  • Page 1 ZXV10 H100 Home Gateway User Manual (Draft) Confidential ZTE CORPORATION...
  • Page 2 Copyright © 2004 ZTE Corporation All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of ZTE Corporation. ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, P.R.China Website: http://www.zte.com.cn...
  • Page 3 FAX: +86-755-26770160 Suggestions and Feedback To improve the quality of ZTE product documentation and offer better services to our customers, we hope you can give us your suggestions and comments on our documentation and fax this form to +86-755-26770160; or mail to “Marketing center 3...
  • Page 5 Thank you for choosing the wireless Local Area Network (LAN) product-ZXV10 H100 of ZTE Corporation. The ZXV10 H100 home gateway is a modular access gateway in the center of a home network. It links multiple devices through Internet connections and provides users with safe communication, entertainment and storage functions.
  • Page 6 Statement: The actual product may differ from what is described in this manual due to frequent update of ZTE products and fast development of technologies. Please contact the local ZTE office for the latest updating information of the product.

  • Page 7: Table Of Contents

    Contents 1 Introduction of the Product ........................1-1 1.1 Introduction of the Product ......................1-1 1.2 Packing List of the Product......................1-1 1.3 Features of the Product ........................1-1 1.4 Appearance of the Product ......................1-2 1.5 System Requirements........................1-4 2 System Connections ..........................
  • Page 8 4.2.5 DHCP Server ........................4-3 4.2.6 DHCP Relay ........................4-3 4.2.7 DNS Relay.......................... 4-3 4.2.8 Bridge Connection......................4-3 4.2.9 SNTP ..........................4-3 4.2.10 SNMP ..........................4-3 4.2.11 WLAN ..........................4-3 4.3 Advanced Configuration........................ 4-3 4.3.1 ADSL Mode Configuration ....................4-3 4.3.2 Firewall Configuration .......................
  • Page 9 Appendix A Radio Client Configuration....................A-3 Appendix B FAQ ............................B-3 Appendix C Technical Specification......................C-3 -iii-...

  • Page 11: Introduction Of The Product

    Thank you for choosing the wireless Local Area Network (LAN) product-ZXV10 H100 of ZTE Corporation. The ZXV10 H100 home gateway is a modular access gateway in the center of a home network. It links multiple devices through Internet connections and provides users with safe communication, entertainment and storage functions.

  • Page 12: Appearance Of The Product

    ZXV10 H100 Home Gateway User Manual (Draft) WAN side: ADSL interface: Built-in splitter, compatible with ADSL/ADSL2/2+ LAN side: Fast Ethernet port: four, RJ-45, 10/100Mbps, complies with the IEEE802.3 and IEEEE802.3u standards WLAN interface: Complies with the IEEE 802.11g/b standard, built-in antenna Blue Tooth interface: Supports Core V1.2, built-in antenna...
  • Page 13 Chapter 1 Introduction of the Product The indicators on the front panel of the ZXV10 H100 are shown below: The meanings of the indicators on the front panel of the ZXV10 H100 are show in the table below: Indicators Status...

  • Page 14: System Requirements

    Flashing Flashing according to the network traffic On the rear panel of the ZXV10 H100, are two RJ–45 LAN network interfaces, three RJ–11 interfaces, the reset button and the power supply slot. The details are shown in the table below:...
  • Page 15 Chapter 1 Introduction of the Product Internet Explorer 5.0 or later, or Netscape Communicator 4.0 or later) should be installed in.

  • Page 17: System Connections

    2 System Connections 2.1 System Application Environment The main application environment of the ZXV10 H100 home gateway is shown below: P W R W I C 0 W I C 0 E T H A C T / C H 0...

  • Page 18: Connecting The Wan (Adsl) Network Interface

    ZXV10 H100 Home Gateway User Manual (Draft) access to the network through wireless signals and adjust the antenna on the rear panel of the H100 to the ideal direction to get the effective coverage. You had better put the H100 in the center of your radio network. Generally, the higher your antenna is, the better the performance is.

  • Page 19: Client Settings

    3 Client Settings 3.1 TCP/IP Installation If your client PC is not installed with the TCP/IP protocol, please refer to the following settings: Click the <Start> button, select [Settings] and then click the [Network and Dial-up Connections] icon; Double click the [Local Connections] icon and then click the <Properties> button in the [Local Connections] tab;...

  • Page 20: Tcp/Ip Configuration

    ZXV10 H100 Home Gateway User Manual (Draft) 3.2 TCP/IP Configuration For access to the Internet through the H100, you must configure the PC in the LAN to be in the same subnet segment with the H100. The default network settings of the H100 are: the IP address of 192.168.1.1 and the subnet mask of 255.255.255.0.

  • Page 21: Configuration Inspection

    Chapter 3 Client Settings 3.3 Configuration Inspection After the above preparations, switch on the H100, and you will see that the power indicator is on. At the same time, the H100 executes the device start-up process and detects the connected devices. You can see from the indicators which devices have been connected to the H100 successfully.
  • Page 22 ZXV10 H100 Home Gateway User Manual (Draft) • Type in “ping 192.168.1.1” at the cursor position in the interface popped up and then enter. If the following information occurs: Pinging 192.168.2.1 with 32 bytes of data: Reply from 192.168.2.1: bytes=32 time=2ms TTL=64 the computer has been successfully connected to the H100;...
  • Page 23 Chapter 3 Client Settings • An error occurs in the installation. Please check the following items in turn: Whether the Ethernet cable between the H100 and your PC is correctly connected. Whether the network adapter driver on your PC is correctly installed. Whether the indicators of the LAN interface in the H100 and the network card in your PC are both on.

  • Page 25: Web Configuration

    4 WEB Configuration The H100 provide configuration tools based on the WEB interface to facilitate configuration and management through the WEB explorer. For ease of operation, you can use one cross-over or straight-through Ethernet cable to connect a PC to the Ethernet interface of the H100 in the first configuration of the H100.

  • Page 26: Basic Configuration

    ZXV10 H100 Home Gateway User Manual (Draft) 4.2 Basic Configuration Click the <Setup> button in the WEB interface to enter the basic configuration of the H100. In the basic configuration, you can configure the parameters such as LAN interface parameter, ADSL WAN connection parameter, static route and RIP...
  • Page 27 Chapter 4 WEB Configuration 4.2.2 ADSL WAN Connection Click the WAN Connection link in the left of the interface to enter the [WAN Connection] interface, where you can set ADSL-based access modes, such as Bridge, PPPoE, PPPoA and IPoA. Attention: For the PPPoE, PPPoA and IPoA connection modes, the Network Address Translation (NAT) function is activated in the H100 by default.
  • Page 28 ZXV10 H100 Home Gateway User Manual (Draft) Click the <ADD> button to switch to the WAN connection configuration interface. The following parameters are the ATM-related configuration parameters of a WAN connection: The Virtual Path Identifier is in an 8-bit area of the ATM cell head, indicating the routed virtual path of the cell.
  • Page 29 Chapter 4 WEB Configuration 4.2.2.1 Bridge (Pure Bridge) Connection Upon configuration of the ATM-related parameters, select the button in front of Bridge Config to configure the related parameters of a Bridge (pure bridge) connection. NAS Interface No. Bridge connection interface No.. The configured No. follows the character string “nas”...
  • Page 30 ZXV10 H100 Home Gateway User Manual (Draft) nas interface in the interface. 4.2.2.2 PPPoE Connection If you want to implement the PPPoE dial-up connection through the H100, a PPPoE connection must be set up. Upon configuration of the ATM-related parameters, select the button in front of PPPoE to configure the related parameters of the PPPoE connection.
  • Page 31 Chapter 4 WEB Configuration becoming idle for a period of time. The idle connection indicates that no packet is received/sent. Vale range: DIRECT/AUTO. Selection of DIRECT indicates that the PPPOE Mode connection is always on line. Selection of AUTO indicates that the functions of idle timeout and auto-redial triggered by traffic are activated.
  • Page 32 ZXV10 H100 Home Gateway User Manual (Draft) Click the <Delete> button to remove the session from the configuration file and stop it. 4.2.2.3 PPPoA Connection If you want to implement the PPPoA dial-up connection through the H100, a PPPoA connection must be set up. Upon configuration of the ATM-related parameters, select the button in front of PPPoA to configure the related parameters of the PPPoA connection.
  • Page 33 Chapter 4 WEB Configuration The PPPOA Session List shows the designated PPPOE sessions that have been created. Click the <Stop> button to stop and delete a PPPOA session. Click the <Delete> button to remove the session from the configuration file and stop it.
  • Page 34 ZXV10 H100 Home Gateway User Manual (Draft) 4.2.2.4 IPoA Connection If your ISP provides the access mode of the IPoA-based static connection, you can select the IPoA access mode. Upon configuration of the ATM-related parameters, select the button in front of IPoA to configure the related parameters of the IPoA connection.

  • Page 35: Static Route

    Chapter 4 WEB Configuration 4.2.3 Static Route Click the Routes link in the left of the interface to enter the route configuration interface of the H100. In the [Route] tab, you can configure and view the static route information of the H100. The main interface shows the static route list of the H100. You can configure a new route, modify or delete the existing routes.
  • Page 36 ZXV10 H100 Home Gateway User Manual (Draft) If you need to modify an existing route, select it in the route list. Its configuration is shown in the set box. Modify the next hop IP address and click the <Modify> button.
  • Page 37 Chapter 4 WEB Configuration To activate the RIP function on the H100, you need to configure Zebra and RIP with the <Configure Zebra> and <Configure RIP> buttons, and then activate the RIP function with the <Enable Zebra> and <Enable RIP> buttons. In the Zebra configuration interface shown below, you can configure Hostname, Password, Enable Password and interface IP address.
  • Page 38 ZXV10 H100 Home Gateway User Manual (Draft) In the RIP configuration interface shown below, you can configure Hostname, Password, Enable Password and RIP Version (RIP version No.) and the interface where the RIP is activated. 4.2.5 DHCP Server The DHCP Server List Interface shows the configuration parameters of the current DHCP server.
  • Page 39 Chapter 4 WEB Configuration In the DHCP Server Configuration Interface, you can set the configurations of the DHCP server. The interface for starting the DHCP server. Interface Starting IP Address The starting address from the IP address pool allocated by the DHCP server.
  • Page 40 ZXV10 H100 Home Gateway User Manual (Draft) 4.2.6 DHCP Relay The DHCP Relay Configuration Interface shows the status of the DHCP Relay module and the related configuration parameters. Status The current status of the DHCP Relay module. Server IP Address The IP address of the DHCP server.
  • Page 41 Chapter 4 WEB Configuration 4.2.7 DNS Relay DNS Relay Configuration Interface: DNS Server IP The DNS server IP address at the LAN side set in [Local DNS Configuration] option. Upon configuration, you should click the <Apply> button. DNS Server 1 and DNS Server 2 When the DNS relay function is configured, the IP addresses of the DNS servers should be filled in the [DNS Server 1] and [DNS Server 2] boxes.
  • Page 42 ZXV10 H100 Home Gateway User Manual (Draft) 4.2.8 Bridge Connection Click the Bridge link in the left of the interface to enter the H100 bridge configuration interface. In this interface, you can create a network bridge interface and configure its properties and the related properties of the STP protocol.
  • Page 43 Chapter 4 WEB Configuration Click the <Add> button to enter the interface for creating a network bridge interface, as shown below. In this interface, you can designate the name of the bridge interface to be created (Bridge Name), add the LAN side interface to the bridge group as a bridge interface, or configure whether to enable the STP protocol or not (STP is enabled if Spanning is Enable;...
  • Page 44 ZXV10 H100 Home Gateway User Manual (Draft) Click the [Spanning] tab in the bridge configuration interface to enter the STP parameter configuration interface, as shown below. In this interface, you can configure the Link Cost property of the member ports in the network bridge.
