Remove the PCI riser cage assembly

WARNING:
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system
components to cool before touching them.
CAUTION:
To prevent damage to the server or expansion boards, power down the server, and disconnect all power
cords before removing or installing the PCI riser cage.

Single-slot left PCI riser cage assembly

Procedure
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis .
4. Place the node on a flat, level surface.
5. In a 2U node, remove the three-slot riser cage assembly.
6. Remove the single-slot left PCI riser cage assembly:
• 1U node
Remove the PCI riser cage assembly 47
