Item Description
c) HPE 800W Flex Slot Universal Hot Plug Power Supply Kit –
94% efficiency*
d) HPE 800W Flex Slot Titanium Hot Plug Power Supply Kit –
96% efficiency*
e) HPE 800W Flex Slot -48VDC Hot Plug Power Supply Kit –
94% efficiency*
6 RCM module
7 Right bezel ear
8 PDB pass-through board assembly
9 PDB pass-through board*
10 Power distribution board
11 RPS link board assembly
12 RPS link board*
13 24 SFF backplane for Apollo r2600 Chassis
14 Storage expander backplane (Apollo r2800 Chassis drive
backplane)
15 Storage expander card (for Apollo r2800 Chassis only)
16 24 SFF drive cage
17 Left bezel ear
18 Fan power cable assembly*
19 Chassis cable kit
a) RCM 2.0 cable*
b) PDB pass-through cable*
c) Left front I/O cable* for HPE Apollo r2600/r2800 Chassis
d) Front I/O cables *
e) RCM 2.0 to 1.0 adapter cable*
20 12 LFF Apollo r2200 Chassis*
21 24 SFF Apollo r2600 Chassis*
22 24 SFF Apollo r2800 Chassis*
*Not shown
1
Mandatory—Parts for which customer self repair is mandatory. If you request Hewlett Packard Enterprise to
replace these parts, you will be charged for the travel and labor costs of this service.
2
Optional—Parts for which customer self repair is optional. These parts are also designed for customer self
repair. If, however, you require that Hewlett Packard Enterprise replace them for you, there may or may not be
additional charges, depending on the type of warranty service designated for your product.
Spare part Customer self
number repair
754379-001 Mandatory
754378-001 Mandatory
754382-001 Mandatory
800361-001 Mandatory
— —
— —
3
800356-001 No
3
800355-001 No
— —
800375-001 Optional
3
800358-001 No
3
800359-001 No
3
800360-001 No
— —
808850-001 Optional
808848-001 Mandatory
811569-001 —
3
— No
— Mandatory
— Mandatory
— Mandatory
— Mandatory
841639-001 Optional
841640-001 Optional
841641-001 Optional
Illustrated parts catalog
1
1
1
1
2
2
1
1
1
1
1
2
2
2
