION Fieldbus™...
  • Page 15 Fieldbus connector Optionally, a fieldbus connector can be installed in field housing instead of a cable gland. Fieldbus connectors can be ordered from Endress+Hauser as an accessory (see Section ' A ccessories' ) . The connection technology of FOUNDATION Fieldbus™ allows measuring devices to be connected to the fieldbus via uniform mechanical connections such as T-boxes, junction boxes, etc.

  • Page 16: Foundation Fieldbus™ Cable Specification

    Wiring RID14 26.5 mm (1.040") 250 mm (9.84”) 150 mm (5.91”) M20x1.5 / NPT 1/2” 7/8-16 UNC A0012573  8 Connectors for connecting to the FOUNDATION Fieldbus™ Pin-Belegung / Farbcodes Fieldbus connector Blue wire: FF– (terminal 2) Field indicator Brown wire: FF+ (terminal 1)
  • Page 17 RID14 Wiring Type A Type B Characteristic impedance at 31.25 kHz 100 Ω ±20 % 100 Ω ±30 % Attenuation constant at 39 kHz 3 dB/km 5 dB/km Capacitive asymmetry 2 nF/km 2 nF/km Envelope delay distortion (7.9 to 39 kHz) 1.7 mS/km...
  • Page 18 Wiring RID14 Optimum electromagnetic compatibility (EMC) of the fieldbus system can only be guaranteed if the system components and, in particular, the lines are shielded and the shield forms as complete a cover as possible. A shield coverage of 90% is ideal.

  • Page 19: Degree Of Protection

    RID14 Wiring 5.3.7 Further information General information and further points on wiring can be found on www.fieldbus.org, the Web site of the Fieldbus Foundation. Degree of protection The devices fulfill the requirements for IP 67 degree of protection. Compliance with the...

  • Page 20: Operating The Field Indicator

    Operating the field indicator RID14 Operating the field indicator Quick operation guide Operators have two options for configuring and commissioning the device: 1. Configuration programs The configuration of FF functions and device-specific parameters is done via the fieldbus interface. You can obtain special configuration and operating programs from various manufacturers for these purposes →...

  • Page 21: Display And Operating Elements

    RID14 Operating the field indicator Display and operating elements 6.2.1 Display A0012574  11 LC display of the field indicator Bar graph display in increments of 10% with indicators for underranging (item 1a) and overranging (item 1b) Measured value display, status indication "Bad measured value status"...
  • Page 22 Operating the field indicator RID14 Visualization and monitoring e. g. P View, FieldCare and diagnostic software Field controller High speed Ethernet (HSE) 100 Mbit/s Linking Linking Linking 31.25 kbit/s Device Device Device H1 IEC 61158-2 FISCO 0 - 10 bar...
  • Page 23 RID14 Operating the field indicator Data can be directly exchanged between field devices, e.g. a sensor and an actuating valve. Each bus user ’publishes’ its data on the bus and all the bus users configured accordingly obtain this data. Publication of this data is carried out by a ’bus administrator’ known as the ’Link Active Scheduler’, which controls the sequence of bus communication centrally.

  • Page 24: Configuration Of The Field Indicator

    Operating the field indicator RID14 In the case of sensors these are typically the following blocks: • "Analog Input" or • "Discrete Input" (digital input) Actuating valves normally have the function blocks: • "Analog Output" or • "Discrete Output" (digital output) For control tasks there are the blocks: •...

  • Page 25: Hardware Settings

    RID14 Operating the field indicator The FF communication system will only function properly if correctly configured. You can obtain special configuration and operating programs from various manufacturers for the configuration. Process control systems Asset management systems Endress+Hauser ControlCare National Instruments NI-Configurator (≥ 3.1.1)
  • Page 26 Operating the field indicator RID14 A0011641  13 Hardware settings via DIP switches Switch position ON Switch position OFF Write lock Endress+Hauser...

  • Page 27: Commissioning

    ID, device type and device serial number. It is unique and can never be assigned twice. The DEVICE_ID of the device is composed as follows: DEVICE_ID = 452B4810CF-XXXXXXXXXXX 452B48 = Endress+Hauser 10CF = RID1x XXXXXXXXXXX = device serial number (11-digit)
  • Page 28 4. Switch the device on.  The first time you establish a connection, the device reacts as follows in the configuration system: EH_RID14-xxxxxxxxxxx (for RID14, xxx... = serial number) 452B4810CF-xxxxxxxxxxx (DEVICE_ID) for RID1x Block structure →  29 5. Using the DEVICE_ID noted, identify the field device and assign the desired tag name (PD_TAG) to the fieldbus device in question.
  • Page 29 RID14 Commissioning Block description Permanent Block class Resource Extended Display Transducer Manufacturer-specific Advanced Diagnostic Manufacturer-specific Standard Input Selector 1 Standard Input Selector 2 Standard Arithmetic Standard Integrator Standard The device is delivered from the factory with the bus address “247” and is thus in the address range for readdressing field devices.
  • Page 30 Commissioning RID14 using graphic display) and then the time for processing the individual process control functions is specified. Endress+Hauser...

  • Page 31: Maintenance

    RID14 Maintenance Maintenance No special maintenance work is required on the device. Endress+Hauser...

  • Page 32: Accessories

    Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.

  • Page 33: Troubleshooting

    RID14 Troubleshooting Troubleshooting 10.1 Troubleshooting instructions In the event of a serious fault, an indicator might have to be returned to the manufacturer for repair. Follow the instructions in →  38 before returning the indicator. Always start troubleshooting with the checklists below if faults occur after start up or during operation.

  • Page 34: Status Messages

    Troubleshooting RID14 Problems when configuring function blocks Transducer Blocks: Check whether the operating mode of the Resource Block is set to AUTO → The operating mode MODE_BLK parameter group / TARGET parameter. cannot be set to AUTO. Transducer Blocks: The device description file (Device Description, DD) has not yet been loaded to the The manufacturer-specific host system or the configuration program? →...

  • Page 35: Spare Parts

    RID14 Troubleshooting Category No. Status message Display Cause of error / remedy symbol • CURRENT_STATUS_ NUMBER in the 'Advanced Diagnostics' Transducer Block • Local display 261 Device status message (FF): No bargraph Cause of error: Electronics board defective displayed Error in the electronics.

  • Page 36: Software History And Overview Of Compatibility

    3x thread NPT1/2, without terminal block 3x M20x1.5, without terminal block 3x thread G1/2, without terminal block Version: Standard RIA141G- ← Order code cpl. housing RID14 Item No. Type Order number Housing cover cpl. display aluminum Ex d + RIA141X-HK seal Housing cover cpl.
  • Page 37 RID14 Troubleshooting The release number on the nameplate and in the Operating Instructions indicates the device release: XX.YY.ZZ (example 01.02.01). Change to main version. No longer compatible. The device and Operating Instructions change. Change to functions and operation. Compatible. Operating Instructions change.

  • Page 38: Return

    The measuring device must be returned if it is need of repair or a factory calibration, or if the wrong measuring device has been delivered or ordered. Legal specifications require Endress+Hauser, as an ISO-certified company, to follow certain procedures when handling products that are in contact with the medium.

  • Page 39: Disposal

    RID14 Disposal Disposal The device contains electronic components and must therefore be disposed of as electronic waste. Comply with local disposal regulations. Endress+Hauser...

  • Page 40: Technical Data

    Technical Data RID14 Technical Data 13.1 Communication 13.1.1 Breakdown information Status message as per the fieldbus specification. 13.1.2 Switch-on delay 13.1.3 FOUNDATION Fieldbus™ • FOUNDATION Fieldbus™ H1, IEC 61158-2 • FDE (Fault Disconnection Electronic) = 0 mA • Data transmission rate: supported baud rate = 31.25 kBit/s •...
  • Page 41 RID14 Technical Data Link settings Slot time Min. inter PDU delay Max. response delay Blocks Block description Block index Permanent Block execution time Block class Resource Extended Display Transducer Manufacturer-specific Advanced Diagnostic Manufacturer-specific 100 ms Standard Input Selector 1 35 ms...

  • Page 42: Power Supply

    Technical Data RID14 mean values are calculated, and flow values are compensated (linear, quadratic compensation), in this block. 13.2 Power supply 13.2.1 Electrical connection A0021528  15 Terminal assignment of the field indicator Fieldbus connection 13.2.2 Supply voltage Voltage is supplied via the fieldbus.

  • Page 43: Environment

    RID14 Technical Data 13.4 Environment 13.4.1 Ambient temperature limits –40 to +80 °C (–40 to +176 °F) The display can react slowly at temperatures < –20 °C (–4 °F). The readability of the display is no longer guaranteed at temperatures <...

  • Page 44: Mechanical Construction

    Technical Data RID14 13.4.9 Measuring category Measuring category II as per IEC 61010-1. The measuring category is provided for measuring on power circuits that are directly connected electrically with the low-voltage network. 13.4.10 Degree of contamination Pollution degree 2 as per IEC 61010-1.

  • Page 45: Operability

    RID14 Technical Data 13.6 Operability 13.6.1 Local operation Display elements A0011307  17 LC display of the field indicator (backlit, pluggable in 90° stages) bar graph display in increments of 10% with indicators for underranging (item 1a) and overranging (item 1b) measured value display, digit height 20.5 mm (0.8 in), status indication "Bad measured value status"...

  • Page 46: Certificates And Approvals

    • System Components and Data Managers - Solutions for the loop: FA00016K/09 • Competence Brochure FOUNDATION fieldbus - Process automation with digital fieldbus technology: CP00003S/04 • Technical Information RID14, 8-channel field indicator with FOUNDATION Fieldbus™ or PROFIBUS® PA protocol: TI00145R/09 Technical Information RID16, 8-channel field indicator with FOUNDATION Fieldbus™ or PROFIBUS®...

  • Page 47: Appendix

    RID14 Appendix Appendix 14.1 Block model In the FOUNDATION™ Fieldbus all the device parameters are categorized according to their functional properties and task and are generally assigned to three different blocks. A block may be regarded as a container in which parameters and the associated functionalities are contained.
  • Page 48 Appendix RID14 14.2.1 Selecting the operating mode The operating mode is set by means of the MODE_BLK parameter group. The Resource Block supports the following operating modes: • AUTO (automatic mode) • OOS (out of service) The ' O ut of Service' (OOS) operating mode is also displayed by means of the BLOCK_ERR parameter.
  • Page 49 RID14 Appendix 14.2.5 Resource Block FF parameters The following table shows all the specified FOUNDATION™ Fieldbus parameters of the Resource Block. Resource Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) Acknowledge AUTO - OOS This parameter is used to specify whether a process alarm must be acknowledged at Option the time of alarm recognition by the fieldbus host system.
  • Page 50 Manufacturer ID Read only Displays the manufacturer' s ID number. (MANUFAC_ID) Display: 0 x 452B48 = Endress+Hauser Max Notify Read only Displays the maximum number of event reports supported by the device that can (MAX_NOTIFY) exist unconfirmed at the same time.
  • Page 51 RID14 Appendix Resource Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) Display: AUTO - OOS The Resource Block supports the following operating modes: AUTO In this mode the execution of the remaining blocks (ISEL, (automatic Arithmetic, Integrator and PID function block) is permitted.
  • Page 52 Appendix RID14 Resource Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) Serial Number Read only Displays the device serial number. (SERIAL_NUMBER Service Locking AUTO - OOS Only for service reasons. (SERVICE_LOCKIN Set Fault State AUTO - OOS This parameter can be used to manually enable the security behavior of the device.

  • Page 53: Transducer Blocks

    RID14 Appendix Resource Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) User input: • 0 = The write protection alarm is not evaluated. • 1 = No report to the fieldbus host system in the event of a write protection alarm.
  • Page 54 Appendix RID14 Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) Factory setting: These data are neither checked nor processed by the Transducer Blocks. Alert key AUTO - OOS Use this function to enter the identification number of the plant unit.
  • Page 55 RID14 Appendix Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) Transducer Error Read only The active device error appears on the display. (XD_ERROR) Possible display: • No Error (normal status) • Electronics failure • Data Integrity Error •...
  • Page 56 Appendix RID14 Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) DISP_VALUE_1_DI Read only This block shows the current digital display value. The block supports: GITAL • DISP_VALUE_1[...8]_STATUS: DISP_VALUE_2_DI Status of the current discrete display value. This value is selected through the GITAL parameter "Source digital"...
  • Page 57 RID14 Appendix Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) DISP_VALUE_1_SE AUTO - OOS This parameter defines all values for the setup of the display. Fllowing parameters TTINGS are included: DISP_VALUE_2_SE • DISP_VALUE_1[...8]_LISTENER_MODE: TTINGS Activates the "Listener mode". In this mode the device is able to show values DISP_VALUE_3_SE published to the bus by other devices.
  • Page 58 Appendix RID14 Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) • DISP_VALUE_1[...8]_FORMAT: Number of places after decimal point for the display. Available parameters are: – Auto (the device automatically sets the position of the decimal point to fill all 5 digits of the display) –...

  • Page 59: Pid Function Block (Pid Controller)

    RID14 Appendix Transducer Block Parameter Index Parameter Write access with Description operating mode (MODE_BLK) C561 Choose different display format F283 Restart device, if error still resists, exchange electronics F261 Exchange electronics CURRENT_STATUS Read only This Parameter displays the Display channel were the ' C urrent diagnostics' message _ CHANNEL appeared.

  • Page 60: Input Selector Function Block

    Appendix RID14 The possibilities available for processing measured values within the PID function block include: signal scaling and limiting, operating mode control, actuating, limiting control, limit detection and signal status propagation. A detailed description of the PID function block can be found in the Guideline FOUNDATION Fieldbus Function Blocks (www.endress.com/download →...

  • Page 61: Index

    RID14 Index Index Installation location ......11 Integrator function block ..... . 60 Alarm detection and processing .
  • Page 62 Index RID14 FF parameters ......53 Transducer blocks ......29 Transducer Blocks .
