CAUTION:
The heatsink thermal interface media is not reusable and must be replaced if the heatsink is removed
from the processor after it has been installed.
IMPORTANT:
Processor socket 1 must be populated at all times or the node does not function.
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis .
4. Place the node on a flat, level surface.
5. In a 2U node, do one of the following:
• Remove the three-slot PCI riser cage assembly.
• Remove the FlexibleLOM 2U node PCI riser cage assembly.
6. Remove the air baffle.
7. Remove the heatsink.
To replace the component:
1. Clean the old thermal grease from the processor with the alcohol swab. Allow the alcohol to evaporate
before continuing.
2. Remove the thermal interface protective cover from the heatsink.
