Extron electronics IN1606 User Manual page 80

Output 1/2 section
Figure 49. Output 1/2 Section
1. Click the tab.
Output
2. For each output in the Output 1/2 section, click the
a limiter in the output. The button turns blue when it is enabled.
3. For each output, select a mix options radio button from the Mix Options panel.
Output 1 Output 2
Left Program Right Program
L and R L and R
Program Program
No Program No Program
4. For each output, select the
output.
5. For each output, click and drag the handle of the output sliders, or enter a value in the
field below the sliders or click the
Click the button for either slider to mute the output.
Mute
Click the button to control both sliders simultaneously.
Gang
6. Select the
Enable Meters
IN1606 and IN1608 Series Scaling Presentation Switcher • Internal Web Pages
Limiter
Output 1 and 2 Mix Options
Note
Output 1 and 2 act as a stereo pair (default).
L and R program audio are summed on each
output. They act as unique, independent outputs
with or without Mic.
No program audio. Output 1 and 2 are treated as
unique, independent outputs with or without Mic.
check box to include the mic/line mix in the
Mic/Line
or arrow button to adjust the output level.
Up Down
check box to display output meters.
button to enable or disable
74
