When you make any of the following menu selections:
The modem directs you to a common ODU SELECT submenu:
ODU SELECT: Config
Monitor
See Sect. 10.2.1.2.1.1.1 for details about this common submenu.
(ODU: Transceiver Control) Enable ► Standalone
ODU SELECT: Config
Monitor Alarms (
Use the ◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
The selections for this common submenu branch are defined in detail in Sect. .
(ODU: Transceiver Control) Enable ►1:1
Monitor/Control:
CSAT#2 Red-Box (
For monitor/control of a redundant CSAT-5060 system: Use the ◄ ► arrow keys to select
CSAT#1, CSAT#2, or Red-Box, and then press ENTER.
(ODU: Transceiver Control) Enable ►1:1 ► CSAT#1 or CSAT#2
ODU SELECT: Config
Monitor
Use the ◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
The selections for this common submenu branch are defined in detail in Sect. K.3.3.1.1.1.1.
(ODU: Transceiver Control) Enable ►1:1 ► Red-Box
Redundancy Box:
Mode Switches
Use the ◄ ► arrow keys to select Online, Mode, Switches, or Voltages, and then press
ENTER.
(ODU: Transceiver Control) Enable ►1:1 ► Redundancy Box ►
Online
Online Unit:
CSAT#1
This display indicates the ODU currently online. The cursor will be flashing under
CSAT#1 or CSAT#2. If the need arises to change the Online unit, use the ◄ ► arrow
keys to move the cursor position to the desired unit, and then press ENTER.
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
(ODU Transceiver Control) Enable ►Standalone
(ODU Transceiver Control) Enable ► 1:1 ► CSAT#1
(ODU Transceiver Control) Enable ► 1:1 ► CSAT#2
Alarms (◄ ►,ENT)
Info
◄ ►
,ENT)
CSAT#1
◄ ►,
ENT)
Info
◄ ►
Alarms ( ,ENT)
Online
Voltages
CSAT#2 (◄ ►,ENT)
Info
