7.4.3.3.5 Configuration | Managed Switch
1. This page is available only to Admin users and when you install the optional
Packet Processor.
2. If you submit any changes to this page, you must also open the 'Admin | Pap
Save' page (see Sect. 7.4.3.2.8) and immediately click [Save PaP
Parameters].
Managed Switch Mode is primarily intended for operation in a point-to-point topology. It supports
VLAN as well as advanced features such as QoS, Header Compression, and Payload
Compression.
Managed Switch Configuration
•
Tx Payload Compression, or L3/L4/L5 Tx Header Compression – When these
features are available, use the drop-down lists to select operation as Disabled,
Enabled, or Per Route.
3xDES Encryption is a future offering and is not available in this firmware
release. This drop-down list is therefore non-functional at this time.
Click [Submit] to save.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page
before proceeding further.
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Figure 7-23. Configuration | Managed Switch Page
