3-way Front System + Center + Mono Amplifier + Subwoofer
Possible routing for this setup
Input/ Output Assignments:
Input
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
Assignment
Output
Front Left
CH 1
Front Right
CH 2
Rear Left
CH 3
Rear Right
CH 4
Subwoofer 1
CH 5
Subwoofer 2
CH 6
CH 7
RCA
Output Connections
SPEAKER OUTPUT
18
15
12
17
14
11
16
13
10
Assignment
Tweeter Front Left
Tweeter Front Right
Midrange Front Left
Midrange Front Right
Low Range Rear Left
Low Range Rear Right
Center
To External Amplifier
9
6
3
5
2
8
7
4
1
MONO AMPLIFIER
33
-EN
