■ 製品の呼び方 本文中の製品名称を次のように略して表記します。 製品名称 本文中の表記 内蔵 LTO3 ユニット(PG-LT301/PGBLT301) 本製品 ® Microsoft Windows Small Business Server 2003 SBS 2003 ® Microsoft Windows Server™ 2003, Standard Edition Windows Server 2003 ® Microsoft Windows Server™ 2003, Enterprise Edition Windows ® Microsoft Windows Server™ 2003, Standard x64 Edition Windows Server 2003 x64 ®...
各部の名称と働き この章では、本製品の各部の名称と働きについて説明しています。 イジェクトボタンおよび LED について Ready LED Drive Error LED Tape Error LED Clean LED ■ イジェクトボタン ドライブに入っているデータカートリッジを取り出すときに押します。10 秒以上押し続け ないでください(強制排出されて、OS、バックアップソフトウェアでエラーとなることが あります) 。 →「2.2.2 取り出し方法(手動・自動) 」 (P.20) ■ Ready LED / Drive Error LED / Tape Error LED / Clean LED 本製品の状態を示す...
LED について この章では、各 LED の状態について説明しています。 本製品前面には、4 つの LED があり、本製品の状態を示します。 Ready Drive Error Tape Error Clean ■ 自己診断中の LED 本製品に電源が供給されるかリセットされると、本製品は自己診断テストを行います(約 5 秒かかります) 。 自己診断テストが正常に行われた場合、Ready LED が数回点滅してから点灯します。他の LED は消灯します。 自己診断テストで異常が検出された場合、Drive Error LED と Tape Error LED が点滅しま す。この場合、本製品の故障が考えられます。担当営業員または担当保守員に連絡してく ださい。 ■ LED によるトラブルシューティング 問題がある場合は、次の表の対処方法に従って解決してください。...
製品の概要 ■ 製品名 使用する OS に応じて、2 つの製品があります。 ・ Fujitsu Tape Maintenance Advisor for Windows ・ Fujitsu Tape Maintenance Advisor for Linux ■ 動作環境 Windows では、本ソフトウェアはサービスの1つを使用します。 Linux では、X-Window(GNOME)が導入され、ログインされている必要がありま す。 ・ OS - Windows の場合 ・ Windows 2000 Server (*) ・ Windows Server 2003 /...
付録 C Windows 自動システム回復 機能(ASR)の手順について ASR でのシステムデータ回復手順 ASR でのシステムデータの回復手順について説明します。 C.1.1 必要な物 ・ Windows Server 2003 CD-ROM ・ ドライバフロッピーディスク「PRIMERGY LTO3 UNIT Device Driver for Windows」 ・ オペレーティングシステムバックアップメディア(Windows 自動システム回復機能用に システムデータをバックアップしたテープ媒体) ・ Windows 自動システム回復ディスク(フロッピーディスク) また、必要に応じて次のものを用意してください。 ・ SCSI カード用ドライバディスク(フロッピーディスク) ・ SCSI アレイコントーローラカード用デバイスドライバディスク(フロッピーディスク) C.1.2 注意事項...
Page 47
C.1.3 システムデータの回復手順 Windows Server 2003 CD-ROM をドライブに入れて、サーバを起動し ます。 Windows セットアップ画面になり、画面の下部に次のメッセージが表示されます。 Press F6 if you need install a third party SCSI or RAID driver … このメッセージは約 5 秒間表示されたあと、自動的に次のメッセージに変わりま す。次の操作を素早く行ってください。 Windows Setup 画面にならない時は、BIOS の設定を行ってください。 【F6】キーを押します。 【F6】キーを押しても次のメッセージに置き換わるまでこのメッセージは画面に残 ります。 画面の下部に、次のメッセージが表示されます。 Press F2 to run Automated System Recovery (ASR) … このメッセージは約...
Page 48
1 ~ 2 分後に、画面中央に次のメッセージが表示されます。 Setup could not determine the type of one or more mass storage devices installed in your system, or you have chosen to manually specify an adapter. Currently, Setup will load support for the following mass storage devices(s): <...
Page 49
使用しているシステムに適するドライバにカーソルを合わせ、 【Enter】 キーを押します。 画面中央に、次のメッセージが表示されます。 Setup will load support for the following mass storage device(s): << 選択したドライバ名 >> * To specify additional SCSI adapters, CD-ROM drives, or special disk controllers for use with Windows, including those for with you have a device support disk from a mass storage device Manufacture, press S.
ハードディスクドライブの初期化手順例 ハードディスクドライブを初期化する手順がない場合は、次の方法で初期化してくださ い。 「C.1.3 システムデータの回復手順」 (→ P.47)の手順 3 の操作を除き、 「C.1.3 システムデータの回復手順」 (→ P.47)の手順 7 までの操作を行 います。 OS のセットアップを続行するかを問うメッセージが表示されます。 OS のインストールは行いませんが、セットアップは続行するので、メッ セージに従い、 【Enter】キーを押します。 セットアップ開始の確認を求めるメッセージが表示されたら、 【Enter】 キーを押します。 Windows ライセンス契約の画面が表示されたら、 【F8】キーを押します。 「C.1.3 システムデータの回復手順」 (→ P.47)の手順 7 に進みます。 Windows がインストールされている場合には、手順 4 で【F8】キーを押しても 「C.1.3 システムデータの回復手順」 (→ P.47)の手順 7 に進まずに既存の Windows の修復を行うか、新しい...
Page 53
Before Reading This Manual Thank you for purchasing the Fujitsu Tape Drv LTO3 Ultrium3 400GB (PG-LT301/PGBLT301). This manual explains the basic usage of the Tape Drv LTO3 Ultrium3 400GB (hereafter referred to as "this product" or "the drive"). Before using this product, read this manual in order to handle it properly.
Page 54
Remarks Warning descriptions Various symbols are used throughout this manual. These are provided to emphasize important points for your safety and that of others. The symbols and their meanings are as follows. Be sure to fully understand these before reading this manual. Ignoring this symbol could be potentially lethal.
Page 55
Abbreviations The following expressions and abbreviations are used to describe the product names used in this manual. Product names Expressions and abbreviations Tape Drv LTO3 Ultrium3 400GB "This product" or "the unit" (PG-LT301/PGBLT301) ® Microsoft Windows Small Business Server 2003 SBS 2003 ®...
Page 56
WARNING • Do not tinker with this product. Doing so may cause an electric shock or fire. CAUTION • Do not disassemble this product or take it apart. • Do not use or store this product in the following environments. - Environments with extremely low temperature - Environments with extremely high temperatures and high humidity - Environments where temperature and humidity change greatly and rapidly.
Page 57
If any items are missing, contact an office listed in "Appendix B Contact Information" ( pg.88). • Tape Drv LTO3 Ultrium3 400GB (this product) • Cleaning cartridge (Ultrium1 Cleaning cartridge U) • Driver floppy disk "PRIMERGY LTO3 UNIT Device Driver for Windows" • Screws (x4) • Washer (x4) •...
Page 58
Contents 1 Installing the Unit to a Server ......Checking the Installation Environment ......Setting Jumpers .
Installing the Unit to a Server This chapter explains how to install this unit to a server. Install the unit in accordance with the following procedures. Check the installation environment. "1.1 Checking the Installation Environment"(pg.59) Set jumpers. "1.2 Setting Jumpers"(pg.60) Install the unit to the server and connect the SCSI cable and the power cable.
Setting Jumpers Normally it is not necessary to change the SCSI-ID. The SCSI-ID can be set using the short jumpers on the rear of the unit (diagram below). [Rear] Short jumpers Term Power SCSI-ID 0 SCSI-ID 1 Reserved SCSI-ID 2 SCSI-ID 3 SCSI connector Power connector...
Installing the Driver To use this product for Windows Server 2003 / SBS 2003 / Windows 2000 Server, use the floppy disk driver provided with this product and install the driver according to the following procedures (Make sure that this product is connected correctly before installing the driver). However, if "Hewlett Packard LTO Ultrium-3 drive"...
Page 62
• When using a CD such as ServerStart • For Windows Server 2003 / SBS 2003 [CD-ROM drive]:\DRIVERS\tape\LTO3\drivers\WinNT\Win2003\i386 • For Windows Server 2003 x64 [CD-ROM drive]:\DRIVERS\tape\LTO3\drivers\WinNT\Win2003\x64 Click [Next]. The "Completing the Hardware Update Wizard" message appears. Click [Finish], and click [Close]. Restart the server.
Page 63
Restart the server. 1.3.2 Driver Installation (For PRIMERGY FT) Notes • This product can be installed only to FT1. It cannot be installed to FT2. • Two of this product cannot be installed at the same time. • This product cannot be used from CoServer. •...
Page 64
After installing the driver to FTvirtual Server by repeating steps 4 - 12, restart the FTvirtual Server. 1.3.3 About the Driver Please download the latest driver for windows 2000 Server / Windows Server 2003 / Windows Server 2003 x64 from the Fujitsu PRIMERGY website (http://primergy.fujitsu.com).
Component Names and Functions This chapter explains the component names and functions of this product. Eject Button and LEDs Data cartridge insertion slot Eject button Emergency reset Ready LED Drive Error LED Tape Error LED Clean LED Eject button Press this button to eject the cartridge from the drive. Do not press this button for more than 10 seconds (Forcible ejection will be performed, and may cause errors in the OS and backup software).
Page 66
• Drive Error LED (Amber) LED Status Device status No errors Blinking A hardware error has been detected. • Tape Error LED (Amber) LED Status Device status No errors Blinking There is a problem with the data cartridge being loaded. •...
Inserting/Ejecting the Data Cartridge Handle the data cartridge properly referring to "3 About the Data Cartridge" ( pg.71). 2.2.1 How to insert Insert the data cartridge slowly into the cartridge slot, with the arrow mark facing up and the label panel facing you.
Page 68
Manually ejecting a data cartridge Check that only the Ready LED is on, and press the eject button. If using backup software to eject the cartridge, select eject. The Ready LED will blink, and the data cartridge will be rewound and ejected. Wait until the Ready LED stops blinking before starting and other operations.
Page 69
• For Windows Backup In batch files etc., add a description that executes the following command after the backup command has been executed. rsm refresh /lf"Hewlett Packard LTO Ultrium-3 drive" rsm eject /lf"Hewlett Packard LTO Ultrium-3 drive" Example of a batch file @echo off setlocal rsm inventory /lf"Hewlett Packard LTO Ultrium-3 drive"...
Page 70
2.2.3 How to use forcible ejection when the data cartridge cannot be ejected The data cartridge can be forcibly ejected by pressing the eject button for more than 10 seconds (Forcible ejection). Only use "Forcible ejection" when the data cartridge cannot be ejected due to an error.
About the Data Cartridge This chapter explains the data cartridge used for this product. Data Cartridges that can be Used Use the following data cartridges for this product. (*1) Product name Supplier Remarks (*2) LTO Ultrium 1 Data Cartridge FUJI PHOTO FILM Co.,LTD. Storage capacity: 100GB LTO Ultrium 2 Data Cartridge FUJI PHOTO FILM Co.,LTD.
Page 72
• Do not use a data cartridge that has had a strong shock such as being dropped or falling. CAUTION • Do not use a defective media whose leader pin is detached, whose data cartridge is deformed, or which had a shock, because such defective media can damage the drive.
Page 73
3.2.3 Storing the Data Cartridge When storing the data cartridge, follow the notes below: • Make the storage area clean, and comply with the usage rules. • Put the data cartridge in the operation environment for more than 24 hours before using it. •...
Cleaning This chapter explains how to clean this product. Cleaning Head cleaning will be performed automatically when a cleaning cartridge is inserted into this product. This product uses a magnetic head to write and read data. If soiled with dust or dirt, the magnetic head does not read or write data correctly.
If a cleaning cartridge that has been used too many times is inserted, the Tape Error LED will turn on and the cleaning cartridge will be ejected in about 20 seconds. If before cleaning the CleanLED starts blinking to request cleaning, the Clean LED will stay blinking. Insert a new cleaning cartridge.
Cautions Concerning Cleaning The following 2 types of cleaning exist. • Periodical cleaning (once every three months) • Cleaning when cleaning is requested (Clean LED blinks) Periodical cleaning It is recommended to perform periodical head cleaning (every three months) as a preventive measure to prevent dust from accumulating on the head.
Cautions Concerning Backup This chapter explains the points to note about backup operations for this product. Operation Check Sheet Items that need to be checked in regards to everyday backup operations (cleaning operations, data cartridge management, device environment etc.) are listed in "Appendix A Operation Check Sheet(Installation/Operation Check)"...
Page 78
Backup performance/capacity The backup performance and backup capacity that can be used in one data cartridge varies depending on the following factors: • The conditions (attrition, dust, etc.) of the recording surface of the data cartridge to be used. • The dust and dirt condition of this product head •...
LEDs This chapter explains the status of each LED. On the front of this product there are 4 LEDs that indicate the status of this product. Ready Drive Error Tape Error Clean LEDs during self diagnostic testing When the power of this device is turned on or the device is reset a self diagnostic test is performed (lasts approx 15 sec.) If the self diagnostic test is not performed correctly the Ready LED blinks several times.
Page 80
LED Status Problem Solution This product is ready for use. None. Normal status. Ready Drive Error Tape Error Clean Normal operations (read, write) in None. Do no reset or restart. progress. Ready Drive Error Tape Error Clean The drive has reached a particular drive Restart the server.
Page 81
LED Status Problem Solution There is a problem with the cartridge that is Insert the cartridge again. If this problem being loaded or that has just been ejected. occurs again there is something wrong with Ready the cartridge. Replace the damaged Drive Error cartridge with a new data cartridge.
Troubleshooting This chapter explains the troubleshooting methods when this product is not running properly during use. If the problem is not resolved after performing the following troubleshooting, contact an office listed in "Appendix B Contact Information" ( pg.88). For details about LED status, refer "6 LEDs" ( pg.79) Problem Solution This product does not...
Page 83
Problem Solution The cartridge is not When it has been confirmed that a data cartridge cannot be ejected ejected. using normal procedures " Manually ejecting a data cartridge" ( pg.68) use the following procedures forcibly eject the data cartridge as described in "2.2.3 How to use forcible ejection when the data cartridge cannot be ejected"...
Specifications This chapter describes the specifications for this product. Specifications Item Functions and Specifications Comment Product name Tape Drive LTO3 Ultrium3 400GB Product ID PG-LT301 PGBLT301 Data memory 400GB Only read is available capacity (no (For Ultrium3 data cartridge) for Ultrium1 data compression) 200GB cartridge.
Tape Drv LTO3 Ultrium3 400GB is a precision instrument and improper daily operation (cleaning/ data cartridge management/ installation environment, etc.) will lead to troubles such as backup failure. We provide here an "Operation Check Sheet" to avoid troubles. The following items are recommended operations by Fujitsu. Classificat Check Check item Description / tasks (*) ❑...
Page 86
Classificat Check Check item Description / tasks (*) ❑ Is the commencing The data cartridge is a consumable part. Worn data date for use written cartridge will cause troubles such as tape surface on the data damage, dirty heads, many media errors, etc. To avoid cartridge? miss-backup due to worn data cartridge, replacement is (Approximate...
Page 87
Classificat Check Check item Description / tasks (*) ❑ Is the environment This product is susceptible to its installation of this product (the environment (especially dust) because the data- server if it is built in recording surface is exposed inside the device. The the server) dust- closer to the floor, the higher the dust level is in general, free?
Fax: +852-2827-4724 Address: 10/F., Lincoln House, 979 King's Road Taikoo Place, Island East, Hong Kong • Indonesia: PT. Fujitsu Systems Indonesia Offices Headquarters Tel: +62-21-570-9330 (Hunting) Fax: +62-21-573-5150 Address: Wisma Kyoei Prince 10th Floor Jl. Jend. Sudirman Kav 3-4 Jakarta, Indonesia 10220 •...
Page 89
Address: Unit 802-8th floor, Fortuna Tower Hanoi 6B Lang ha Street, Ba dinh District, Hanoi Socialist Republic of Vietnam • United States: Fujitsu Computer Systems Corporation Tel: +1-800-831-3183 Fax: +1-408-496-0575 Address: 1250 East Arques Avenue, Sunnyvale, CA USA 94088-3470 For the latest information, refer to the Fujitsu PRIMERGY website (http://primergy.fujitsu.com). Appendix B Contact Information...
