Do these steps:
1. Use Command-line to transfer (FTP) the files from the User PC to the CDM-570A/570AL:
a. Type "ftp xxx.xxx.xxx.xxx" (where 'xxx.xxx.xxx.xxx' is the CDM-570A/570AL
Ethernet Traffic/Management IP Address).
b. The Admin User Name and Password when prompted. The default User Name and
Password is "comtech".
c. Type "bin" to set the binary transfer mode.
d. Type "prompt" and then "hash" to facilitate the file upload.
•
For either option, it will take several minutes to transfer the file and update the
firmware image.
e. Once the file transfers, Command-line displays the upload result, similar to:
ftp: XXXXXXX bytes sent in XX.XXSeconds XXX.XXXKbytes/sec.
f. Once the FTP upload is complete, as the upgrade process continues, the modem
front panel displays:
The process sequences through several blocks – this will take several minutes. Once
the update process is complete, the modem returns you to the previously active
menu screen.
g. Type "bye" to terminate the FTP session, and then close the Command-line window.
2. Use the modem front panel menus, the CDM-570A HTTP Interface 'Admin | Firmware |
Modem' page, or issue the Serial Remote Interface <0/SWR? or <0/FRW? query, as
shown previously, to verify that the PC-to-Modem FTP file transfer was successful.
Updating Firmware
CDM-570A/570AL Satellite Modem with Optional Packet Processor
To begin the file transfer, transfer file FW-0020683*_#.#.#.bin (where '*' is the
revision letter and '#.#.#' is the version number):
If the Packet Processor is not installed:
o
Type "put FW-0020683*_#.#.#.bin a:\bulk.bin:" to begin the file transfers –
the destination "a:\bulk.bin" must be all lower case.
If the Packet Processor is installed:
o
Type "put FW-0020683*_#.#.#.bin" (make sure you do not type the
destination "a:\bulk.bin" as was done for the previous upload option).
In the event you receive the "Connection closed by remote host."
message, wait another minute before continuing. The firmware upload
sometimes takes longer than the FTP client allows.
UPGRADING FIRMWARE
Please Wait...
