202 SAFETY
3. After driving the vehicle for up to 20 minutes above
15.5 mph (25 km/h) the "TPMS Telltale Light" will turn
OFF, as long as no tire pressure is below the low-
pressure warning limit in any of the four active road
tires.
4. The instrument cluster will display a graphic showing
the tire pressure value in the same color as the other
pressure values in place of the different color low tire
pressure value. The instrument cluster will also display
a "SPARE LOW PRESSURE" message to remind you to
service the flat tire.
Vehicles With Compact Spare or Non-Matching Full Size
Spare
1. The compact spare tire or non-matching full size does not
have a tire pressure monitoring sensor. Therefore, the TPMS
will not monitor the pressure in the compact spare tire.
2. If you install the compact or non-matching full size
spare tire in place of a road tire that has a pressure below
the low-pressure warning limit, upon the next ignition
key cycle, the "TPMS Telltale Light" will remain on and
a chime will sound. In addition, the graphic in the
instrument cluster will still display a different color
pressure value and an Inflate to XX message.
3. After driving the vehicle for up to 20 minutes above
15.5 mph (25 km/h), the "TPMS Telltale Light" will flash
on and off for 75 seconds and then remain on solid. In
addition, the instrument cluster will display a "SER-
VICE TPM SYSTEM" message for five seconds and then
display dashes (- -) in place of the pressure value.
4. For each subsequent ignition key cycle, a chime will
sound, the "TPMS Telltale Light" will flash on and off
for 75 seconds and then remain on solid, and the
instrument cluster will display a "SERVICE TPM SYS-
TEM" message for five seconds and then display dashes
(- -) in place of the pressure value.
5. Once you repair or replace the original road tire and
reinstall it on the vehicle in place of the compact spare or
non-matching full size, the TPMS will update automati-
cally. In addition, the "TPMS Telltale Light" will turn off
and the graphic in the instrument cluster will display a
new pressure value instead of dashes (- -), as long as no
tire pressure is below the low-pressure warning limit in
any of the four active road tires. The vehicle may need to
be driven for up to 20 minutes above 15.5 mph
(25 km/h) in order for the TPMS to receive this infor-
mation.
