ERROR CODE AND SELF-DIAGNOSTIC MODE

2.1 Error Code List
The following error codes is displayed at the upper right of the screen when the "CLEAR PAPER" or
"CALL SERVICE" symbol is blinking.
2.1.1 Jam
Error code Classification
E010 Paper exit jam
E020
E030 Other paper jam
E061
E062
E063
E064
E065
E090
E110 Paper misfeeding
E120
E130
E140
© 2005 - 2007 TOSHIBA TEC CORPORATION All rights reserved
Contents
Paper not reaching fuser transport sensor: Paper
which has passed the fuser unit does not reach the
fuser transport sensor.
Paper stopping at fuser transport sensor: The trail-
ing edge of paper does not pass the fuser transport
sensor after its leading edge has reached the fuser
transport sensor.
Power-ON jam: Paper is remaining on the paper
transport path of the equipment when the power is
turned ON.
Incorrect paper size setting for 1st drawer: The size
of paper in the 1st drawer differs from size setting of
the equipment.
Incorrect paper size setting for 2nd drawer: The
size of paper in the 2nd drawer differs from size set-
ting of the equipment.
Incorrect paper size setting for 3rd drawer: The size
of paper in the 3rd drawer differs from size setting
of the equipment.
Incorrect paper size setting for 4th drawer: The size
of paper in the 4th drawer differs from size setting of
the equipment.
Incorrect paper size setting for bypass tray: The
size of paper in the bypass tray differs from size
setting of the equipment.
Image data delay jam: Image data to be printed
cannot be prepared.
Transport jam during duplex printing (paper not
reaching registration sensor): Paper which passed
the reverse transport section does not reach the
registration sensor during duplex printing.
Bypass misfeeding (paper not reaching registration
sensor): Paper fed out of the bypass tray does not
reach the registration sensor.
1st drawer misfeeding (paper not reaching 1st
drawer feed sensor): Paper does not reach the 1st
drawer feed sensor during the feeding at the 1st
drawer.
2nd drawer misfeeding (paper not reaching 2nd
drawer feed sensor): Paper does not reach the 2nd
drawer feed sensor during the feeding at the 2nd
drawer.
2 - 1
Troubleshooting
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.1
Ch.5.1.2
Ch.5.1.2
Ch.5.1.2
Ch.5.1.2
e-STUDIO520/523/600/603/720/723/850/853
