The EDID properties currently assigned to each input are displayed in the table of inputs.
The audio input format listed in an EDID is determined by the Audio Input Format on the
Audio Configuration page (unless a custom EDID is used).
Filtering Available EDID
Use the tab to limit the number of available EDID displayed in the Available EDIDs
Filter
and Connected Outputs section.
1. From the
Resolution
2.
From the
Refresh Rate
Assigning EDID
To assign EDID to selected inputs:
1. From the inputs group box (table of inputs) on the right, select the check boxes for the
desired inputs.
2. From the Available EDIDs or Connected Outputs section on the left, select the desired
EDID.
3. From the inputs group box, click the
or inputs.
To assign EDID to all inputs:
1.
From the Favorites (PCS only), Connected Outputs, or Available EDIDs section, select
an EDID.
2. From the inputs group box, click the
NOTE: Checked or unchecked inputs are ignored and the EDID is assigned to all
inputs.
To match the selected inputs to the current output resolution:
Matching the output resolution is the default value for all inputs.
1. From the inputs group box (table of inputs) on the right, select the check boxes for the
desired inputs.
2. In the Output Resolution panel, click the
Adding EDID to the EDID Library
1. Click the
Add EDID to Library
opens.
2.
Navigate to the desired EDID file location and select it.
NOTE: Valid EDID files have a .bin file extension.
3. Click the button. The EDID is added to the Available EDIDs section.
Open
Saving EDID to the EDID Library
1. From the Connected Outputs or Available EDIDs, right-click on an EDID.
2. Select
Save to EDID Library
3. Click the button to save the file.
OK
NOTE: Saving a factory scaler EDID exports an HDMI, LPCM-2Ch EDID to the PC. The
file is saved as a BIN file.
IN1606 and IN1608 Series Scaling Presentation Switcher • Internal Web Pages
drop-down menu, select a specific resolution or
drop-down menu, select a specific refresh rate or
button to assign EDID to the selected input
Assign
Assign to All
Match Output
button. The Browse Add EDID to Library window
.
.
Any
.
Any
button.
button.
