CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless all PCI riser cages
or rear I/O blanks are installed, and do not operate the node unless all PCI slots have either an
expansion slot cover or an expansion board installed.

Single-slot 2U node PCI riser cage assembly

Procedure
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis.
4. Place the node on a flat, level surface.
5. Remove the FlexibleLOM 2U node riser cage assembly.
6. Remove the single-slot 2U node PCI riser cage assembly.
50 Single-slot 2U node PCI riser cage assembly
