2-way Front System + 2-way Passive Rear System + 2 Subwoofer
Possible routing for this setup
Input/ Output Assignments:
Input
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
Assignment
Output
Front Left
CH 1
Front Right
CH 2
Rear Left
CH 3
Rear Right
CH 4
Subwoofer 1
CH 5
Subwoofer 2
CH 6
CH 7
CH 8
Output Connections
SPEAKER OUTPUT
18
15
12
17
14
11
16
13
10
Assignment
Tweeter Front Left
Tweeter Front Right
Low Range Front Left
Low Range Front Right
Full Range Rear Left
Full Range Rear Right
Subwoofer Left
Subwoofer Right
9
6
3
5
2
8
7
4
1
35
-EN
