Example Programs
Example 14
Example 15
90
ASCII Unit Program:
10 OPEN #2,"SCRN:(40)"
20 PC READ "@R,10,1,B0";R
30 IF R = 0 THEN RS$ = "OFF"
ELSE RS$ = "ON"
40 PRINT #2,"RELAY = ";RS$
Remarks:
The PC READ "@..." statement is used with "@R" as the first argument di-
recting the read statement to obtain the data from the PC Relay memory
area.
Purpose: To input data from a bar code reader using the PC WRITE state-
ment
Remarks: Connect the bar code reader to port 2.
The following figure defines the output format of the bar code reader.
STX Data 1 Data 2
PC Program:
DM000 Data 1
DM001 Data 3
DM002 Data 5
DM003 Data 7
DM004 Data 9
ASCII Unit Program :
10 OPEN #2,"COMU:(22)"
20 A$ = INPUT$ (1,#2)
30 IF A$ = CHR$(2) GOTO 50
40 GOTO 20
50 B$ = INPUT$(11,#2)
60 IF CHR$(3) = RIGHT$ (B$,1)
THEN B$ = MID$(B$,1,10)
ELSE GOTO 20
70 PC WRITE "@D,0,5,5A3";B$
80 GOTO 20
Note For details on the COMU statement, refer to the description of the OPEN
statement in Section 4-2-4 Device Control Statements.
Purpose: To read data from an input file through a com port
• This example does not require a PC data transfer routine.
ASCII Unit Program
10 CLEAR 1000
100 OPEN #1,"COMU:"
Data 3 Data 4 Data 5 Data 6
Data 2
Data 4
Data 6
Data 8
Data 10
Section 6-1
Data 7 Data 8 Data 9 Data 10 ETX
