Chassis rear panel components

Four 1U nodes
Item Description
1 Node 4
2 Node 3
3 RCM module (optional)
4 Power supply 2
5 Power supply 1
6 Node 2
7 Node 1
Two 2U nodes
Item Description
1 Node 3
2 RCM module (optional)
3 Power supply 2
4 Power supply 1
5 Node 1
