SRPL8 Server System Quick Start Guide Order Number: A49446-001 How to do basic set-up, boot from the configuration software CD, install the optional slide rail kit, and access the Product Guide from the CD.
Page 2
Intel. Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document.
The Server Product Guide....................20 Using the Acrobat .PDF Files..................20 Copy Configuration Software to Diskettes ................21 Warnings..........................22 WARNING: English (US) ..................23 AVERTISSEMENT: Français ..................25 WARNUNG: Deutsch....................27 AVVERTENZA: Italiano .................... 29 ADVERTENCIAS: Español ..................31 SRPL8 Server System 3...
Page 4
WARNINGS : Before operating this server, read the warnings ARNINGS beginning on page 22. : To avoid personal injury when unpacking the server, VOID INJURY use only a mechanical assist unit to lift it off the shipping pallet. The minimum server configuration weighs 51 kg (113 lbs); the maximum weighs 63.5 kg (140 lbs).
Server Specifications Table 1. SRPL8 Server Physical Specifications Specification Value Height 31.12 cm (12.25 inches, 7u) Width 44.45 cm (17.5 inches) Depth 71.12 cm (28.0 inches) Weight 51.4 kg (113 lbs) minimum configuration 63.5 kg (140 lbs) maximum configuration Required front clearance 10 inches (inlet airflow <35 °C / 95 °F)
Select Site WARNING The push-button on/off power switch on the front panel of the server does not turn off the AC power. To remove AC power from the server, you must unplug the AC power cord from the server or wall outlet. CAUTION, ESD precautions Electrostatic discharge (ESD) can damage disk drives, add-in boards, and other parts.
Optional Slide Rail Kit If the SRPL8 Server is to be rack mounted the slide rail kit should be installed as follows before proceeding. Equipment Rack Precautions WARNINGS : The equipment rack must be anchored NCHOR THE EQUIPMENT RACK to an unmovable support to prevent it from falling over when one or more servers are extended in front of it on slide assemblies.
Prepare the Slide Assemblies 1. Remove the slide assemblies from the kit. 2. Orient the slide assembly so that the arrow embossed on each rail assembly is facing toward the front of the server as shown in Figure 2. Figure 2. Slide Rail Orientation 3.
Page 9
10. Press the safety latch, and separate the bars. Set the center bar and large outer bar assembly aside to attach to the equipment rack in a later step. 11. Prepare the other slide assembly by repeating steps 2–10 above. SRPL8 Server System 9...
Attach the Rail Slide Rail Brackets to the Equipment Rack NOTE Mounting holes in the vertical rails of equipment racks are commonly spaced in a 5/8 x 5/8 x 1/2-inch sequence. Perform the following steps carefully; brackets must be mounted with precision to allow room for the next server you install in a rack.
Back right-angle extension bracket Screw C. Flat washer, lock washer, and nut D. Large outer bar Safety latch on the center bar Center bar G. Front right-angle extension bracket OM11072 Figure 7. Center Bar and Large Outer Bar Assembly SRPL8 Server System 11...
Install the Server in the Rack WARNINGS : The equipment rack must be anchored NCHOR THE EQUIPMENT RACK to an unmovable support to prevent it from falling over when one or more servers are extended in front of it on slide assemblies. The anchors must be able to withstand a force of up to 113 kg (250 lbs).
It must have certification marks showing certification by an agency acceptable in your region. • Connector, server end: The connector that plugs into the AC receptacle on the server must be an IEC 320, sheet C19, type female connector. SRPL8 Server System 13...
Page 14
• Cord length and flexibility: Cords must be less than 4.5 meters (14.76 feet) long, and must < > be flexible (harmonized ) cord or VDE-certified cordage to comply with server's safety certifications. NOTES Surge suppressor recommended: In geographic regions that are susceptible to electrical storms, we highly recommend that you plug the server into a surge suppressor.
PS/2-compatible serial ports A and B, 9-pin RS-232 connector Super VGA compatible, 15-pin video connector PS/2-compatible parallel port (LPT), 25-pin bidirectional subminiature D connector USB ports 0 and 1, 4-pin connector Interchassis Management Bus (ICMB) connectors port 1 and 2 continued SRPL8 Server System 15...
Table 2. Back Components, Controls, and Indicators (continued) Item Feature/Description Power Supplies (in this view, supplies must be populated from left to right; the right bay would contain the redundant supply) Failure LED (yellow) Predictive failure LED (yellow) for power supply fan Power LED (green) AC input power connector Turn on Video Monitor and Server...
Page 17
It adjusts the volume of headphones or speakers. Headphone jack It provides a connection for headphones or speakers. 3.5-inch Diskette (Floppy) Drive Activity LED When lit, it indicates the drive is in use. Ejector button When pressed, it ejects the diskette. SRPL8 Server System 17...
Run Power-on Self Test Each time you turn on the system, POST starts running. POST checks the carriers, processors, memory, keyboard, and most installed peripheral devices. During the memory test, POST displays the amount of memory it is able to access and test. The length of time needed to test memory depends on the amount of memory installed.
6. When POST completes, the server boots from the CD, installs a mouse driver, and displays the CD-ROM menu bar. Use the arrow keys to scroll through the menu bar and to view the tasks in the pop-up menus. SRPL8 Server System 19...
11. Make sure the CD is in the drive, and boot the server. The Server Product Guide We provide the SRPL8 Server System Product Guide file on the CD. Because printing from within Acrobat is time-consuming, we recommend printing only a small range of pages for immediate use.
2. From the CD-ROM menu bar, select Create Diskettes and press <Enter>. 3. Follow the prompts to copy the software onto the diskettes. 4. When finished, from the CD-ROM menu bar, select Quit to DOS and press <Enter>. 5. Remove the CD from the CD-ROM drive. SRPL8 Server System 21...
Attach the covers to the chassis with the screws removed earlier, and tighten them firmly. Insert and lock the padlock to the system to prevent unauthorized access inside the system. Connect all external cables and the AC power cord(s) to the system. continued SRPL8 Server System 23...
Page 24
WARNING: English (continued) A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves. Danger of explosion if the battery is incorrectly replaced.
Revissez solidement les panneaux du boîtier avec les vis retirées plus tôt. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé à l’intérieur du système. Rebranchez tous les cordons d’alimentation c. a. et câbles externes au système. suite SRPL8 Server System 25...
Page 26
AVERTISSEMENT: Français (suite) Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été sous tension. Faites également attention aux broches aiguës des cartes et aux bords tranchants du capot. Nous vous recommandons l'usage de gants de protection. Danger d'explosion si la batterie n'est pas remontée correctement.
Schrauben wieder anbringen. Ziehen Sie diese gut an. Bringen Sie die Verschlußeinrichtung (Padlock) wieder an und schließen Sie diese, um ein unerlaubtes Öffnen des Systems zu verhindern. Schließen Sie alle externen Kabel und den AC Stromanschlußstecker Ihres Systems wieder an. fortsetzung SRPL8 Server System 27...
Page 28
WARNUNG: Deutsch (fortsetzung) Der Mikroprozessor und der Kühler sind möglicherweise erhitzt, wenn das System in Betrieb ist. Außerdem können einige Platinen und Gehäuseteile scharfe Spitzen und Kanten aufweisen. Arbeiten an Platinen und Gehäuse sollten vorsichtig ausgeführt werden. Sie sollten Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr.
Attaccare le coperture al telaio con le viti tolte in precedenza e avvitarle strettamente. Inserire e chiudere a chiave il lucchetto sul retro del sistema per impedire l’accesso non autorizzato al sistema. Ricollegare tutti i cavi esterni e le prolunghe AC del sistema. continua SRPL8 Server System 29...
Page 30
AVVERTENZA: Italiano (continua) Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto.
Incorpore las tapas al chasis mediante los tornillos extraídos anteriormente, tensándolos firmemente. Inserte el bloqueo de seguridad en el sistema y bloquéelo para impedir que pueda accederse al mismo sin autorización. Conecte todos los cables externos y los cables de alimentación CA al sistema. continúa SRPL8 Server System 31...
Page 32
ADVERTENCIAS: Español (continúa) Si el sistema ha estado en funcionamiento, el microprocesador y el disipador de calor pueden estar aún calientes. También conviene tener en cuenta que en el chasis o en el tablero puede haber piezas cortantes o punzantes. Por ello, se recomienda precaución y el uso de guantes protectores.
