- Page 1 ® Intel Blade Server Chassis SBCE: Serial Over LAN (SOL) Setup Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products Order Number: C71689-002...
- Page 2 Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability ®...
-
Page 3: Table Of Contents
Global SOL settings and status ..........4 Configuring the global SOL settings for the SBCE unit ......6 Linux configuration . - Page 4 Server Compute Blade SBX44 ....... . . 28 Mounting and unmounting media in Red Hat Enterprise Linux ES 2.1 ..28 Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
-
Page 5: Safety And Regulatory Information
Important Safety Instructions Read all caution and safety statements in this document before performing any of the instructions. See Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http:\\support.intel.com. Wichtige Sicherheitshinweise Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor... -
Page 6: General Safety
• Do not work alone under hazardous conditions, or near equipment that has hazardous voltages. • Disconnect all power before: — Performing a mechanical inspection Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... -
Page 7: Handling Electrostatic Discharge-Sensitive Devices
— Working near power supplies — Removing or installing main units • Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer to power-off the wall box (that supplies power to the machine) and to lock the wall box in the off position. •... - Page 8 3. Attach signal cables to connectors. 3. Remove signal cables from connectors. 4. Attach power cords to outlet. 4. Remove all cables from devices. 5. Turn device ON. viii Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
- Page 9 xx CAUTION: If your system has a module containing a lithium battery, replace it only with the same or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer.
- Page 10 Do not place any object weighing more than 82 kg (180 lbs.) on top of rack-mounted devices. xx CAUTION: Do not place any object weighing more then 82 kg (180lbs.) on top of rack-mounted devices. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
-
Page 11: Regulatory Specifications And Disclaimers
xx CAUTION: To avoid personal injury, before lifting the unit, remove all the blades to reduce the weight. xx CAUTION: Hazardous energy is present when the blade is connected to the power source. Always replace the blade cover before installing the blade. Regulatory specifications and disclaimers Safety compliance: USA:... -
Page 12: Electromagnetic Compatibility Notices (Usa)
Class A system. In this configuration, operation of this equipment in a residential area is likely to cause harmful interference. NOTE This product is intended to be installed with CAT5 cable, or equivalent, to minimize electrical interference. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... -
Page 13: Electromagnetic Compatibility Notices (International)
Electromagnetic compatibility notices (International) Europe (CE Declaration of Conformity): This product has been tested in accordance to, and complies with the Low Voltage Directive (73/23/EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance. Japan EMC Compatibility: English translation of the notice above: This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). - Page 14 Class A device: operated in a commercial area. Class B device: operated in a residential area. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
-
Page 15: Introduction
When this Telnet command-line interface session is running, you can start a remote-console SOL session with any blade server in the SBCE unit that is set up and enabled for SOL operation. You can establish up to 20 separate Telnet sessions with the SBCE management module, so that you can have 14 simultaneous SOL sessions active (one for each of up to 14 blade servers) with six additional command-line interface sessions available for SBCE unit management. -
Page 16: Firmware Requirements
The Firmware VPD choice identifies the firmware type, build ID, release date, and revision number for the firmware that is installed in each blade server, I/O module, and management module in the SBCE unit. The vital product data (VPD) for the firmware in the management modules also includes the file name of the firmware components. -
Page 17: General Configuration
2 General configuration This section provides instructions for configuring the SBCE unit to operate using SOL. You must perform the following configuration procedures: • Configure the SBCE for SOL operation (see “Configuring the global SOL settings for the SBCE unit” on page 6). -
Page 18: Global Sol Settings And Status
Select Serial Over LAN under Blade Tasks to view and change the global SOL settings that are used by all blade servers in the SBCE unit. Select this choice also to enable or disable SOL for each blade server. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... - Page 19 BSMP IP Address Range: This is a mandatory field where x.x.x.x is the base IP address for blade servers in the SBCE unit. The IP address that SOL uses to communicate with the blade system management processor (BSMP) of each blade server is based on the IP address that is set in this field.
-
Page 20: Configuring The Global Sol Settings For The Sbce Unit
Telnet session. Configuring the global SOL settings for the SBCE unit Complete the following steps to configure the global SOL settings for the SBCE unit: management-module Web interface (see Start the SBCE “Starting the SBCE management-module... - Page 21 Comment out the map=/boot/map line by adding a at the beginning of this line. Comment out the message=/boot/message line by adding a at the beginning of this line. image=... line: Add the following line before the first # This will allow you to only Monitor the OS boot via SOL label=linux line Add the following text to the end of the first -Monitor...
- Page 22 Pressing Tab while at this prompt will install all of the boot options that are listed. To load the operating system in interactive mode, type linux-Interact and then press Enter. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
-
Page 23: Grub Configuration
GRUB configuration If you are using GRUB, complete the following steps to modify the /boot/grub/grub.conf file: splashimage=... line by adding a # Comment out the at the beginning of this line. title=... line: Add the following line before the first # This will allow you to only Monitor the OS boot via SOL title=... - Page 24 Red Hat Enterprise Linux ES (2.4.9-e.12smp) root (hd0,0) kernel /vmlinuz-2.4.9-e.12smp ro root=/dev/hda6 initrd /initrd-2.4.9-e.12smp.img title Red Hat Enterprise Linux ES-up (2.4.9-e.12) root (hd0,0) kernel /vmlinuz-2.4.9-e.12 ro root=/dev/hda6 initrd /initrd-2.4.9-e.12.img Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
- Page 25 SOL. For some blade servers, you must also install device drivers for your Ethernet controller: ® • If you are using a Intel Server Compute Blade SBXL52, you must also install the Broadcom* NetXtreme Gigabit Ethernet Controller Device Driver for Linux Operating Systems. See “Installing the Broadcom NetXtreme Gigabit Ethernet controller device driver”...
-
Page 26: Microsoft Windows 2003 Advanced Edition Configuration
Original bootcfg program output Boot Loader Settings ---------------------------- timeout: 30 default: multi(0)disk(0)rdisk(0)partition(1)\WINDOWS Boot Entries ---------------- Boot entry ID: 1 OS Friendly Name: Windows Server 2003, Standard Path: multi(0)disk(0)rdisk(0)partition(1)\WINDOWS OS Load Options: /fastdetect Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... - Page 27 Modified bootcfg program output Boot Loader Settings ---------------------------- timeout: 30 default: multi(0)disk(0)rdisk(0)partition(1)\WINDOWS redirect: COM2 redirectbaudrate: 19200 Boot Entries ---------------- Boot entry ID: 1 OS Friendly Name: Windows Server 2003, Standard Path: multi(0)disk(0)rdisk(0)partition(1)\WINDOWS OS Load Options: /fastdetect /redirect You must reboot the Windows 2003 operating system after completing this procedure for the changes to take effect and to enable SOL.
-
Page 28: Installing And Configuring Ssh For Sol
If you have not previously installed the SSH security key file, complete the following steps: Download the security key from http://downloadfinder.intel.com, type "SSL" in the Download Search box and click on "Go!". Or, you may contact your Intel Corporation Support Representative. ®... - Page 29 Make sure that the ® For the Intel Server Compute Blade SBXL52, if the SOL Session column does not show a status of Ready, make sure that the J28 jumper on the blade server is in the correct position. See “SOL jumper...
- Page 30 Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide...
-
Page 31: Component-Specific Configuration
3 Component-specific configuration This section provides instructions for configuring SBCE components for SOL operation. Use it in addition to the information in Chapter 2, “General configuration,” on page 3. It is divided into the following subsections: • ”Configuring the management module” on page 17 ®... - Page 32 Yes to 4) Click restart the management module and end the session. You must wait approximately 10 seconds for the management module to restart before attempting start the SBCE management- module Web interface. (see Start the SBCE management-module Web interface ”Starting the SBCE management-module Web...
-
Page 33: Server Compute Blade Sbxl52
BSMP IP address range • Set the field to the base IP address for blade servers installed in the SBCE unit. Valid IP addresses are of the form x.x.x.x, where each is a number from 0 to 255. Accumulate timeout •... -
Page 34: Updating And Configuring The Bios
• : Enabled Remote Console Flow Control • : Hardware Remote Console Redirection Devices and I/O Ports Press Esc twice to exit the sections of the Configuration/Setup Utility program Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... -
Page 35: Updating The Integrated Systems Management Processor Firmware
SBXL52 ISMP to enable SOL. Attention: Do not change the SBCE media tray owner by pressing the button on the front of the blade server or through the SBCE management-module Web interface while the ISMP firmware update is in progress. This ®... -
Page 36: Updating The Broadcom* Netxtreme* Gigabit Ethernet Controller Firmware
Server Compute Blade SBXL52 has the following requirements for SOL operation: • An SOL capable Ethernet I/O module must be installed in I/O module bay 1 of the SBCE unit (see ”Hardware and firmware requirements” on page 1). ® •... -
Page 37: Updating And Configuring The Bios
Server Compute Blade SBX44 from your Intel Corporation Support Representative Update the blade server Intel Ethernet controller device drivers, following the instructions that come with the device-driver package that you downloaded. Configure the network interfaces for the operating system. See the documentation for your operating... -
Page 38: Configuring The Intel ® Blade Server Ethernet Switch Module For The Intel
Blade Server Chassis SBCE. No configuration is required on the Intel Blade Server Ethernet Switch Module to enable SOL. ® You will not be able to perform this procedure if the values for the network configuration of the Intel Blade ® Server Ethernet Switch Module for the Intel Blade Server Chassis SBCE are not within the same subnet as the SBCE management-module network interfaces (eth0 and eth1). -
Page 39: Using Sol
Telnet connection to the IP address of the management module or by establishing a Secure Shell (SSH) connection. You can establish up to 20 separate Telnet or SSH sessions to the SBCE management module, so that you can have 20 command-line interface sessions active at the same time. You can use up to 14 of these command-line sessions to run SOL sessions with the blade servers, with the remaining six sessions ®... -
Page 40: Starting A Command-Line Secure Shell (Ssh) Connection
SOL command-line interface. Serial over LAN (SOL) must be enabled for both the SBCE unit and the blade server before you can start an SOL session with the blade server. See Chapter 2, “General configuration,” on page 3 and Chapter 3, “Component-specific configuration,”... -
Page 41: Ending An Sol Session
-T system:blade[14] NOTE ® If an SOL session for the Intel Server Compute Blade SBXL52 displays only a flashing cursor in a blank screen, this indicates an interruption in the flow of serial data. Press Ctrl+q to resume serial data flow. -
Page 42: Mounting And Unmounting Media For The Intel
If the medium to be unmounted is a CD, type umount /mnt/cdrom and then press Enter. • If the medium to be unmounted is a diskette, type umount /mnt/floppy and then press Enter. Intel® Blade Server Chassis SBCE: Serial over LAN (SOL) Setup Guide... - Page 43 17 configure blade server SBX44 22 blade server SBXL52 19 global SOL settings 6 GRUB 9 Intel® Blade Server Ethernet Switch Module 24 LILO 6 management module 17 Microsoft Windows 2003 12 Red Hat Enterprise Linux 6 SSH 14...
