Related Manuals for Intel SRPM8
Summary of Contents for Intel SRPM8
- Page 1 SRPM8 Server System Quick Start Guide Order Number: A27246-001 How to do basic set-up, boot from the configuration software CD, install the optional slide rail kit, and access the Product Guide from the CD...
- Page 2 Intel. Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Using the Acrobat .PDF Files..................20 Copy Configuration Software to Diskettes ................21 Warnings ..........................22 WARNING: English (US) ..................23 AVERTISSEMENT: Français ..................25 WARNUNG: Deutsch....................27 AVVERTENZA: Italiano .................... 29 ADVERTENCIAS: Español ..................31 SRPM8 Server System Quick Start Guide 3... - Page 4 Do not attempt to lift or move the server by the handles on the power supplies. Use only a hand-truck or other mechanical assist unit to move the server from one location to another. 4 SRPM8 Server System Quick Start Guide...
-
Page 5: Server Specifications
51.4 kg (113 lbs) minimum configuration 63.5 kg (140 lbs) maximum configuration Required front clearance 10 inches (inlet airflow <35 °C / 95 °F) Required rear clearance 8 inches (no airflow restriction) OM08750 Figure 1. SRPM8 Server SRPM8 Server System Quick Start Guide 5... -
Page 6: Select Site
Access space provided so the server power cords can be unplugged from the power supply or the wall outlet; this is the only way to remove AC power from the server. • Clearance provided for cooling and airflow. 6 SRPM8 Server System Quick Start Guide... -
Page 7: Optional Slide Rail Kit
Optional Slide Rail Kit If the SRPM8 Server is to be rack mounted the slide rail kit should be installed as follows before proceeding. Equipment Rack Precautions WARNINGS : The equipment rack must be anchored NCHOR THE EQUIPMENT RACK to an unmovable support to prevent it from falling over when one or more servers are extended in front of it on slide assemblies. -
Page 8: Prepare The Slide Assemblies
(all three overlapping bars will be visible). 5. Grasp the small outer bar (attached to the server) with your right hand so that your thumb is on the safety latch of the small outer bar. 8 SRPM8 Server System Quick Start Guide... - Page 9 10. Press the safety latch, and separate the bars. Set the center bar and large outer bar assembly aside to attach to the equipment rack in a later step. 11. Prepare the other slide assembly by repeating steps 2–10 above. SRPM8 Server System Quick Start Guide 9...
-
Page 10: Attach The Rail Slide Rail Brackets To The Equipment Rack
Place a bar nut on the screw and loosely tighten it. Repeat for the marked bottom hole. 6. Install the three remaining right-angle extension brackets on the other three vertical rails by repeating steps 1–5 above. 10 SRPM8 Server System Quick Start Guide... -
Page 11: Attach The Center Bar And Large Outer Bar Assemblies To The Equipment Rack
C. Flat washer, lock washer, and nut D. Large outer bar Safety latch on the center bar Center bar G. Front right-angle extension bracket OM08047 Figure 7. Center Bar and Large Outer Bar Assembly SRPM8 Server System Quick Start Guide 11... -
Page 12: Install The Server In The Rack
3. When the server stops, press in on the safety latches on the small bars and gently slide the server into the rack. 4. Connect all external cables and the power cord to the server. 12 SRPM8 Server System Quick Start Guide... -
Page 13: Check Power Cord
Do not plug in the server power cord yet if you will be adding internal parts (boards, DIMMs, removable media drives). (For these installation procedures, see the SRPM8 Server System Product Guide.) Power Cord Requirements • Rating: Cords must be rated for available AC voltage and have a current rating at least 125% of current rating of server. -
Page 14: Connect Monitor, Keyboard, Mouse
We recommend you use the retention mechanism, but you do not NEED to. To access the retention mechanism, remove the left power supply (see Chapter 4 in the SRPM8 Server System Product Guide). For EMI information, see the Product Guide: For information about complying with electromagnetic interference regulations, see “Electromagnetic Compatibility”... - Page 15 Power Supplies (in this view, supplies must be populated from left to right; the right bay would contain the redundant supply) Failure LED (yellow) Predictive failure LED (yellow) for power supply fan Power LED (green) AC input power connector SRPM8 Server System Quick Start Guide 15...
-
Page 16: Turn On Video Monitor And Server
7. Verify that the power-on light on the front panel is lit. After a few seconds, the power-on self test (POST) begins. Handy Hint Power switch is rounded outward (convex). Reset switch is recessed (concave). D E F G K J I OM07301 Figure 10. Front Controls and Indicators 16 SRPM8 Server System Quick Start Guide... - Page 17 Headphone jack It provides a connection for headphones or speakers. 3.5-inch Diskette (Floppy) Drive Activity LED When lit, it indicates the drive is in use. Ejector button When pressed, it ejects the diskette. SRPM8 Server System Quick Start Guide 17...
-
Page 18: Run Power-On Self Test
† Also see “Using the Symbios SCSI Utility” in the SRPM8 Server System Product Guide. If you do not enter the SCSI utility, the boot process continues. 5. Press <Esc> during POST to access a boot menu when POST finishes. From this menu, you can choose the boot device or enter BIOS Setup. -
Page 19: Boot From Cd
6. When POST completes, the server boots from the CD, installs a mouse driver, and displays the CD-ROM menu bar. Use the arrow keys to scroll through the menu bar and to view the tasks in the pop-up menus. SRPM8 Server System Quick Start Guide 19... -
Page 20: Change Boot Device Priority
5. Use your mouse or the tab key to select the .PDF file for the manual. Double click the left mouse button or press an arrow key and <Enter> to view the .PDF file. 20 SRPM8 Server System Quick Start Guide... -
Page 21: Copy Configuration Software To Diskettes
3. Follow the prompts to copy the software onto the diskettes. 4. When finished, from the CD-ROM menu bar, select Quit to DOS and press <Enter>. 5. Remove the CD from the CD-ROM drive. SRPM8 Server System Quick Start Guide 21... -
Page 22: Warnings
Warnings WARNING: English AVERTISSEMENT: Français WARNUNG: Deutsch AVVERTENZA: Italiano ADVERTENCIAS: Español 22 SRPM8 Server System Quick Start Guide... -
Page 23: Warning: English (Us)
Attach the covers to the chassis with the screws removed earlier, and tighten them firmly. Insert and lock the padlock to the system to prevent unauthorized access inside the system. Connect all external cables and the AC power cord(s) to the system. continued SRPM8 Server System Quick Start Guide 23... - Page 24 • Provided with sufficient space to access the power supply cords, because they serve as the product’s main power disconnect. • Provided with sufficient space to access the server power supply cord, because it serves as the product's main power disconnect. 24 SRPM8 Server System Quick Start Guide...
-
Page 25: Avertissement: Français
Revissez solidement les panneaux du boîtier avec les vis retirées plus tôt. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé à l’intérieur du système. Rebranchez tous les cordons d’alimentation c. a. et câbles externes au système. suite SRPM8 Server System Quick Start Guide 25... - Page 26 étant le seul moyen de mettre le système hors tension). • Fourni en suffisamment d'espace pour accéder à la corde d'alimentation d'énergie de serveur, parce qu'elle sert de débranchement de la puissance principale du produit. 26 SRPM8 Server System Quick Start Guide...
-
Page 27: Warnung: Deutsch
Bringen Sie die Verschlußeinrichtung (Padlock) wieder an und schließen Sie diese, um ein unerlaubtes Öffnen des Systems zu verhindern. Schließen Sie alle externen Kabel und den AC Stromanschlußstecker Ihres Systems wieder an. fortsetzung SRPM8 Server System Quick Start Guide 27... - Page 28 • über ausreichend Platz verfügen, um Zugang zu den Netzkabeln zu gewährleisten, da der Stromanschluß des Produkts hauptsächlich über die Kabel unterbrochen wird. • Versehen mit genügendem Platz, um das Server Spg.Versorgungsteilnetzkabel zuzugreifen, weil es. 28 SRPM8 Server System Quick Start Guide...
-
Page 29: Avvertenza: Italiano
Attaccare le coperture al telaio con le viti tolte in precedenza e avvitarle strettamente. Inserire e chiudere a chiave il lucchetto sul retro del sistema per impedire l’accesso non autorizzato al sistema. Ricollegare tutti i cavi esterni e le prolunghe AC del sistema. continua SRPM8 Server System Quick Start Guide 29... - Page 30 • Dotata di spazio sufficiente ad accedere ai cavi di alimentazione, i quali rappresentano il mezzo principale di scollegamento del sistema. • Fornito di uno spazio sufficiente ad accedere al cavo di alimentazione del server, poiché si tratta del modo principale per scollegare l'alimentazione del sistema. 30 SRPM8 Server System Quick Start Guide...
-
Page 31: Advertencias: Español
Inserte el bloqueo de seguridad en el sistema y bloquéelo para impedir que pueda accederse al mismo sin autorización. Conecte todos los cables externos y los cables de alimentación CA al sistema. continúa SRPM8 Server System Quick Start Guide 31... - Page 32 • Provisto de una toma de tierra correctamente instalada. • Provisto de espacio suficiente como para acceder a los cables de alimentación, ya que éstos hacen de medio principal de desconexión del sistema. 32 SRPM8 Server System Quick Start Guide...
