Page 1: Service Manual
MX71x, MX81x, XM51xx & XM71xx Machine Type 7463-0xx, -2xx, -4xx, -6xx, -8xx Service Manual • Start diagnostics • Maintenance • Safety and notices • Trademarks • Index August 27, 2014 www.lexmark.com P/N 12G3100...
Page 2: August
August 27, 2014 The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Page 3: Table Of Contents
7463 Table of contents Product information..................2 Edition notice....................2 Notices and safety information..............29 Laser notices............................29 Safety information...........................32 Preface.......................37 Service manual conventions........................37 Change history............................37 General information...................47 Media guidelines.............................47 Paper guidelines ...............................47 Paper characteristics ............................47 Selecting paper.............................48 Selecting preprinted forms and letterhead....................49 Storing paper..............................49 Using recycled paper and other office papers ....................49 Using specialty media ............................51 Tips on using card stock ..........................51...
Page 4 7463 Initial print quality check ..........................61 Gray background check ............................61 Horizontal voids check ............................62 Print irregularities check ...........................63 Blank pages check.............................64 Solid black pages check.............................65 Shadow images check ............................66 Skewed print check............................67 Streaked horizontal lines check ........................68 Streaked vertical lines check..........................70 Toner specks check ............................70 Vertical voids check ............................71 Toner fog or background shading check......................72...
Page 5 7463 [x]‑page jam, open upper and lower rear door. [231–234] ...............102 [x]‑page jam, remove tray 1 to clear duplex. [235–239]................104 23y paper jam messages ..........................104 Sensor (duplex path) static jam service check....................105 Sensor (duplex path) never‑ or late‑arriving jam service check..............106 Sensor (duplex path) early arriving jam service check ................107 Sensor (duplex path) late leaving jam service check..................107 Duplex control jam service check.......................108...
Page 6 7463 29y paper jams ...............................156 29y paper jam messages ..........................156 ADF cover open jam ...........................156 Sensor (multifeed detect) detected multiple sheets service check ............157 431 paper jams ...............................158 [x]‑page jam, open mailbox rear door. Leave paper in bin. [43y.xx]............158 431 paper jam messages ..........................159 Sensor (mailbox pass through) jam service check..................160 Mailbox main motor jam service check......................162 Mailbox diverter jam service check......................163...
Page 7 7463 HPU communication error jam service check ....................212 Sensor (HPU media align) jam service check....................213 Sensor (HPU trailing edge) jam service check ....................214 Sensor (HPU leading edge) jam service check....................216 Understanding the printer messages....................217 Cartridge low [88.xy]............................217 Cartridge nearly low [88.xy]..........................217 Cartridge very low, [x] estimated pages remain [88.xy] .................217 Change [paper source] to [custom string] load [orientation] .................217 Change [paper source] to [custom type name] load [orientation]..............
Page 8 Memory full, cannot send faxes ........................227 No analog phone line connected to modem, fax is disabled................227 Network [x] software error [54] ........................227 Non‑Lexmark [supply type], see User’s Guide [33.xy] ..................228 Not enough free space in flash memory for resources [52] ................228 Paper changes needed............................228 Parallel port [x] disabled [56]..........................228...
Page 9 7463 Replace roller kit [81.xx] ..........................232 Replace separator pad ............................232 Replace unsupported cartridge [32.xy] ......................233 Replace unsupported imaging unit [32.xy] .....................233 Replace wiper ..............................233 Restore held jobs? ............................233 Scan document too long ..........................233 Scanner automatic feeder cover open ......................233 Scanner disabled by admin [840.01].......................233 Scanner disabled.
Page 10 7463 Fuser drive motor service check.........................248 121 errors ...............................248 121 error messages ............................248 Fuser service check.............................250 126 errors ...............................250 126 error messages ............................250 LVPS failure service check ..........................251 13y errors................................251 13y error messages ............................251 Toner level sensing service check.......................252 14y errors................................252 14y error messages ............................252 Main drive motor service check .........................253 Media feeder service check........................253...
Page 11 7463 98y error messages ............................271 99y errors................................271 99y error messages ............................271 Base printer symptoms...........................271 Network service check............................272 Dead machine service check...........................274 Blank display, five beeps service check......................275 ADF/Scanner hardware errors.......................276 8yy error messages ............................276 Flatbed scanner and ADF communications failure service check ..............276 Flatbed scanner home position error service check ..................277 ADF elevator tray home position error service check..................278 ADF elevator tray motor stalled error service check ..................279...
Page 12 7463 Option tray symptoms ............................304 250/550-sheet media type error service check ....................305 250/550-sheet tray undetected service check ....................307 250/550-sheet option undetected service check ...................308 HCIT incorrect media error service check .......................308 HCIT media type error service check ......................310 HCIT undetected service check........................312 HCIT media low undetected service check .....................314 Mailbox incorrect bin exit service check......................316 Mailbox undetected service check .........................317...
Page 13 7463 Top Margin ..............................342 Sensor Test ..............................342 Motor Test..............................343 Duplex Feed 1.............................343 Duplex Feed 2.............................343 INPUT TRAY TESTS ............................344 Feed Tests ..............................344 Sensor Tests ...............................344 OUTPUT BIN TESTS ............................345 Feed Tests ..............................345 Feed To All Bins ............................345 Sensor Test ..............................345 Diverter Test...............................346 FINISHER TESTS ...............................346 Staple Test ..............................346...
Page 14 7463 Display Log ..............................353 Print Log ..............................354 Clear Log..............................354 Print Log Summary .............................354 Exit Diags.................................354 SCANNER TESTS ..............................355 Back Side Scan Uniformity..........................355 ASIC Test..............................355 Motor Tests ..............................355 Feed Test ..............................355 Sensor Test ..............................356 Scanner Calibration Reset ..........................356 ADF Magnification and Flatbed Magnification...................356 Configuration menu..........................356 Entering the Configuration menu ........................356 Roller Kit Counter Value..........................357...
Page 15 7463 Require Standby..............................365 A5 Loading ..............................365 UI Automation ..............................366 LES Applications ..............................366 Key Repeat Initial Delay ..........................366 Key Repeat Rate..............................367 Clear Supply Usage History ..........................367 Clear Custom Status............................367 USB Speed...............................367 Automatically Display Error Screens .......................368 USB PnP ................................368 Restore factory defaults ..........................368 Restore Settings ............................368 Erase Printer Memory ..........................368 Erase Hard Disk............................369...
Page 16 Column right outer cover removal........................437 Right cover removal (MX71x) .........................438 Right cover removal (MX81x) .........................439 Right inner cover removal (MX71x) ........................440 Control panel speaker and speaker bracket removal (MX71x)...............441 Cartridge cooling fan removal ........................442 Duplex cooling fan removal ..........................443 HVPS removal ..............................444 LVPS removal ..............................445...
Page 17 Control panel board and display removal (MX81x) ..................502 Control panel front cover removal .........................510 Control panel latch removal ...........................512 Control panel left bezel removal (MX71x) ......................513 Control panel right bezel removal (MX71x)....................515 Left control panel hinge removal........................516 Right control panel hinge removal........................519 Tilting display removal (7‑inch and 10‑inch)....................522...
Page 18 Top cover removal ............................561 Cartridge door removal ..........................561 Output bin sensor cover removal ........................564 Sensor (standard bin full) removal .........................564 Standard bin cover removal (MX71x) ......................565 Standard bin cover removal (MX81x) ......................567 Upper redrive motor removal.........................569 Upper redrive removal............................571 ADF/scanner removals..........................572 ADF/scanner assembly removal ........................572...
Page 19 7463 ADF rear side drive parts pack removal .....................600 ADF right hinge removal..........................600 ADF separation guide removal ........................601 ADF separator roller removal........................602 Sensor (ADF 1st scan) removal........................604 Sensor (ADF elevator tray home position) removal ...................605 Sensor (ADF lower door interlock) removal ....................606 Sensor (ADF top door interlock) removal....................607 ADF tray lift drive removal .........................608 Bin extension removal..........................612...
Page 20 7463 Drawer media feeder removal ........................656 Drawer transport motor removal ........................658 Sensor (drawer pass through) removal ......................659 Sensor (pick) removal .............................661 High capacity input tray option removals (MX710 and MX711)............664 High capacity input tray option removal ......................664 HCIT removal ..............................665 HCIT drawer assembly removal ........................665 HCIT separator roller assembly removal......................666 HCIT media guide removal..........................667...
Page 21 7463 HCIT media guide removal..........................706 HCIT front cover removal..........................707 HCIT pick arm assembly removal ........................708 HCIT drawer assembly rear cover removal.....................709 HCIT drawer assembly left cover removal ......................709 HCIT drawer assembly right cover removal ....................710 HCIT controller board removal ........................711 HCIT top cover assembly removal ........................712 HCIT lift drive motor removal .........................714 HCIT drawer assembly interface cable removal .....................716...
Page 22 7463 Media pusher assembly removal........................765 Stapler/offset stacker feed roll removal......................765 Stapler/offset stacker chute assembly removal .....................767 Sensor (stapler/stacker pass through) removal....................770 Stapler/offset stacker ejector motor assembly removal ................771 Sensor (stapler/stacker ejector HP) removal....................774 Sensor (media pusher HP) removal ........................777 Sensor (stapler/stacker diverter plunger HP) removal ...................779 Stapler-unique FRU removals .........................782 Stapler right cover removal........................782 Stapler cartridge access door removal .......................784...
Page 23 7463 Stapler cartridge access door removal ......................841 Hole punch box removal..........................841 Staple, hole punch left cover removal ......................842 Staple, hole punch right cover removal......................843 Sensor (cartridge door interlock) removal......................845 Stapler door close limit switch removal......................846 Stapler carriage assembly removal.........................848 Sensor (throat media present) removal ......................849 Staple, hole punch latch removal ........................851 Stapler controller board removal ........................851 Stapler main motor removal...........................852...
Page 24 Assembly 14: ADF covers........................941 Assembly 15: ADF mechanical.......................943 Assembly 16: ADF electronics.......................945 Assembly 17: Flatbed scanner (MX71x and XM51xx)................949 Assembly 18: Flatbed scanner (MX81x and XM71xx)................953 Assembly 19: Input options (MX71x and XM51xx)................955 Assembly 20: Input options (MX81x and XM71xx)................957...
Page 25 Assembly 22: 550-sheet tray option (MX71x and XM51xx)..............961 Assembly 23: 550-sheet tray option (MX81x and XM71xx)..............963 Assembly 24: High capacity input tray option 1 (MX71x and XM51xx)..........965 Assembly 25: High capacity input tray option 2 (MX71x and XM51xx)..........967 Assembly 26: High capacity input tray option 3 (MX81x and XM71xx)..........969 Assembly 27: High capacity input tray option 4 (MX81x and XM71xx)..........971...
Page 26 7463 Input options supported........................1015 Output options supported........................1015 Physical specifications (options)......................1015 Appendix C: Theory of operation............1017 Models MX81x and MX71x paper path rollers and sensors..............1017 Models MX81x and MX71x sensors....................1018 Functions of main components......................1018 Media tray..............................1018 Rear media guide ............................1019 Side media guide............................1019 Media tray............................1019...
Page 27 7463 Main cooling fan ............................1029 Cartridge cooling fan.............................1030 Duplex cooling fan ............................1030 LVPS board assembly ............................1030 HVPS board assembly ...........................1030 Controller board ............................1030 Xerographic and print cartridge components..................1030 Document scanning at ADF.........................1034 Document scanning at platen......................1035 Names and functions of components....................1036 Flatbed scanner ............................1036 ADF components ............................1038 Output options theory.........................1041...
Page 28 7463 Table of contents...
Page 29: Notices And Safety Information
7463 Notices and safety information Laser notices Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1. Class I laser products are not considered to be hazardous.
Page 30 7463 Aviso de láser Esta impresora se ha certificado en EE. UU. de conformidad con los requisitos de DHHS 21 CFR, capítulo I, subcapítulo J, para los productos láser de Clase I (1), y en otros países está certificada como un producto láser de Clase I de acuerdo con los requisitos de IEC 60825-1.
Page 31 7463 Luokan I lasertuotteita ei pidetä haitallisina. Tulostimen sisällä on luokan IIIb (3b) laser, joka on nimellisteholtaan 10 mW:n galliumarsenidilaser ja toimii 787–800 nanometrin aallonpituuksilla. Laserjärjestelmä ja tulostin ovat rakenteeltaan sellaisia, että käyttäjä ei joudu alttiiksi luokkaa 1 suuremmalle säteilylle normaalin käytön, ylläpidon tai huollon aikana.
Page 32: Safety Information
7463 Class I 레이저 제품은 위험한 제품으로 간주되지 않습니다. 프린터에는 655-675 나노미터의 파장 영역에서 작동 하는 공칭 7 밀리와트 갈륨 비소 레이저인 클래스 IIIb(3b) 레이저가 내부에 포함되어 있습니다. 레이저 시스템 과 프린터는 정상적인 작동, 사용자 유지 관리 또는 사전 설명된 서비스 조건에는 사람에게 클래스 I 수준 이상 의...
Page 33 7463 AVERTISSEMENT—RISQUE DE BLESSURE La batterie lithium de ce produit n'est pas destinée à être remplacée. Il existe un risque d'explosion si une batterie lithium est placée de façon incorrecte. Ne rechargez pas, ne démontez pas et n’incinérez pas une batterie lithium.
Page 34 7463 Informações de Segurança • A segurança deste produto baseia-se em testes e aprovações do modelo original e de componentes específicos. O fabricante não é responsável pela segunrança, no caso de uso de peças de substituição não autorizadas. • As informações de segurança relativas a este produto destinam-se a profissionais destes serviços e não devem ser utilizadas por outras pessoas.
Page 35 7463 当心一可能的伤害：本产品中的锂电池不可更换。如果不正确更换锂电池，可能会有爆炸危险。不要再充电、拆解或焚烧锂电池。丢弃旧的锂电池时应按照制造商的指导及当地法规进行处理。 Notices and safety information...
Page 36 7463...
Page 37: Preface
7463 Preface This manual contains maintenance procedures for service personnel. It is divided into the following chapters: • General information contains a general description of the printer. Special tools and test equipment are discussed. • Diagnostic information contains diagnostic aids you can use to isolate failing FRUs. These diagnostic aids include error code tables, symptom tables, and service checks.
Page 38 7463 August 13, 2014 • Blank display and noise (five beeps) symptoms were added. Blank display, five beeps service check topic was added to address the symptoms. • New error codes were added (126.06, 126.24, and 201.22). • LVPS service check was revised. •...
Page 39 Control panel board and display removal (MX711) – Control panel board and display removal (MX81x) • Split the former Assembly 9: Control panel (MX71x and XM51xx) in the parts catalog into two assemblies: – Control panel (MX710 and XM5163) –...
Page 40 7463 – 40X8256—Stapler diverter motor – 40X8722—Stapler diverter plunger assembly – 40X8744—Stapler tray link assembly – 40X7592—Sensor (stapler diverter plunger HP) – 40X7592—Sensor (paddle motor HP) – 40X8741—Stapler drive gear assembly – 40X7592—Sensor (stapler rear door interlock) – 40X8742—Stapler tray spring –...
Page 41 7463 – Sensor (throat media present) jam service check – Finisher (HPU) diverter jam service check – Finisher (HPU) left tamper jam service check – Finisher (HPU) right tamper jam service check – Finisher (HPU) tray holder jam service check –...
Page 42 7463 – Staple, hole punch left cover removal – Staple, hole punch right cover removal – Sensor (cartridge door interlock) removal – Stapler door close limit switch removal – Stapler carriage assembly removal – Sensor (throat media present) removal – Staple, hole punch latch removal –...
Page 43 7463 – Option tray symptoms – Sensor (mailbox pass through) jam service check – Mailbox diverter jam service check – Sensor (finisher pass through) jam service check – Finisher left tamper jam service check – Finisher right tamper jam service check –...
Page 44 7463 – Sensor (left tamper motor HP) removal – Tamper assembly removal – Stapler/offset stacker output bin LED removal – Stapler/offset stacker main motor removal – Stapler/offset stacker diverter motor removal – Stapler/offset stacker diverter plunger assembly removal – Stapler/offset stacker drive gear assembly removal –...
Page 45 – Control panel latch removal – Assembly 2: Covers (MX81x) – Assembly 8: Frame Assembly – Assembly 9: Control panel (MX71x) – Assembly 10: Control panel 10inch display (MX81x) – Assembly 11: Paper tray – Assembly 15: ADF electronics –...
Page 46 – Control panel latch removal – Assembly 2: Covers (MX81x) – Assembly 8: Frame Assembly – Assembly 9: Control panel (MX71x) – Assembly 10: Control panel 10inch display (MX81x) – Assembly 11: Paper tray – Assembly 15: ADF electronics –...
Page 47: General Information
General information The Lexmark MX71x and MX81x are network‑capable, multi‑function laser printers that print monochrome print jobs. The operator panel is touch‑sensitive and lets the user adjust the viewing angle. All information in this service manual pertains to all models unless explicitly noted.
Page 48: Selecting Paper
7463 Weight The printer trays and multipurpose feeder can automatically feed paper weights between 60–176 g/m (16–47‑lb) grain long paper. The 2100‑sheet tray can automatically feed paper weights up to 60–135 g/m (16–36‑lb) grain long paper. Paper lighter than 60 g/m (16 lb) might not be stiff enough to feed properly, and may cause jams.
Page 49: Selecting Preprinted Forms And Letterhead
(electrophotographic) printers. While no blanket statement can be made that all recycled paper will feed well, Lexmark consistently tests papers that represent recycled cut size copier papers available on the global market. This scientific testing is conducted with rigor and discipline.
Page 50 Lexmark concerns itself with the responsible use of paper in general based on life cycle assessments of its products. To gain a better understanding of the impact of printers on the environment, the company commissioned a number of life cycle assessments and found that paper was identified as the primary contributor (up to 80%) of carbon emissions caused throughout the entire life of a device (from design to end-of-life).
Page 51: Using Specialty Media
7463 Using specialty media Tips on using card stock Card stock is heavy, single‑ply specialty media. Many of its variable characteristics, such as moisture content, thickness, and texture, can significantly affect print quality. • From the printer control panel, set the paper size, type, texture, and weight in the Paper menu to match the card stock loaded in the tray.
Page 52: Tips On Using Letterhead
7463 • For more information on label printing, characteristics, and design, see the Card Stock & Label Guide at http://support.lexmark.com. • Use labels designed specifically for laser printers. • Do not use labels with slick backing material. • Use full label sheets. Partial sheets may cause labels to peel off during printing, resulting in a jam. Partial sheets also contaminate the printer and the cartridge with adhesive, and could void the printer and toner cartridge warranties.
Page 53: Supported Paper Sizes, Types, And Weights
7463 Supported paper sizes, types, and weights The following tables provide information on standard and optional paper sources and the sizes, types, and weights of paper they support. Note: For an unlisted paper size, select the closest larger listed size. Paper sizes supported by the printer Note: When printing on paper less than 210 mm (8.3 inches) wide, the printer may print at a reduced speed after a period of time to ensure the best print performance.
Page 54: Paper Types And Weights Supported By The Printer
7463 Dimensions 550‑sheet tray 2100‑sheet tray Multipurpose Duplex Scanner Paper size feeder glass Universal 105 x 148 mm to 216 x 356 mm (4.13 x 5.83 in. to 8.5 x 14 in.) 70 x 127 mm to 216 x 356 mm (2.76 x 5 in.
Page 55: Paper Sizes, Types, And Weights Supported By The Output Options
7463 Paper type 550‑sheet tray 2100‑sheet Multipurpose Duplex Scanner glass tray feeder Plain Envelope Rough Envelope Paper Labels Pharmacy Labels Transparencies* * Print transparencies in batches of only up to 20 to prevent them from sticking together. For more information, see “Tips on using transparencies”...
Page 56 7463 Supported paper types and weights Paper type Paper weight 4‑bin mailbox Offset stacker Staple finisher Staple, hole punch finisher Plain paper 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Card stock 163 g/m (90 Ib index) 199 g/m (110 Ib index) Transparency 146 g/m...
Page 57: Data Security Notice
7463 Paper type Paper weight 4‑bin mailbox Offset stacker Staple finisher Staple, hole punch finisher Preprinted 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Colored paper 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Light paper 90–176 g/m (24–47 lb bond) 60–90 g/m...
Page 58: Tools Required For Service
7463 • Hard disk memory—The printer hard disk is designed for printer-specific functionality and cannot be used for the long‑term storage of data that is not print-related. The hard disk can retain buffered user data from complex print jobs, form data, and font data. To erase volatile memory, turn off the printer.
Page 59: Diagnostic Information
7463 Diagnostic information CAUTION—SHOCK HAZARD: Remove the power cord from the electrical outlet before you connect or disconnect any cable or electronic card or assembly for personal safety and to prevent damage to the printer. Disconnect any connections between the printer and PCs/peripherals. CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more trained personnel to lift it safely.
Page 60: Using Safe Mode
7463 A splash screen appears on the display. The following errors or messages may appear: • Close Door or Insert Cartridge appear if the front access door is open or the print cartridge is missing • Cartridge errors, such as Defective Cartridge or Missing Cartridge Ready appears on the display.
Page 61: Fixing Print Quality Issues
7463 Fixing print quality issues The symptoms described in this chapter might require replacement of one or more CRUs (Customer Replaceable Units) designated as supplies or maintenance items, which are the responsibility of the customer. With the customer's permission, you might need to install a developer (toner) cartridge. Initial print quality check Before troubleshooting specific print problems, complete the following initial print quality check: •...
Page 62: Horizontal Voids Check
7463 Actions Step 1 Go to step 2. Replace the toner cartridge. Ensure the toner cartridge has sufficient toner. Does the cartridge have sufficient toner? Step 2 Go to step 3. Problem is solved. Remove any contamination from the CTLS contacts, located on the toner level/imaging unit high voltage contact.
Page 63: Print Irregularities Check
7463 Action Step 1 Go to step 2. The problem is solved. Check the media condition, and load new dry, and recommended media. Reprint the defective image. Does the problem remain? Step 2 Go to step 3. Remove debris or contamination.
Page 64: Blank Pages Check
7463 Action Step 2 Go to step 3. The problem is solved. Check the media condition and load new dry, recommended media. Reprint the defective image. Does the problem remain? Step 3 Go to step 4. Replace the print cartridge. Check the toner level.
Page 65: Solid Black Pages Check
7463 Actions Step 1 Replace the toner Go to step 2. cartridge. Check the toner cartridge level. Is the toner level low? Step 2 Go to step 3. Replace the imaging unit. Check the imaging unit for wear or damage. Is it free of wear or damage? Step 3 Go to step 4.
Page 66: Shadow Images Check
7463 Actions Step 1 Go to step 2. Replace the imaging unit. Check the imaging unit for damage. Is it free of damage? Step 2 Go to step 3. The problem is solved. Remove any contamination from the imaging unit contacts. Does the problem remain? Step 3 Replace the HVPS.
Page 67: Skewed Print Check
7463 Actions Step 5 Replace the LVPS. See The problem is solved. “LVPS removal” on Reseat the connections on the LVPS. page 445. Does the problem remain? Skewed print check Actions Step 1 Go to step 2. The problem is solved. Perform a print test: Diagnostics menu >...
Page 68: Streaked Horizontal Lines Check
7463 Actions Step 6 Contact the next level The problem is solved. of support. Perform the media skew adjustment. See “Media aligner roller adjustment” on page 393. Does the problem remain? Step 7 The problem is solved. Replace the printer. Make sure the input roller/deskew assembly is free of debris.
Page 69 7463 Actions Step 4 Go to step 5. The problem is solved. Make sure the imaging unit or toner cartridge is not damaged. Remove the print or toner cartridge. Warning—Potential Damage: Be careful not to touch the photoconductor drum or imaging unit. Doing so may affect the print quality of future print jobs.
Page 70: Streaked Vertical Lines Check
7463 Actions Step 11 Contact the next level The problem is solved. of support. Perform a print test. Does the problem remain? Streaked vertical lines check Actions Step 1 Go to step 2. Replace the transfer roll. Check the transfer roll for contamination or excessive wear. Is it free of contamination or wear? Step 2 Go to step 3.
Page 71: Vertical Voids Check
7463 Actions Step 1 Go to step 2. Replace the imaging unit. Check the imaging unit for wear or damage. Is it free of wear or damage? Step 2 Go to step 3. The problem is solved. Make sure the paper path is free of debris or toner contamination. Does the problem remain? Step 3 Go to step 4.
Page 72: Toner Fog Or Background Shading Check
7463 Action Step 3 Go to step 4. Remove debris or clean the printhead Check the laser beam route. Check for debris between the printhead assembly window. assembly and the PC drum. Is the laser beam route free of debris, and the glass window in the printhead assembly free of contamination? Step 4 Go to step 5.
Page 73 7463 Actions Step 1 The problem is solved. Go to step 2. Make sure the imaging unit or toner cartridge is not damaged. Note: In some printer models, you may need to check all print or toner cartridges. Remove the imaging unit or toner cartridge. Warning—Potential Damage: Be careful not to touch the photoconductor drum or imaging kit.
Page 74: Toner Smear Check
7463 Toner smear check Actions Step 1 Go to step 2. Reseat the fuser, and tighten the screws. Check if the fuser screws are tightly fastened. Are they tightly fastened? Step 2 Go to step 3. Replace the fuser. See “Fuser removal”...
Page 75 7463 Correct loading of paper Incorrect loading of paper • Do not remove a tray while the printer is printing. • Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it. •...
Page 76 7463 • Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing tightly against the paper or envelopes. • Push the tray firmly into the printer after loading paper. • If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the paper are on the right side of the tray.
Page 77: Understanding Jam Messages And Locations
7463 • If paper needs to be returned to the mailbox bin, then insert the paper under the bin arm, and then push the paper all the way back. Note: If the paper is not under the bin arm, then a jam occurs due to an overfilled bin. Use recommended paper •...
Page 78 Check your printed output for blank pages. • When Jam Recovery is set to On or Auto, the printer reprints jammed pages. However, the Auto setting reprints jammed pages if adequate printer memory is available. MX71x Area Area name Printer control panel message...
Page 79 7463 MX81x Area name Printer control panel message What to do Stapler doors [x]‑page jam, remove paper, open Remove paper from the stapler bin, and then open the stapler door. Leave paper in stapler outer and inner doors. Then remove the staple bin.
Page 80: Paper Jams
7463 Area name Printer control panel message What to do Standard bin [x]‑page jam, remove standard bin Remove all paper from the standard bin, and then jam. [203] remove the jammed paper. Automatic [x]‑page jam, open automatic feeder Remove all paper from the ADF tray, and then remove document feeder top cover.
Page 81 7463 Lift the green handle, and then pull the imaging unit out of the printer. Place the imaging unit aside on a flat, smooth surface. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems.
Page 82 7463 Install the imaging unit. Note: Use the arrows on the side of the printer as a guide. Insert the cartridge into the printer, and then push the green handle back into place. Notes: • Align the arrows on the guides of the toner cartridge with the arrows in the printer. •...
Page 83: Paper Jam Messages
7463 Close the multipurpose feeder door and the front cover. To clear the message and continue printing, select Next > > Clear the jam, press OK > 200–201 paper jam messages Error code Description Action 200.01 Media remains on the sensor (input) during Go to “Sensor (input) static jam service check”...
Page 84 7463 Error code Description Action 200.12 Printhead was not ready for the page when Go to “Printhead motor control jam service check” on the sensor (input) was reached. page 200.13 The page at the sensor (input) is not the next Go to “Sensor (input) miscellaneous jam 1 service check”...
Page 85: Sensor (Input) Static Jam Service Check
7463 Sensor (input) static jam service check Action Step 1 Go to step 2. Remove any pre- staged or jammed Check the media path for partially fed or jammed media. media. Is the media path free from partially fed or jammed media? Step 2 Go to step 4.
Page 86: Sensor (Input) Never‑ Or Late‑Arriving Jam Service Check
7463 Action Step 4 Go to step 5. Replace the MPF feeder lift plate. See Check the MPF feeder lift plate assembly for damage. “MPF feeder lift plate removal” on page Is the component free from damage? 465. Step 5 Go to step 6.
Page 87 7463 Action Step 3 Replace the damaged Go to step 4. media. Check the media condition in all media trays. Is any of the media in any of the media trays crumpled or damaged? Step 4 Go to step 5. Go to step 7.
Page 88: Sensor (Input) Late-Leaving Or Did-Not-Clear Jam Service Check
7463 Action Step 11 Replace the Sensor Replace the (input). See “Sensor connection. Check the sensor for proper connection. (input) removal” on page 473. Is the sensor connected properly? Step 12 Go to step 13. Replace the appropriate media Perform a print test, and check the appropriate media feeder. feeder.
Page 89 7463 Action Step 6 Go to step 9. Replace the MPF pick solenoid. Perform a MPF print test, and check the MPF pick solenoid for proper operation. Does the component operate properly? Step 7 Go to step 8. Clean or replace the pick roller.
Page 90: Main Drive Motor Control Jam Service Check
7463 Main drive motor control jam service check Action Step 1 Go to step 2. The problem is solved. Reseat the imaging unit, and then perform a print test. Does the error remain? Step 2 Go to step 3. The problem is solved. Replace the imaging unit.
Page 91: Fuser Drive Motor Control Jam Service Check
7463 Fuser drive motor control jam service check Action Step 1 Go to step 2. The problem is solved. Make sure that the paper is properly loaded to the tray. See “Avoiding jams” on page Make sure that the paper is properly loaded to the tray. See “Avoiding jams”...
Page 92: Sensor (Input) Miscellaneous Jam 1 Service Check
7463 Sensor (input) miscellaneous jam 1 service check Action Step 1 Go to step 3. Go to step 2. Check the appropriate media tray sensor (pass through) in the appropriate input option for proper operation. Enter the diagnostic mode. Select Input tray tests. Select Sensor test.
Page 93: Sensor (Input) Miscellaneous Jam 3 Service Check
7463 Sensor (input) miscellaneous jam 3 service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for all media trays. setup. Does the media size in use match the size set for all media trays? Step 2 Replace the damaged Go to step 3.
Page 94: Paper Jam Messages
7463 Close the rear door. To clear the message and continue printing, select Next > > Clear the jam, press OK > 202 paper jam messages Error code Description Action 202.01 Media remains on the sensor (narrow media) Go to “Sensor (narrow media) static jam service check”...
Page 95: Sensor (Fuser Exit) Static Jam Service Check
7463 Error code Description Action 202.22 Cartridge Motor—Motor under‑speed error. Go to “Fuser drive motor control jam service check” on page Motor made it to closed loop at a steady state, but then detected speed was below threshold 202.28 The sensor (fuser exit) rebounded upon being Go to “Sensor (fuser exit) miscellaneous jam service check”...
Page 96: Sensor (Fuser Exit) Late-Leaving Jam Service Check
7463 Sensor (fuser exit) late-leaving jam service check Action Step 1 Go to step 2. Close or replace the rear door. See “Rear Check the rear door. door removal” on page 549. Is the rear door free of damage and properly closed? Step 2 Replace the fuser.
Page 97: Sensor (Fuser Exit) Late-Arriving Jam Service Check
7463 Sensor (fuser exit) late-arriving jam service check Action Step 1 Replace the fuser. See Go to step 2. “Fuser removal” on Check the fuser unit assembly for damage and life expiration. page 556. Is the component damaged or has it exceeded life? Step 2 Go to step 3.
Page 98: Sensor (Narrow Media) Late Arriving Jam Service Check
7463 Sensor (narrow media) late arriving jam service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for all media trays. setup. Does the media size, in use, match the size set for all media trays? Step 2 Go to step 3.
Page 99: Sensor (Narrow Media) Static Jam Service Check
7463 Sensor (narrow media) static jam service check Action Step 1 Go to step 2. Remove any jammed media. Check the fuser for jammed media. Is the fuser path free from jammed media? Step 2 Go to step 4. Go to step 3. Check the sensor (fuser exit) for proper operation.
Page 100: Fuser Id Chip Control Jam Service Check
7463 Fuser ID chip control jam service check Action Step 1 Go to step 2. Reinstall the fuser. Ensure the fuser is properly installed. Is the fuser properly installed? Step 2 Replace the fuser. See Problem solved. “Fuser removal” on Remove the existing fuser, and install a different fuser.
Page 101: Paper Jam Messages
7463 203 paper jam messages Error code Description Action 203.20 Took too long to ramp up upper redrive Go to “Upper redrive motor control jam service check” on motor page 101. 203.21 Upper redrive motor stopped after successful Go to “Upper redrive motor control jam service check”...
Page 102: Y Paper Jams
7463 23y paper jams [x]‑page jam, open upper and lower rear door. [231–234] CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching. Pull down the rear door.
Page 103 7463 Push the back of the standard tray. Press down the rear duplex flap, then firmly grasp the jammed paper, and then gently pull the paper out. Note: Make sure all paper fragments are removed. Insert the standard tray. To clear the message and continue printing, select Next > >...
Page 104: X]‑Page Jam, Remove Tray 1 To Clear Duplex. [235–239]
7463 [x]‑page jam, remove tray 1 to clear duplex. [235–239] Lift the tray slightly, and then pull it out completely. Push down the front duplex flap, then firmly grasp the jammed paper, and then gently pull the paper to the right and out of the printer.
Page 105: Sensor (Duplex Path) Static Jam Service Check
7463 Error code Description Action 232.03 The media is late reaching the sensor (input) Go to “Sensor (input) never-arriving jam (exiting duplex) within the specified time when exiting the service check” on page 110. duplex. 230.05 The media reached the sensor (duplex path) Go to “Sensor (duplex path) late leaving jam service check”...
Page 106: Sensor (Duplex Path) Never‑ Or Late‑Arriving Jam Service Check
7463 Sensor (duplex path) never‑ or late‑arriving jam service check Action Step 1 Go to step 2. Remove any jammed media or obstructions. Check the fuser access door area for media jams and obstructions. Is the fuser access door area free from jammed media and obstructions? Step 2 Go to step 3.
Page 107: Sensor (Duplex Path) Early Arriving Jam Service Check
7463 Sensor (duplex path) early arriving jam service check Action Step 1 Go to step 2. Remove any jammed media or obstructions. Check the duplex path for jammed media and obstructions. Is the duplex path free from jammed media and obstructions? Step 2 Go to step 4.
Page 108: Duplex Control Jam Service Check
7463 Action Step 3 Go to step 5. Go to step 4. Check the sensor (duplex path) for proper operation. Enter the diagnostic mode. Select duplex tests. Select sensor test. Observe the line item sensor. Does the display on the control panel change every time the sensing area of the sensor is interrupted or blocked? Step 4 Replace the sensor...
Page 109: Sensor (Duplex Path) Miscellaneous Jam Service Check
7463 Action Step 3 Replace the duplex Problem solved. motor. See “Duplex Reset the machine. motor removal” on page 553. Does the error continue? Go to step 4. Step 4 Replace the controller Problem solved. board. See “Controller Reset the machine. board removal”...
Page 110: Sensor (Input) Never-Arriving Jam (Exiting Duplex) Service Check
7463 Sensor (input) never-arriving jam (exiting duplex) service check Action Step 1 Go to step 2. Remove media jams and obstructions. Check the duplex path for media jams and obstructions. Is the duplex path free from media jams and obstructions? Step 2 Go to step 4.
Page 111: Paper Jams
7463 241 paper jams [x]‑page jam, open tray [1]. [241] Check which tray is indicated on the printer display. Lift the tray slightly, and then pull it out completely. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed.
Page 112: Paper Jam Messages
7463 Insert the tray. To clear the message and continue printing, select Next > > Clear the jam, press OK > 241 paper jam messages Error code Description Action 241.02 Sensor (input) early arriving jam Go to “Sensor (input) early arriving jam service check”...
Page 113: Sensor (Input) Never-Arriving Jam From Tray 1 Service Check
7463 Sensor (input) never-arriving jam from tray 1 service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for media tray 1. setup in media tray 1. Does the media size, in use, match the size set for media tray 1? Step 2 Remove any excess...
Page 114: Media Tray 1 Pulled Jam Service Check
7463 Action Step 10 Contact the next Problem solved. highest level of Perform a print test. technical support. Does the problem remain? Media tray 1 pulled jam service check Action Step 1 Go to step 2. Remove all media jams. Remove all media jams from the media tray and printer.
Page 115: Media Feeder Motor Tray Lift Error Service Check
7463 Action Step 5 Go to step 6. Reseat the connection. Ensure the cable for socket “INDEX / PAP OUT/ PICK MTR” on the controller board is properly connected. Is the above connection properly connected? Step 6 Replace the media Problem solved.
Page 116: Paper Jams
7463 242–245 paper jams [x]‑page jam, open tray [x]. [24y] Check which tray is indicated on the printer display. Lift the tray slightly, and then pull it out completely. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed.
Page 117: Paper Jam Messages
7463 Insert the tray. To clear the message and continue printing, select Next > > Clear the jam, press OK > 242 paper jam messages Error code Description Action 242.01 250/550‑sheet tray: Media remains detected Go to “250/550-sheet media tray option jam service check” on by the tray 2 sensor (pass through) after page 129.
Page 118 7463 Error code Description Action 242.10 HCIT: Failure to feed from tray 2 Go to “HCIT source jam service check” on page 134. 242.11 250/550‑sheet tray: Pick/lift motor encoder Go to “250/550-sheet media tray option jam service check” on not detected in tray 2. page 129.
Page 119 7463 Error code Description Action 242.19 HCIT: Failed to feed from tray 2—the leading Go to “HCIT jam service check” on page 132. edge of the media was not detected. 242.20 250/550‑sheet tray: Took too long to ramp up Go to “250/550-sheet media tray option jam service check”...
Page 120: Paper Jam Messages
7463 Error code Description Action 242.45 250/550‑sheet tray: Separator pass through Go to “250/550-sheet media tray option jam service check” on motor under‑speed in tray 2 page 129. 242.45 HCIT: Separator pass through motor Go to “HCIT jam service check” on page 132.
Page 121 7463 Error code Description Action 243.08 HCIT: A misfeed occurred due to shingling. Go to “HCIT jam service check” on page 132. The misfed media is flushed to the output bin. Press Continue to print using the next available media. 243.09 250/550‑sheet tray: Tray 3 pick motor lost Go to...
Page 122 7463 Error code Description Action 243.19 250/550‑sheet tray: Failed to feed from tray Go to “250/550-sheet media tray option jam service check” on 3—the leading edge of the media was not page 129. detected. 243.19 HCIT: Failed to feed from tray 3—the leading Go to “HCIT jam service check”...
Page 123: Paper Jam Messages
7463 Error code Description Action 243.44 250/550‑sheet tray: Separator pass through Go to “250/550-sheet media tray option jam service check” on motor stall in tray 3 page 129. 243.44 HCIT: Separator pass through motor stall in Go to “HCIT jam service check” on page 132.
Page 124 7463 Error code Description Action 244.08 250/550‑sheet tray: A misfeed occurred due Go to “250/550-sheet media tray option jam service check” on to shingling. The misfed media is flushed to page 129. the output bin. Press Continue to print using the next available media.
Page 125 7463 Error code Description Action 244.17 HCIT: Media was not properly picked from Go to “HCIT jam service check” on page 132. tray 4. Tray did not exhaust all pick retry attempts because of media committed to the media path from the tray below. 244.19 250/550‑sheet tray: Failed to feed from tray Go to...
Page 126: Paper Jam Messages
7463 Error code Description Action 244.43 HCIT: Media feeder motor did not reach the Go to “HCIT jam service check” on page 132. required speed 244.44 250/550‑sheet tray: Separator pass through Go to “250/550-sheet media tray option jam service check” on motor stall in tray 4 page 129.
Page 127 7463 Error code Description Action 245.08 250/550‑sheet tray: A misfeed occurred due Go to “250/550-sheet media tray option jam service check” on to shingling. The misfed media is flushed to page 129. the output bin. Press Continue to print using the next available media.
Page 128 7463 Error code Description Action 245.17 HCIT: Media was not properly picked from Go to “HCIT jam service check” on page 132. tray 5. Tray did not exhaust all pick retry attempts because of media committed to the media path from the tray below. 245.19 250/550‑sheet tray: Failed to feed from tray Go to...
Page 129: Sheet Media Tray Option Jam Service Check
7463 Error code Description Action 245.43 HCIT: Media feeder motor did not reach the Go to “HCIT jam service check” on page 132. required speed 245.44 250/550‑sheet tray: Separator pass through Go to “250/550-sheet media tray option jam service check” on motor stall in tray 5 page 129.
Page 130 7463 Action Step 2 Go to step 3. The problem is solved. Check the pick roller assembly for proper installation. Fully press the pick roller assembly toward the sensor to make sure the mounting latches are properly engaging the slot in the shaft. Does the problem remain? Step 3 Go to step 4.
Page 131 7463 Action Step 8 Go to step 9. The problem is solved. Reseat the connectors J4, J8 and J7 on the controller board. Does the error remain? Step 9 Go to step 11. Go to step 10. Remove the media tray. Manually turn the lift plate drive gear and observe the lift plate.
Page 132: Hcit Jam Service Check
7463 HCIT jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Open the media trays and make sure there are no obstructions on the media path. Check the following: • Make sure the size of the media loaded is within specifications. •...
Page 133 7463 Action Step 6 Go to step 7. Replace the pick roller assembly. See “Drawer Check the pick roller assembly to make sure that the rollers are free from pick roller removal ” on contamination and paper dust. page 650. Is the pick roller assembly free of wear or damage? Step 7 Go to step 8.
Page 134: Hcit Source Jam Service Check
7463 HCIT source jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Check the media paths: Open the media trays and make sure there are no obstructions on the media path. Remove the toner cartridge and the imaging unit. Make sure there are no obstructions on the media path.
Page 135 7463 Action Step 4 Go to step 5. The problem is solved. Remove the left cover and do the following: • Lower down the media pick actuator and then release. Check if the actuator would spring back to its original position. •...
Page 136: Paper Jams
7463 Action Step 9 Replace the controller The problem is solved. board. See “HCIT Check the connectors on the controller board. If damaged, then replace controller board the controller board. See “HCIT controller board removal” on page 676. removal” on page Reseat all connectors on the controller board, then POR the machine.
Page 137: Paper Jam Messages
7463 Slide the paper guide until it lightly rests against the edge of the paper. To clear the message and continue printing, select Next > > Clear the jam, press OK > 250 paper jam messages Error code Description Action 250.02 The input sensor detected a late feed during Go to...
Page 138: Sensor (Input) Never-Arriving Jam From Mpf Media Tray Service Check
7463 Sensor (input) never-arriving jam from MPF media tray service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for the MPF tray. setup. Does the media size, in use, match the size set for the MPF tray? Step 2 Remove any excess Go to step 3.
Page 139: Y Paper Jams
7463 Action Step 10 Go to step 11. Replace the main drive motor. See “Main drive Perform a print test and check the main motor assembly. motor removal” on page 428. Is the media properly transported and able to reach the sensor (input)? Step 11 Contact the next Problem solved.
Page 140 7463 Open the scanner cover. If the jam is in the bottom ADF door or ADF exit bin, then open the bottom ADF door, and then firmly grasp the jammed paper on each side. Note: Make sure all paper fragments are removed. Close the bottom ADF door.
Page 141: Y Paper Jam Messages
7463 Straighten the edges of the original documents, then load the documents into the ADF, and then adjust the paper guide. From the printer control panel, touch Done to clear the message and continue printing. 28y paper jam messages Error code Description Action 282.01...
Page 142: Sensor (Adf Pick) Static Jam Service Check
7463 Sensor (ADF pick) static jam service check Action Step 1 Go to step 2. Remove any media or media fragments. Check the media path. Is the media path free of media or media fragments? Step 2 Go to step 4. Go to step 3.
Page 143 7463 Action Step 3 Go to step 4. Clean or replace the ADF pick roller. Go to Check the ADF pick roller for wear or gear damage. “ADF pick roller removal” on page Is the ADF pick roller assembly free of excess wear or gear damage? 596.
Page 144: Sensor (Adf Pick) Late Leaving Or Not Cleared Jam Service Check
7463 Action Step 11 Contact the next level The problem is solved. of support. Perform a print test using the ADF. Does the problem remain? Sensor (ADF pick) late leaving or not cleared jam service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for the ADF.
Page 145: Sensor (Adf 1St Scan) Static Jam Service Check
7463 Action Step 6 Go to step 8. Go to step 7. Check the ADF pick motor for proper operation. Enter the Diagnostics Menu. Touch Motor Tests. Touch Pick Motor. Perform the test. Does the ADF pick motor operate properly? Step 7 Replace the ADF rear Replace the connection...
Page 146: Sensor (Adf 1St Scan) Never Arriving Or Late Arriving Jam Service Check
7463 Action Step 4 Replace the ADF The problem is solved. controller board. Place an undamaged document in the ADF, and perform a ADF test. Does the error remain? Step 5 Contact the next level The problem is solved. of support. Perform a print test using the ADF.
Page 147 7463 Action Step 5 Go to step 7. Go to step 6. Check the ADF transport motor for proper operation. Enter the Diagnostics Menu. Touch TESTS. Touch Transport Motor/Deskew Clutch. Touch either Motor Forward or Motor backward Perform the test. Does the ADF pick motor operate properly? Step 6 Replace the ADF rear...
Page 148: Sensor (Adf 1St Scan) Late Leaving Or Not Cleared Jam
7463 Sensor (ADF 1st scan) late leaving or not cleared jam Action Step 1 Go to step 2. The problem is solved. Excessive paper dust accumulates on the mylar under the lower paper path guide. This causes the jam error. Place the compressed air can tube in the area shown.
Page 149: Sensor (Adf 2Nd Scan) Static Jam
7463 Action Step 4 Replace the sensor Replace the connection (ADF 1st scan). Go to Check the sensor (ADF 1st scan) for proper connection. “Sensor (ADF 1st scan) removal” on page Is the component properly connected? 604. Step 5 Go to step 7. Go to step 6.
Page 150: Sensor (Adf 2Nd Scan) Never Arriving Or Late Arriving Jam Service Check
7463 Action Step 3 Replace the sensor Replace the (ADF 2nd scan). Go to connection. Check the sensor (ADF 2nd scan) for proper connection. “Interrupt with flag sensor (ADF 2nd scan) Is the component properly connected? removal” on page 614. Step 4 Replace the ADF The problem is solved.
Page 151: Sensor (Adf 2Nd Scan) Late Leaving Or Not Cleared Jam Service Check
7463 Action Step 5 Go to step 7. Go to step 6. Check the ADF transport motor for proper operation. Enter the Diagnostics Menu. Touch TESTS. Touch Transport Motor/Deskew Clutch. Touch either Motor Forward or Motor backward Perform test. Does the ADF pick motor operate properly? Step 6 Replace the ADF rear Replace the...
Page 152 7463 Action Step 3 Go to step 4. Go to step 4. Check the sensor (ADF 2nd scan) for proper operation. Enter the Diagnostics Menu. Touch SCANNER TESTS. Touch Sensor Tests. Observe the line "sensor (ADF 2nd scan)." Does the display on the operator panel change every time the sensing area of the sensor is interrupted or blocked? Step 4 Replace the sensor...
Page 153: Sensor (Adf Media Exit) Static Jam Service Check
7463 Sensor (ADF media exit) static jam service check Action Step 1 Go to step 2. Replace the media, or change the media size Check the media size setup and tray guides for the ADF. Does the media setup. size, in use, match the size set for the ADF Step 2 Go to step 4.
Page 154 7463 Action Step 3 Go to step 5. Go to step 4. Check the sensor (ADF media exit) for proper operation. Enter the Diagnostics Menu. Touch SCANNER TESTS. Touch Sensor Tests. Observe the line "sensor (ADF media exit)." Does the display on the operator panel change every time the sensing area of the sensor is interrupted or blocked? Step 4 Replace the sensor...
Page 155: Sensor (Adf Media Exit) Late Leaving Or Not Cleared Jam Service Check
7463 Sensor (ADF media exit) late leaving or not cleared jam service check Action Step 1 Go to step 2. Remove all contaminates from the Check the media path for contaminates. media path. Is the media path free of excess media dust and foreign objects such as paper clips and staples? Step 2 Go to step 3.
Page 156: Y Paper Jams
7463 Action Step 8 Replace the ADF The problem is solved. controller board. Place an undamaged document in the ADF, and perform a ADF test. Does the error remain? Step 9 Contact the next level The problem is solved. of support. Perform a print test using the ADF.
Page 157: Sensor (Multifeed Detect) Detected Multiple Sheets Service Check
7463 Sensor (multifeed detect) detected multiple sheets service check Action Step 1 Go to step 2. Remove damaged original document and Check the original document condition. replace with a new undamaged original Is the original document free of paper clips and staples as well as damage document.
Page 158: Paper Jams
7463 431 paper jams [x]‑page jam, open mailbox rear door. Leave paper in bin. [43y.xx] Open the rear mailbox door. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Diagnostic information...
Page 159: Paper Jam Messages
7463 Close the rear mailbox door. If the jam is in the mailbox bin, then firmly grasp the jammed paper, and then gently pull it out. Note: Make sure all paper fragments are removed. To clear the message and continue printing, select Next > >...
Page 160: Sensor (Mailbox Pass Through) Jam Service Check
7463 Sensor (mailbox pass through) jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Close the rear door properly. Does the error remain? Step 2 Go to step 3.
Page 161 7463 Action Step 7 Go to step 8. Replace the mailbox diverter plunger Check the diverter plunger assembly: assembly. See • Check the diverter plunger for damage. “Mailbox diverter • Check the diverter cam for damage. plunger assembly removal” on page •...
Page 162: Mailbox Main Motor Jam Service Check
7463 Mailbox main motor jam service check Action Step 1 Go to step 2. The problem is solved. POR the machine. Reseat the output option on the printer. Open the rear door and clear obstructions along the paper path. Does the error remain? Step 2 Go to step 3.
Page 163: Mailbox Diverter Jam Service Check
7463 Action Step 7 Go to step 8. Replace the mailbox rear door. See Open the rear door and do the following: “Mailbox rear door • check the rear door for damage removal” on page • manually turn the rear door rollers and check if they are ok 791.
Page 164 7463 Action Step 4 Go to step 5. Replace the mailbox rear door. See Open the rear door and do the following: “Mailbox rear door • Check the rear door for damage removal” on page • Manually turn the rear door rollers and check if they are ok 791.
Page 165 7463 Action Step 8 Go to step 9. The problem is solved. Open the rear door and check the sensors (pass through): • Make sure the sensor is aligned and seated properly. • Check the sensor and sensor flag for damage. If damaged, then replace the sensor.
Page 166: Mailbox Diverter Plunger Jam Service Check
7463 Action Step 12 Replace the controller The problem is solved. board. See “Mailbox Reseat all the connectors on the controller board. POR the machine. controller board removal” on page Does the error remain? 809. If the error persists, then replace the mailbox assembly.
Page 167: Y Paper Jams
7463 Action Step 5 Replace the sensor The problem is solved. (mailbox diverter Make sure the sensor (mailbox diverter plunger HP) is aligned and plunger HP). See properly seated. “Sensor (mailbox Reseat the sensor cable on the sensor side. Reseat also the sensor diverter plunger HP) connector J8 on the controller board.
Page 168: X]‑Page Jam, Remove Paper, Open Stapler Door. Leave Paper In Bin. [455–457]
7463 Close the staple finisher door. To clear the message and continue printing, select Next > > Clear the jam, press OK > [x]‑page jam, remove paper, open stapler door. Leave paper in bin. [455–457] From the stapler bin, firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed.
Page 169 7463 Open the stapler door. Pull down the latch of the staple cartridge holder, and then pull the holder out of the printer. Use the metal tab to lift the staple guard, and then remove any loose staples. Diagnostic information...
Page 170 7463 Press down the staple guard until it clicks into place. Slide the staples toward the metal bracket. Note: If the staples are at the rear of the cartridge, then shake the cartridge downward to bring the staples near the metal bracket. Diagnostic information...
Page 171: Paper Jam Messages
7463 Warning—Potential Damage: Do not tap the cartridge on a hard surface. This could damage the cartridge. Push the cartridge holder firmly back into the stapler unit until the cartridge holder clicks into place. Close the stapler door. To clear the message and continue printing, select Next > >...
Page 172: Paper Jam Messages
7463 Error code Description Action 451.09 Never received Page In Output from the finisher/offset stacker 451.10 Invalid Page ID returned by the finisher/offset stacker 451.41 Finisher/offset stacker: Main/interface motor stalled Go to “Finisher main motor jam service check” on page 179.
Page 173: Paper Jam Messages
7463 454 paper jam messages Error code Description Action 454.41 Finisher/offset stacker: ejector motor stalled Go to “Finisher ejector jam service check” on page 184. 454.41 Staple, hole punch finisher: ejector motor stalled Go to “Finisher (HPU) ejector jam service check” on page 200.
Page 174: Paper Jam Messages
7463 Error code Description Action 455.80 Finisher/offset stacker: paddle failed to reach its Go to “Finisher paddle jam service check” on home position page 186. 455.80 Staple, hole punch finisher: paddle failed to reach its Go to “Finisher (HPU) paddle jam service check” on home position page 202.
Page 175: Paper Jam Messages
7463 Error code Description Action 456.34 Staple, hole punch finisher: not ready to perform Go to “Stapler carriage (HPU) jam service check” on priming operation page 208. 456.35 Finisher/offset stacker: not ready to perform homing For staple finisher or offset stacker—go to “Stapler operation carriage jam service check”...
Page 176: Paper Jam Messages
7463 Error code Description Action 457.89 Staple, hole punch finisher: Stapler failed to prime Go to “Stapler carriage (HPU) jam service check” on after a stapling operation page 208. 457.90 Finisher/offset stacker: Stapler failed to prime before Go to “Stapler carriage jam service check” on a stapling operation page 191.
Page 177: Sensor (Finisher Pass Through) Jam Service Check
7463 Error code Description Action 459.91 Media fed did not leave the sensor (HPU media align) Go to “HPU communication error jam service on time. check” on page 212. 459.92 Media fed did not leave the sensor (HPU leading edge) on time.
Page 178 7463 Action Step 5 Go to step 6. The problem is solved. Reseat the connector J13 on the controller board, and then POR the machine. Does the error remain? Step 6 Go to step 7. Replace the rear door. “Stapler/offset Open the rear door, and check: stacker rear door •...
Page 179: Finisher Main Motor Jam Service Check
7463 Action Step 12 Go to step 13. Replace the right media stack flap. See Check the right media stack flap: “Media stack flap • Check for damage. (right) removal” on • Check if it is not dislodged from its original position. page 736.
Page 180: Finisher Left Tamper Jam Service Check
7463 Action Step 4 Go to step 6. Go to step 5. Remove the three screws securing the main motor. Note: No need to disconnect the motor cable. Just pull away the motor to see its pinion gear. POR the machine and check if the main motor runs. Does the main motor run? Step 5 Go to step 6.
Page 181 7463 Action Step 2 Go to step 3. Replace the upper interface cable of the Check the auto connector end of the printer below the staple finisher. printer. Is it free of damage? Step 3 Go to step 4. The problem is solved. Check the lower interface cable.
Page 182: Finisher Right Tamper Jam Service Check
7463 Action Step 7 Go to step 8. If a 453.75 or 453.76 error occurs, then Reseat the cable J4 on the controller board, then reseat the same cable replace the right on the tamper motor end. tamper motor. See Swap the left and right tamper motors and take note of the error code.
Page 183 7463 Action Step 4 Go to step 5. Replace the tamper assembly. See “Tamper Make sure the following components are properly installed: assembly removal” on • sensor (right tamper motor HP) page 747. • sensor (left tamper motor HP) • tamper motor (right) •...
Page 184: Finisher Ejector Jam Service Check
7463 Finisher ejector jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 185: Finisher Diverter Jam Service Check
7463 Finisher diverter jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 186: Finisher Paddle Jam Service Check
7463 Action Step 6 Replace the sensor The problem is solved. (stapler diverter Make sure the sensor (stapler diverter plunger HP) is properly seated. plunger HP). See Reseat the cable J11 on the controller board. Reseat the same cable “Sensor (stapler/ on the sensor (stapler diverter plunger HP) end.
Page 187 7463 Action Step 4 Replace the sensor The problem is solved. (paddle motor HP). See Remove the left cover. Reseat the cable J11 on the controller board, then “Sensor (paddle motor reseat the same cable on the sensor (paddle motor HP) end. POR the HP) removal”...
Page 188: Finisher Tray Holder Jam Service Check
7463 Finisher tray holder jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 189: Sensor (Throat Media Present) Jam Service Check
7463 Sensor (throat media present) jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 190 7463 Action Step 7 Go to step 8. Replace the media pusher assembly. See Check the media pusher assembly mechanism: “Media pusher • Check the media pusher assembly, media pusher arm, and sensor flag assembly removal” on for damage. page 765.
Page 191: Stapler Carriage Jam Service Check
7463 Action Step 12 Go to step 14. Go to step 13. Remove the three screws securing the main motor. Note: No need to disconnect the motor cable. Just pull away the motor to see its pinion gear. POR the machine and check if the main motor runs. Does the main motor run? Step 13 Go to step 14.
Page 192 7463 Action Step 3 Go to step 4. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Stapler/offset stacker lower interface cable removal” on page 754. Remove the left cover. Reseat the cable J15 on the controller board, then POR the machine.
Page 193: Sensor (Hpu Finisher Pass Through) Jam Service Check
7463 Sensor (HPU finisher pass through) jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 194 7463 Action Step 6 If the error persists, Replace the finisher then go to step 6. option. See “Staple, Open the rear door. Check the upper and lower rollers on the finisher hole punch finisher side for damage. option removal” on Open the left cover.
Page 195: Finisher (Hpu) Main Motor Jam Service Check
7463 Action Step 12 Go to step 13. Replace the finisher. “Staple, hole Open the top cover and do the following: punch finisher option Check the right media stack flap for damage. removal” on page Make sure the right media stack flap is properly seated and aligned. 840.
Page 196: Finisher (Hpu) Left Tamper Jam Service Check
7463 Action Step 4 Go to step 6. Go to step 5. Remove the three screws securing the main motor. Note: No need to disconnect the motor cable. Just pull away the motor to see its pinion gear. POR the machine and check if the main motor runs. Does the main motor run? Step 5 Go to step 6.
Page 197 7463 Action Step 2 Go to step 3. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861. Remove the left cover. Reseat the cable J15 on the controller board, then POR the machine.
Page 198: Finisher (Hpu) Right Tamper Jam Service Check
7463 Action Step 7 Go to step 8. If a 453.75 or 453.76 error occurs, then Reseat the cable J4 on the stapler controller board, then reseat the replace the right same cable on the tamper motor end. tamper motor. See Swap the left and right tamper motors and take note of the error code.
Page 199 7463 Action Step 4 Go to step 5. Replace the tamper assembly. See “Stapler Make sure the following components are properly installed: tamper assembly • sensor (right tamper motor HP) removal” on page • sensor (left tamper motor HP) 869. •...
Page 200: Finisher (Hpu) Ejector Jam Service Check
7463 Finisher (HPU) ejector jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 201: Finisher (Hpu) Diverter Jam Service Check
7463 Finisher (HPU) diverter jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 202: Finisher (Hpu) Paddle Jam Service Check
7463 Action Step 6 Go to step 7. The problem is solved. Make sure the sensor (stapler diverter plunger HP) is properly seated. Reseat the cable J8 on the controller board. Reseat the same cable on the sensor (stapler diverter plunger HP) end. POR the machine. Does the error remain? Step 7 Replace the stapler...
Page 203 7463 Action Step 4 Replace the sensor The problem is solved. (paddle motor HP). See Remove the left cover. Reseat the cable J11 on the controller board, then “Sensor (paddle motor reseat the same cable on the sensor (paddle motor HP) end. POR the HP) removal”...
Page 204: Finisher (Hpu) Tray Holder Jam Service Check
7463 Finisher (HPU) tray holder jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 205: Sensor (Hpu Throat Media Present) Jam Service Check
7463 Sensor (HPU throat media present) jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 206 7463 Action Step 6 Replace the sensor The problem is solved. (throat media present). Open the left and right cover, then do the following: “Sensor (throat Check the sensor flag (throat media present) for damage. Toggle the media present) sensor flag and check if it has no problem moving. removal”...
Page 207 7463 Action Step 10 Go to step 11. Replace the stapler drive gear assembly. Check the drive gear assembly mechanism: “Stapler drive gear • Remove the finisher option from the printer. From the bottom of the assembly removal” on option, turn the lowermost drive gear clockwise. Make sure the rollers page 857.
Page 208: Stapler Carriage (Hpu) Jam Service Check
7463 Stapler carriage (HPU) jam service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Reseat the installed output option on the printer. Clear obstructions along the paper path. Make sure that the sensors (pass through) are free from obstructions. Close the rear door properly.
Page 209: Hpu Motor Jam Service Check
7463 Action Step 7 Go to step 8. Replace the stapler carriage. See “Stapler Remove the stapler carriage. Manually turn the gears to open the stapling carriage assembly mechanism. While open, check the area inside the stapling mechanism removal” on page and make sure it is free from obstructions.
Page 210 7463 Action Step 3 If the error persists, Replace the finisher then go to step 4. option. See “Staple, Open the rear door. Clear all obstructions on the hole punching area. hole punch finisher Rotate the gear engaged to the hole puncher to release stuck media option removal”...
Page 211: Hpu Feed Motor Jam Service Check
7463 HPU feed motor jam service check Action Step 1 Go to step 2. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861.
Page 212: Hpu Communication Error Jam Service Check
7463 HPU communication error jam service check Action Step 1 Go to step 2. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861.
Page 213: Sensor (Hpu Media Align) Jam Service Check
7463 Sensor (HPU media align) jam service check Action Step 1 Go to step 2. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861.
Page 214: Sensor (Hpu Trailing Edge) Jam Service Check
7463 Action Step 6 Replace the stapler The problem is solved. controller board. See Open the left cover, reseat all connectors on the stapler controller board “Stapler controller and then POR the machine. board removal” on page 851. Does the error remain? If the error persists, then replace the finisher option.
Page 215 7463 Action Step 4 If the error persists, Replace the finisher then go to step 5. option. See “Staple, Do the following: hole punch finisher • Open, and then close the rear door. Check if the rear door closes option removal” on properly.
Page 216: Sensor (Hpu Leading Edge) Jam Service Check
7463 Sensor (HPU leading edge) jam service check Action Step 1 Go to step 2. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861.
Page 217: Understanding The Printer Messages
7463 Action Step 6 Replace the stapler The problem is solved. controller board. See Open the left cover, reseat all connectors on the stapler controller board “Stapler controller and then POR the machine. board removal” on page 851. Does the error remain? If the error persists, then replace the finisher option.
Page 218: Change [Paper Source] To [Paper Size] Load [Orientation]
7463 • Cancel the print job. Change [paper source] to [paper size] load [orientation] Try one or more of the following: • Load the correct size and type of paper in the tray or feeder, specify the paper size and type in the Paper menu on the printer control panel, and then touch Finished changing paper.
Page 219: Close Finisher Rear Door
7463 Close finisher rear door Close the rear door of the finisher. Close flatbed cover and load originals if restarting job [2yy.xx] Try one or more of the following: • Touch Scan from automatic feeder to continue scanning from the ADF immediately after the last successful scan job.
Page 220: Defective Flash Detected [51]
7463 Defective flash detected [51] Try one or more of the following: • Replace the defective flash memory card. • From the printer control panel, touch Continue to ignore the message and continue printing. • Cancel the current print job. Disk full [62] Try one or more of the following: •...
Page 221: Error Reading Usb Hub. Remove Hub
7463 Error reading USB hub. Remove hub. An unsupported USB hub has been inserted. Remove the USB hub, and then install a supported one. Fax memory full From the printer control panel, touch Continue to clear the message. Fax partition inoperative. Contact system administrator. Try one or more of the following: •...
Page 222: Imaging Unit Very Low, [X] Estimated Pages Remain [84.Xy]
7463 Imaging unit very low, [x] estimated pages remain [84.xy] You may need to replace the imaging unit very soon. For more information, see the “Replacing supplies” section of the User’s Guide. If necessary, touch Continue on the printer control panel to clear the message and continue printing. Incompatible output bin [x] [59] Try one or more of the following: •...
Page 223: Insert Tray [X]
7463 Insert Tray [x] Try one or more of the following: • Insert the specified tray into the printer. • Cancel the print job. • Reset the active bin for a linked set of bins by selecting Reset active bin on the printer control panel. Install bin [x] Try one or more of the following: •...
Page 224: Insufficient Memory For Flash Memory Defragment Operation [37]
7463 • Reset the active bin. Insufficient memory for Flash Memory Defragment operation [37] Try one or more of the following: • From the printer control panel, touch Continue to stop the defragmentation and continue printing. • Delete fonts, macros, and other data in the printer memory. •...
Page 225: Load [Paper Source] With [Custom Type Name] [Paper Orientation]
7463 Load [paper source] with [custom type name] [paper orientation] Try one or more of the following: • Load the tray or feeder with the correct size and type of paper. • To use the tray with the correct paper size or type, touch Finished loading paper on the printer control panel. Note: If the printer detects a tray that has the correct paper size and type, then it feeds from that tray.
Page 226: Load Manual Feeder With [Custom Type Name] [Paper Orientation]
From the printer control panel, touch Cancel job to cancel the print job. Maintenance kit low [80.xy] You may need to order a maintenance kit. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact customer support, and then report the message.
Page 227: Maintenance Kit Nearly Low [80.Xy]
If necessary, touch Continue to clear the message and continue printing. Maintenance kit very low, [x] estimated pages remain [80.xy] You may need to replace the maintenance kit very soon. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact customer support, and then report the message.
Page 228: Non‑Lexmark [Supply Type], See User's Guide [33.Xy]
The printer has detected a non‑Lexmark supply or part installed in the printer. Your Lexmark printer is designed to function best with genuine Lexmark supplies and parts. Use of third-party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components.
Page 229: Printer Had To Restart. Last Job May Be Incomplete
Printer had to restart. Last job may be incomplete. From the printer control panel, touch Continue to clear the message and continue printing. For more information, visit http://support.lexmark.com or contact customer support. Reattach bin [x] Try one or more of the following: •...
Page 230: Reinstall Missing Or Unresponsive Cartridge [31.Xy]
7463 Reinstall missing or unresponsive cartridge [31.xy] Try one or more of the following: • Check if the toner cartridge is missing. If missing, install the toner cartridge. For information on installing the cartridge, see the “Replacing supplies” section of the User’s Guide. •...
Page 231: Replace All Originals If Restarting Job
“Replacing supplies” section of the User’s Guide. Note: If you do not have a replacement cartridge, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace cartridge, printer region mismatch [42.xy] Install a toner cartridge that matches the region number of the printer.
Page 232: Replace Jammed Originals If Restarting Job
Touch Restart job to restart the scan job with the same settings from the previous scan job. Replace maintenance kit, 0 estimated pages remain [80.xy] The printer is scheduled for maintenance. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact your service representative, and then report the message.
Page 233: Replace Unsupported Cartridge [32.Xy]
Guide. Note: If you do not have a replacement cartridge, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace unsupported imaging unit [32.xy] Remove the imaging unit, and then install a supported one to clear the message and continue printing. For more information, see the instruction sheet that came with the supply or see the “Replacing supplies”...
Page 234: Scanner Jam, Remove All Originals From The Scanner [2Yy.xx]
7463 Scanner disabled. Contact system administrator if problem persists. [840.02] Try one or more of the following: • Touch Continue with scanner disabled to return to the home screen, and then contact your system support person. • Touch Reboot and automatically enable scanner to cancel the job. Note: This attempts to enable the scanner.
Page 235: Standard Network Software Error [54]
Turn off the printer, and then turn it back on. • Update the network firmware in the printer or print server. For more information, go to http://support.lexmark.com or contact customer support, and then report the message. Standard USB port disabled [56] Try one or more of the following: •...
Page 236: Too Many Flash Options Installed [58]
7463 Too many flash options installed [58] Turn off the printer. Unplug the power cord from the electrical outlet. Remove the extra flash memory. Connect the power cord to a properly grounded electrical outlet. Turn the printer back on. Too many trays attached [58] Turn off the printer.
Page 237: Usb Port [X] Disabled [56]
7463 Connect the power cord to a properly grounded electrical outlet. Turn the printer back on. USB port [x] disabled [56] From the printer control panel, touch Continue to clear the message. Notes: • The printer discards any data received through the USB port. •...
Page 238 7463 Error Description Action code 31.44 Toner cartridge ROM signature error Go to “Toner cartridge smart chip error service check” on page 242. 31.45 Toner cartridge stuck or busy; status register and/or CRI Arbiter Go to “Toner cartridge smart chip error service register report busy check”...
Page 239 7463 Error Description Action code 33.xx Non‑license return program (NLRP) supply installers Replace non‑licensed supply with properly licensed supply. 34.xx Media size mismatch—the printer detects the media as too Do the following: short or too narrow • Make sure that the media loaded is in the proper size.
Page 240 7463 Error Description Action code 42.xy Printer/cartridge mismatch Install a toner cartridge that matches the region number of the printer. The .xy error code value represents the required region number, where x indicates the printer’s region number and y for the cartridge’s region number: •...
Page 241 7463 Error Description Action code Network error—communication failure between the controller Try one or more of the following: board and the network port • From the printer control panel, press Continue to confirm. • Unplug the router, then wait for 30 seconds, and then plug it back again.
Page 242: Toner Level Sensing Error Service Check
7463 Toner level sensing error service check Action Step 1 Go to step 2. Reinstall the toner cartridge properly. Ensure that the toner cartridge is installed properly. Is the toner cartridge properly installed? Step 2 Go to step 3. The problem is resolved.
Page 243: Toner Add Error Service Check
Remove the toner cartridge and properly reinstall it. Does the error remain? Step 2 Go to step 3. Replace the component: Check the toner cartridge plunger (A) for proper operation. • For MX71x models, remove the control panel. See “Control panel removal (MX71x)” on page 488.
Page 244: Imaging Unit Smart Chip Service Check
7463 Action Step 3 Go to step 4. Replace the toner cartridge. Check the toner cartridge shutter button (B) for proper operation. Is the component functional? Step 4 Replace the toner add The problem is solved. motor. See “Toner add Replace the toner cartridge.
Page 245: Fuser Unit Smart Chip Service Check
7463 Action Step 5 Replace the controller Problem resolved. board. See “Controller Reset the machine. board removal” on page 422. Does the error continue? Fuser unit smart chip service check Action Step 1 Go to step 2. Reinstall the fuser properly.
Page 246: Printer Hardware Errors
7463 Printer hardware errors 111 errors 111 error messages Error code Description Action 111.30 Printhead ID error Go to “Printhead ID service check” on page 247. 111.31 Printhead no first HSYNC error 111.32 Printhead loss of HSYNC error 111.33 Printhead loss of HSYNC during servo 111.34 Printhead mirror motor loss of lock 111.35...
Page 247: Printhead Id Service Check
7463 Printhead ID service check Action Step 1 Go to step 2. Install the correct laser printhead. Ensure the correct laser printhead is installed. Go to step 2. Is the proper laser printhead installed? Step 2 Go to step 3. Reseat the connections.
Page 248: Fuser Drive Motor Service Check
7463 Fuser drive motor service check Action Step 1 Go to step 2. Reseat the connections. Ensure the cable for socket J24 on the controller board is properly connected. Go to step 2. Is the connection properly connected? Step 2 Replace the fuser drive The problem is motor.
Page 249 7463 Error code Description Action 121.26 Fuser failed to reach temperature during Go to “Fuser service check” on page 250. warm up 121.28 Fuser failed to reach EP warm-up temperature in time 121.29 Fuser failed to reach preheat temperature for motor start during warm up 121.30 Fuser failed to reach printing temperature by the time a page got to the fuser...
Page 250: Fuser Service Check
7463 Fuser service check Action Step 1 Go to step 2. Reseat the connections. Ensure the fuser is properly installed. Go to step 2. Is the fuser properly installed? Step 2 Replace the fuser. See Problem resolved. “Fuser removal” on Remove the existing fuser and install a different fuser.
Page 251: Lvps Failure Service Check
7463 LVPS failure service check Action Step 1 Go to step 2. The problem is solved. POR the printer. Does the error remain? Step 2 Go to step 3. The problem is solved. Make sure that all of the LVPS cables are properly connected. Does the error remain? Step 3 Go to step 4.
Page 252: Toner Level Sensing Service Check
7463 Toner level sensing service check Action Step 1 Go to step 2. Reinstall the toner cartridge properly. Ensure that the toner cartridge is installed properly. Is the toner cartridge properly installed? Step 2 Go to step 3. Problem resolved. Remove the existing toner cartridge and install a different cartridge.
Page 253: Main Drive Motor Service Check
7463 Error code Description Action 149.00 Redrive motor encoder never detected Go to “Redrive motor service check” on page 254. Main drive motor service check Action Step 1 Go to step 2. Reseat the connections. Ensure the cable for socket “TRANSPORT MTR” on the controller board is properly connected.
Page 254: Redrive Motor Service Check
7463 Redrive motor service check Action Step 1 Go to step 2. Reseat the connection. Ensure the cable for socket "REDRIVE” on the controller board is properly connected. Is the above connection properly connected? Step 2 Replace the upper Problem resolved. redrive.
Page 255: Toner Add Motor Service Check
7463 Toner add motor service check Action Step 1 Go to step 2. Reseat the connection. Ensure the cable for socket J48 on the controller board is properly connected. Is the above connection properly connected? Step 2 Replace the toner add Problem resolved.
Page 256: Main Cooling Fan Service Check
7463 Error code Description Action 172.03 Cartridge cooling fan took too long to ramp Go to “Cartridge cooling fan service check” on page 257. 172.04 Cartridge cooling fan under speed or stalled during speed adjustment state 172.05 Cartridge cooling fan over speed during speed adjustment state 172.06 Cartridge cooling fan capture data is invalid...
Page 257: Cartridge Cooling Fan Service Check
7463 Cartridge cooling fan service check Action Step 1 Go to step 2. Reseat the connection. Ensure the cable for socket "HVPS” on the controller board is properly connected. Is the above connection properly connected? Step 2 Replace the cartridge Problem resolved.
Page 258: Steps Before Starting The 9Yy Service Checks
7463 Action Step 6 Contact the next level The problem is solved. of support. Replace the LVPS. See “LVPS removal” on page 445. Does the error remain? Steps before starting the 9yy service checks Before starting the service checks in this section, you will need to retrieve certain information. This will aid your next level of support in diagnosing the problem before replacing the controller board.
Page 259: Errors
7463 E-mail the logs to your next level of support. Note: Some printer SE menus give you the option of clicking Logs Gzip Compressed. If this option is shown in the menu, then click it and retrieve the compressed log file. Take note of the destination folder where the log file is saved.
Page 260 258. Determine the operating system used when the error occurred. If possible determine whether a PostScript or PCL file was sent to the device when the error occurred. Ask the customer which Lexmark Solutions applications are installed on the device.
Page 261 7463 Action Step 6 Go to step 31. Go to step 7. Print the following: • Error log • Menu settings page • Network settings page Does the error remain while these pages were printing? Step 7 Go to step 8. Go to step 10.
Page 262 Send a print job to the printer. Does the error remain? Step 15 Go to step 31. The problem is solved. Install a Lexmark recommended memory option. Send a print job to the printer. Does the error remain? Step 16 Go to step 17.
Page 263 7463 Action Step 22 Go to step 24. Go to step 23. Reinstall the first ISP option. POR the printer. Does the error remain? Step 23 Go to step 24. Go to step 26. Run a job to test the option. Does the error remain? Step 24 Go to step 25.
Page 264: Errors
7463 Action Step 30 Go to step 31. Go to step 26. Replace the faulty ISP option. POR the printer. Does the error remain? Step 31 Contact your next level of support. You will need the following information: • Exact 900.xx error digits and complete error message •...
Page 265: Errors
7463 950–958 errors 950–958 error messages Error code Description Action 950.xx NVRAM mismatch failure—mismatch between Go to “NVRAM mismatch failure service check” on controller board EEPROM and control panel mirror. page 265. ".xx" codes: • 00-29— mismatch between system and mirror •...
Page 266 7463 Warning—Potential Damage: These components can be used as a method of troubleshooting as long as the machine is booted into diagnostic mode or is operating in diagnostic mode. Once a component has been installed in a machine and powered up into user mode, it cannot be used in another machine. It must be returned to the manufacturer.
Page 267: Adf/Scanner Communication Failure Service Check
7463 ADF/scanner communication failure service check Action Step 1 Replace the flatbed Replace the scanner controller connection. Check the cable that connects the ADF to the controller board in the board. See “Flatbed printer. scanner board removal” on page Is the cable properly connected? 643.
Page 268: Errors
7463 959 errors 959 error messages Error code Description Action 959.01 Controller verification failure of smart chip boot code Go to “Controller board removal” on page 422. Upgrade firmware. If that fails, replace the controller board. 959.02 Failure to authenticate Signature Verification Code Upgrade firmware.
Page 269: Y Errors
7463 Error code Description Action 959.30 Smart chip library flagged an invalid argument(s) Go to “Controller board removal” on page 422. Replace the controller board. 959.31 Smart chip library flagged an invalid device address Replace the controller board. 959.32 Failure to initialize physical interface Replace the controller board.
Page 270: Ram Memory Error Service Check
7463 RAM memory error service check Action Replace the bad memory card. Contact the next level The problem is solved. of support. Does the error remain? Download emulation cyclic redundancy service check Action Step 1 Go to step 2. The problem is solved. Disable the download emulation, and then program the download emulation into the firmware card again.
Page 271: Y Errors
7463 98y errors 98y error messages Error code Description Action 980.xx Engine experiencing unreliable communication with Call the next level of support. the specified device 981.xx Engine protocol violation detected by the specified device 982.xx Communications error detected by the specified device—device can be: •...
Page 272: Network Service Check
Have the network administrator verify that the device is using the correct SSID, and wireless security protocols. For more network troubleshooting information, consult the Lexmark Network Setup Guide. Actions Step 1 Go to step 3.
Page 273 7463 Actions Step 9 Problem fixed. Go to step 10. Reset the address on the printer to match the IP address on the driver. Did this resolve the issue? Step 10 Go to step 12. Go to step 11. Have the network administrator verify that the printer and PC’s IP address have identical subnet addresses.
Page 274: Dead Machine Service Check
7463 Actions Step 20 Go to step 22. Go to step 21. If there is an attached antenna, is the antenna damaged? Step 21 Problem resolved. Go to step 22. Replace the antenna. Did this fix the problem? Step 22 Problem resolved.
Page 275: Blank Display, Five Beeps Service Check
7463 Action Step 4 Go to step 5. Try a different outlet. Check the AC line voltage to the machine. The voltage should be within the following limits: • for 110 machines—100 to 127 V AC • for 220 V machines—200 to 240 V AC Is the voltage within the limits? Step 5 Contact the next...
Page 276: Adf/Scanner Hardware Errors
7463 ADF/Scanner hardware errors 8yy error messages Error code Description Action 840.01 The end user has manually disabled the Enter Configuration mode to enable the scanner and determine flatbed scanner and ADF. if additional errors have occurred. 840.02 The controller has automatically disabled Enter Configuration mode to enable the scanner and determine the flatbed scanner and ADF after two if additional errors have occurred.
Page 277: Flatbed Scanner Home Position Error Service Check
7463 Action Step 3 Replace the ADF Replace the controller board. See connection. Perform an ADF scanner test. “ADF controller card Does the problem remain? removal” on page 582. Flatbed scanner home position error service check Action Step 1 Go to step 2. Replace the connection.
Page 278: Adf Elevator Tray Home Position Error Service Check
7463 Action Step 7 Replace the flatbed The problem is scanner controller resolved. Place an undamaged document on the flatbed scanner and perform a board. See “Flatbed scanner test. scanner board Does the problem remain? removal” on page 643. Step 8 Replace the ADF The problem is controller board.
Page 279: Adf Elevator Tray Motor Stalled Error Service Check
7463 Action Step 5 Replace the ADF The problem is solved. controller board. See Place an undamaged document on the ADF elevator tray and perform an “ADF controller card ADF scanner test. removal” on page Does the problem remain? 582. Step 6 Replace the controller The problem is solved.
Page 280: Adf Elevator Tray Motor Time-Out Error Service Check
7463 ADF elevator tray motor time-out error service check Action Step 1 Go to step 2. The problem is solved. Check the ADF pick roller for proper installation. Remove the ADF pick roller cover, and fully press the ADF pick roller toward the sensor to make sure the mounting latch is properly engaging the slot in the shaft.
Page 281: Flatbed Scanner Ccd Initialization Error Service Check
7463 Flatbed scanner CCD initialization error service check Action Step 1 Go to step 2. Replace the connections. Check the flatbed scanner controller board and all connections on the controller board in the printer for proper connectivity. Are the components properly connected? Step 2 Replace the flatbed The problem is...
Page 282: Adf Media Present Service Check
7463 ADF media present service check Action Step 1 Go to step 2. Remove all contaminates from the Check the media path for contaminates. media path. Is the media path free of excess media dust and foreign objects (for example, paper clips or staples)? Step 2 Go to step 3.
Page 283: Input/Output Option Hardware Errors
7463 Input/output option hardware errors 3yy error messages User attendance messages Error code Description Action 321.51 No encoder feedback detected from the tray 2 Go to “250/550-sheet media feeder failure service pick/lift motor. check” on page 291. 321.52 Motor stop error—the tray 2 pick/lift motor kept on Go to “250/550-sheet media feeder failure service running some time after the motor was commanded...
Page 284 7463 Error code Description Action 325.64 Hardware Error—tray 2 lift plate failed to reach its Go to “HCIT lift plate failure service check” on home position page 299. 331.51 No encoder feedback detected from the tray 3 Go to “250/550-sheet media feeder failure service pick/lift motor.
Page 285 7463 Error code Description Action 341.52 Motor stop error—the tray 4 pick/lift motor kept on Go to “250/550-sheet media feeder failure service running some time after the motor was commanded check” on page 291. to stop. 341.53 The tray 4 pick/lift motor went over the normal speed Go to “250/550-sheet media feeder failure service check”...
Page 286 7463 Error code Description Action 378.52 Motor stop error—the output option 2/mailbox Go to “Mailbox failure service check” on page main/interface motor kept on running some time 302. after the motor was commanded to stop. 379.51 No encoder feedback detected from the output Go to “Mailbox failure service check”...
Page 287: Errors
7463 321–345 errors 321 error messages 321–345 error messages Error code Description Action 321.51 No encoder feedback detected from the tray 2 Go to “250/550-sheet media feeder failure service pick/lift motor. check” on page 291. 321.52 Motor stop error—the tray 2 pick/lift motor kept on running some time after the motor was commanded to stop.
Page 288: Error Messages
7463 324 error messages 321–345 error messages Error code Description Action 324.57 No encoder feedback detected from the tray 2 (HCIT) Go to “HCIT lift drive motor failure service check” lift motor. on page 298. 324.58 Motor stop error—the tray 2 (HCIT) lift motor kept on running some time after the motor was commanded to stop.
Page 289: Error Messages
7463 332 error messages 321–345 error messages Error code Description Action 332.54 250/550‑sheet trays: No encoder feedback detected Go to “250/550-sheet transport motor failure from the tray 3 transport motor. service check” on page 293. 332.54 HCIT: No encoder feedback detected from the tray 3 Go to “HCIT transport motor failure service check”...
Page 290: Error Messages
7463 Error code Description Action 335.64 Hardware Error—tray 3 lift plate failed to reach its Go to “HCIT lift plate failure service check” on home position page 299. 341 error messages 321–345 error messages Error code Description Action 341.51 No encoder feedback detected from the tray 4 Go to “250/550-sheet media feeder failure service pick/lift motor.
Page 291: Error Messages
7463 344 error messages 321–345 error messages Error code Description Action 344.57 No encoder feedback detected from the tray 4 (HCIT) Go to “HCIT lift drive motor failure service check” lift motor. on page 298. 344.58 Motor stop error—the tray 4 (HCIT) lift motor kept on running some time after the motor was commanded to stop.
Page 292 7463 Action Step 2 Go to step 3. Replace the pick roller. Go to “Drawer pick Remove the tray from the drawer and do the following: roller removal ” on • Check the pick roller's position. The pick roller should not hang page 650.
Page 293: Sheet Transport Motor Failure Service Check
7463 Action Step 6 Go to step 7. Replace the interface cable of the printer or Check the interface cable of the printer or upper level option for damage. upper level option. Is the above component in good condition? Step 7 Replace the controller The problem is solved.
Page 294 7463 Action Step 3 Go to step 4. Replace the media tray. “Media tray Remove the tray from the drawer and do the following: assembly removal” on • Check the paper guides for damage. Move the paper guide and verify page 649.
Page 295: Sheet Controller Board Failure Service Check
7463 Action Step 8 Replace the input tray The problem is solved. option. See “250/550- If the 250/550-sheet tray option is the only input option installed, then sheet media tray replace the 250/550-sheet tray option. See “250/550-sheet media tray option removal” on option removal”...
Page 296: Hcit Transport Motor Failure Service Check
7463 Action Step 5 Replace the input tray The problem is solved. option. Go to If the 250/550-sheet tray option is the only input option installed, then “250/550-sheet media replace the 250/550-sheet tray option. See “250/550-sheet media tray tray option removal” option removal”...
Page 297 7463 Action Step 5 Go to step 6. The problem is solved. Separate the HCIT from the printer. Remove also the remaining input options. Check the HCIT interface cable. If damaged, then replace the cable. See “HCIT interface cable removal” on page 681.
Page 298: Hcit Lift Drive Motor Failure Service Check
7463 HCIT lift drive motor failure service check Action Step 1 Go to step 2. Replace the media tray. Go to “HCIT removal” Remove the media tray from the HCIT option and do the following: on page 665. • Remove all media and check the paper guides for damage. Move the paper guide and verify if it can move freely from one position to another.
Page 299: Hcit Lift Plate Failure Service Check
7463 Action Step 6 Replace the controller The problem is solved. board. Go to “HCIT Check the connectors on the controller board. If damaged, then replace controller board the controller board. See “HCIT controller board removal” on page 676. removal” on page Reseat all connectors on the controller board, then POR the machine.
Page 300 7463 Action Step 2 Go to step 3. The problem is solved. Remove the media tray and do the following: • Check the lift drive gears for damage. Manually turn the gears, and check if it causes the lift drive motor encoder to turn. •...
Page 301: Errors
7463 Action Step 8 Go to step 9. The problem is solved. Replace the tray. Does the error remain? Step 9 Contact the next level The problem is solved. of support. Replace the drawer. Does the error remain? 377–381 errors 377–379 error messages 371–383 error messages Error code...
Page 302: Mailbox Failure Service Check
7463 Error code Description Action 381.52 Staple finisher/offset stacker: Motor stop error—the Go to “Finisher ejector jam service check” on output option 1/finisher/offset stacker ejector motor page 184. kept on running some time after the motor was commanded to stop. 381.52 Staple, hole punch finisher: Motor stop error—the Go to...
Page 303 7463 Action Step 3 Go to step 4. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Mailbox lower interface cable removal” on page 812. Reseat the connector J1 on the controller board, then POR the machine. Does the error remain? Step 4 Go to step 5.
Page 304: Option Tray Symptoms
7463 Option tray symptoms Symptom Action Recurring media type error detected on the 250/550‑sheet tray Go to “250/550-sheet media type error service option. check” on page 305. The 250/550-sheet tray is not detected or recognized. Go to “250/550-sheet tray undetected service check”...
Page 305: Sheet Media Type Error Service Check
7463 250/550-sheet media type error service check Action Step 1 The problem may not Go to step 2. be on this option tray. Remove all input options and reinstall only the suspected 250/550-sheet Reinstall the remaining tray option. POR into diagnostics mode and navigate to: input options one at a INPUT TRAY TESTS >...
Page 306 7463 Action Step 4 Go to step 5. The problem is solved. Remove the left cover and do the following: • Lower down the media pick actuator and then release. Check if the actuator would spring back to its original position. •...
Page 307: Sheet Tray Undetected Service Check
7463 250/550-sheet tray undetected service check Action Step 1 Go to step 2. Replace the media tray. Go to “Media tray Remove the tray from the drawer and do the following: assembly removal” on • Check the paper guides for damage. Move the paper guide and verify page 649.
Page 308: Sheet Option Undetected Service Check
7463 Action Step 6 Replace the input tray The problem is solved. option. Go to If the 250/550-sheet tray option is the only input option installed, then “250/550-sheet media replace the 250/550-sheet tray option. See “250/550-sheet media tray tray option removal” option removal”...
Page 309 7463 Action Step 2 Go to step 3. Replace the HCIT drawer assembly. Go to Remove the media tray from the HCIT option and do the following: “HCIT drawer • Check if there is no problem moving the tray input guides. assembly removal”...
Page 310: Hcit Media Type Error Service Check
7463 Action Step 9 Contact the next level The problem is solved. of support. Replace the drawer. Does the error remain? HCIT media type error service check Action Step 1 Go to step 2. Replace the media tray. Go to “HCIT removal”...
Page 311 7463 Action Step 3 Go to step 4. The problem is solved. Remove the left cover and do the following: • Lower down the media pick actuator and then release. Check if the actuator would spring back to its original position. •...
Page 312: Hcit Undetected Service Check
7463 Action Step 8 Replace the controller The problem is solved. board. Go to “HCIT Check the connectors on the controller board. If damaged, then replace controller board the controller board. See “HCIT controller board removal” on page 676. removal” on page Reseat all connectors on the controller board, then POR the machine.
Page 313 7463 Action Step 3 Go to step 4. The problem is solved. Separate the HCIT from the printer. Remove also the remaining input options. Check the HCIT interface cable. If damaged, then replace the cable. See “HCIT interface cable removal” on page 681.
Page 314: Hcit Media Low Undetected Service Check
7463 HCIT media low undetected service check Action Step 1 Go to step 2. Replace the media tray. Go to “HCIT removal” Remove the media tray from the HCIT option and do the following: on page 665. • Remove all media and check the paper guides for damage. Move the paper guide and verify if it can move freely from one position to another.
Page 315 7463 Action Step 4 Go to step 5. Replace the HCIT drawer assembly. Go to Remove the media tray from the HCIT option and do the following: “HCIT drawer • Check if there is no problem moving the tray input guides. assembly removal”...
Page 316: Mailbox Incorrect Bin Exit Service Check
7463 Mailbox incorrect bin exit service check Action Step 1 Go to step 2. Replace the upper interface cable of the Check the auto connector end of the printer below the mailbox. printer. Is it free of damage? Step 2 Go to step 3.
Page 317: Mailbox Undetected Service Check
7463 Action Step 6 Go to step 8. Go to step 7. Open the rear door and check the two sensors (pass through) for proper operation. Enter Diagnostics Menu and navigate to: Output bin tests > Sensor test Select the output bin assigned to the mailbox option. Does the display on the operator panel change every time the sensing area of the sensors are interrupted or blocked? Step 7...
Page 318: Finisher Side Door Error Service Check
7463 Action Step 3 Replace the controller The problem is solved. board. See “Mailbox Reseat all the connectors on the controller board, then POR the machine. controller board removal” on page Does the error remain? 809. If the error persists, then replace the mailbox.
Page 319: Finisher Cartridge Error Service Check
7463 Action Step 6 If the same error The problem is solved. occurs, then go to step Check the sensor (cartridge door interlock). Make sure the sensor is stable 7. If another error and properly installed. occurs, then the sensor Swap the sensor with another common sensor.
Page 320 7463 Action Step 3 Go to step 4. Replace the stapler cartridge. Remove the stapler cartridge. Check the stapler cartridge and make sure obstructions are removed. Is it free of damage? Step 4 Go to step 5. The problem is solved. Remove the left cover.
Page 321: Finisher Undetected Service Check
7463 Finisher undetected service check Action Step 1 Go to step 2. Replace the upper interface cable of the Check the auto connector end of the printer below the staple finisher. printer under the staple finisher. Is it free of damage? Step 2 Go to step 3.
Page 322 7463 Action Step 3 Go to step 4. Clear the obstructions between the two Check the path between the sensor (bin full receive) and the sensor (bin sensors. Remove dirt full send). on the sensor covers. Make sure the sensor Is it free of obstructions? covers are stable and properly installed;...
Page 323: Finisher Door Undetected Service Check
7463 Finisher door undetected service check Action Step 1 Go to step 2. Replace the upper interface cable of the Check the auto connector end of the printer below the staple finisher. printer under the staple finisher. Is it free of damage? Step 2 Go to step 3.
Page 324: Stapler Carriage Failure Service Check
7463 Stapler carriage failure service check Action Step 1 Go to step 2. Replace the upper interface cable of the Check the auto connector end of the printer. printer. Is it free of damage? Step 2 Go to step 3. The problem is solved.
Page 325: Finisher Bin Media Present Error Service Check
7463 Finisher bin media present error service check Action Step 1 Go to step 2. Replace the upper interface cable of the Check the auto connector end of the printer below the staple finisher. printer. Is it free of damage? Step 2 Go to step 3.
Page 326: Stuck Media On Hole Puncher Service Check
7463 Stuck media on hole puncher service check Action Step 1 Go to step 2. The problem is solved. Check the lower interface cable. If damaged, then replace the lower interface cable. See “Staple, hole punch lower interface cable removal” on page 861.
Page 327 7463 Action Step 3 If the error persists, Replace the finisher then go to step 4. option. See “Staple, Do the following: hole punch finisher • Open, and then close the rear door. Check if the rear door closes option removal” on properly.
Page 328: Hole Punch Box Undetected Service Check
7463 Action Step 8 Replace the stapler The problem is solved. controller board. See Open the left cover, reseat all connectors on the stapler controller board “Stapler controller and then POR the machine. board removal” on page 851. Does the error remain? If the error persists, then replace the finisher option.
Page 329: Finisher Door (Hpu) Undetected Service Check
7463 Action Step 5 Replace the stapler The problem is solved. controller board. See Open the left cover, reseat all connectors on the stapler controller board “Stapler controller and then POR the machine. board removal” on page 851. Does the error remain? If the error persists, then replace the finisher option.
Page 330 7463 Action Step 4 Replace the sensor The problem is solved. (HPU rear door Open the rear door and the left cover. Make sure the sensor (HPU rear interlock). See “Sensor door interlock) is properly aligned and seated. (HPU rear door Reseat the sensor cable J4 on the HPU controller board.
Page 331: Service Menus
7463 Service menus Understanding the printer control panel Using the printer control panel MX71x @ ! . A B C D E F G H I J K L M N O P Q R S T U V W X Y Z...
Page 332: Understanding The Colors Of The Sleep Button And Indicator Lights
7463 MX81x Use the Display • View the printer status and messages. • Set up and operate the printer. Home button Go to the home screen. Sleep button Enable Sleep mode or Hibernate mode. Do the following to wake the printer from Sleep mode: •...
Page 333: Understanding The Home Screen
7463 Sleep button light Printer status Blinking amber The printer is entering or waking from Hibernate mode. Blinking amber for 0.1 second, then goes The printer is in Hibernate mode. completely off for 1.9 seconds in a slow, pulsing pattern Understanding the home screen When the printer is turned on, the display shows a basic screen, referred to as the home screen.
Page 334: Using The Touch-Screen Buttons
7463 Touch Status/Supplies • Show a warning or error message whenever the printer requires intervention to continue processing. • Access the messages screen for more information on the message, and how to clear it. Tips Open a context-sensitive Help dialog. Search Held Jobs Search for one or more of the following items: •...
Page 335 7463 Touch Arrows View a list of options. Copy It Print a copy. Advanced Options Select a copy option. Home Go to the home screen. Increase Select a higher value. Decrease Select a lower value. Tips Open a context-sensitive Help dialog. Other touch-screen buttons Touch Accept...
Page 336: Menus List
7463 Menus list Paper Menu Reports Network/Ports Security Settings Default Source Menu Settings Page Active NIC Edit Security Setups General Settings Paper Size/Type Device Statistics Miscellaneous Security Copy Settings Standard Network Settings Configure MP Network Setup Page Fax Settings Standard USB Confidential Print Substitute Size Network [x] Setup...
Page 337: Registration
7463 REGISTRATION These settings adjust the margins of the black plane. To set the Registration: Print a Quick test page. From the Diagnostics menu, navigate to: REGISTRATION > Quick Test Retain this page to determine the changes you need to make to the margin settings. The alignment diamonds in the margins should touch the margins of the page.
Page 338: Print Tests
7463 To view the result for an ADF front adjustment, place a test page image side up and touch Copy Quick Test. Compare the results to the original. Adjust if necessary. To view the result for an ADF back adjustment, place a test page image side down and touch Copy Quick Test. Compare the results to the original.
Page 339: Hardware Tests
7463 PRINT TESTS > Print Quality Pages HARDWARE TESTS If the hardware test fails, replace the failing part. Panel Test This test verifies the function of the control panel display. Enter the Diagnostics menu, and then navigate to: Hardware Tests > Panel Test Exit the test.
Page 340: Serial Wrap Test
7463 • F:##### represents the number of times the memory test failed and finished with errors. The maximum pass count is 999,999. After the maximum pass or fail count is reached or when all the DRAM has been tested, the test stops and the final results appear.
Page 341: Usb Hs Test Mode
7463 USB HS Test Mode From the Diagnostics menu, navigate to: Hardware Tests > USB HS Test Mode Choose the desired port, and then choose the desired test. Ports Tests Port 0 Test J Port 1 Test K Port 2 Test SEO NAK Port 3 Test Packet...
Page 342: Top Margin
7463 To run the Duplex quick test: From the Diagnostics menu, navigate to: Duplex Tests > Quick Test Choose any of the following: • Single—Prints a single Quick test page. • Continuous—Continuously prints the Quick test pages until X is pressed. The printer attempts to print the Quick test page from the default paper source.
Page 343: Motor Test
7463 To run this test: From the Diagnostics menu, navigate to: Duplex Tests > Sensor Test Testing… appears while the printer is verifying the state of the sensor. The control panel displays the current state of the sensor. Manually actuate the sensor to make it toggle between Open and Closed. If the sensor does not toggle, then it is malfunctioning.
Page 344: Input Tray Tests
7463 To run this test: From the Diagnostics menu, navigate to: Duplex Tests > Duplex Feed 2 The power indicator blinks while the paper is feeding, and Duplex Feed 2 Feeding… appears. This test cannot be canceled. The panel displays Duplex Feed 2 Clear Paper when the paper reaches the duplex paper stop position 2. Remove the sheet of paper from the duplex unit, and shut the duplex door.
Page 345: Output Bin Tests
7463 Input source Empty Pass through sensor (Input tray empty (Input tray paper low sensor) sensor) Multi‑purpose feeder Envelope feeder Manually actuate each sensor. The tray empty sensor can be actuated by hand; however, a sheet of paper can be used to cover the pass through sensor.
Page 346: Diverter Test
7463 To run this test: From the Diagnostics menu, navigate to: Output Bin Tests > Sensor Test > Standard Bin Testing... appears while the printer is verifying the state of the sensor. The control panel displays the current state of the sensor. Manually actuate the sensor to make it toggle between empty and full.
Page 347: Feed Test (Finisher)
7463 • 4 Punch Test Hole Punch Test Running... appears while the test is running. Feed Test (finisher) This test verifies that media can be fed from the default source to a finisher output bin. Any size paper that is supported can be used.
Page 348: Device Tests
7463 The following sensors can be checked using this test: • Input • Fuser exit • Narrow media • Control panel interlock • Rear door interlock • Rear lower door interlock CAUTION—SHOCK HAZARD: Do not use your hand to toggle these switches. Use a nonconducting item. To run the Base Sensor Test.
Page 349: Flash Test
7463 Flash Test This test verifies the condition of the flash device by writing data to it and then reading data from it. Warning—Potential Damage: This test destroys all data on the flash device. Note: After this test is executed, reformat the flash using the Flash Format setting in the Utilities menu. From the Diagnostics menu, navigate to: Device Tests >...
Page 350: Printed Page Count
7463 Do one of the following: • Depending on the printer model, press OK or touch to save any changes. • Press X to return to the Printer setup menu. Printed Page Count This setting gauges the amount of usage on the printer. The value of the Printed Page Count setting equals the value of the Picked Sides meter.
Page 351: Ep Setup
7463 Each time the value is increased by one, the strobe is sampled 50 nanoseconds longer. Each time the value is decreased by one, the strobe is sampled 50 nanoseconds less than the default value. The range of values is between -4 and +6, in increments of one.
Page 352: Transfer
7463 Transfer This setting controls the transfer roll algorithm. To adjust this setting: From the Diagnostics menu, navigate to: EP Setup > Transfer Press Back. Print Contrast This setting controls the developer voltage offset. To adjust this setting: From the Diagnostics menu, navigate to: EP Setup >...
Page 353: Reports
7463 Each time this setting executes, the printer performs the following: • Calibrates its toner density sensor • Measures the reflectivity of its bare drum • Prints patches on the drum and measures the reflectivity of the drum through the patches •...
Page 354: Print Log
7463 Print Log Additional diagnostic information is available when the event log is printed. The first page of the report shows the general device information. The specific events that appear in the report vary depending on the operational history of the printer. Logs may be printed from the following events: •...
Page 355: Scanner Tests
7463 This menu appears as a soft button at the bottom right corner of the panel. This is always accessible to the user from the main Diagnostics menu. SCANNER TESTS Back Side Scan Uniformity Perform this test after replacing the ADF. Note: Before starting, make sure the scanner glass and backing material are clean.
Page 356: Sensor Test
7463 Sensor Test To test a flatbed or ADF sensor, perform the following steps: Navigate to Scanner tests > Sensor Test. Actuate the sensor you wish to test. The screen will toggle between 0 and 1 if the sensor is properly functioning. Press X to leave the test.
Page 357: Roller Kit Counter Value
7463 Turn on the printer. Release the buttons after 10 seconds. Roller Kit Counter Value When this setting is selected, the printer displays the current value for the Roller Kit counter. A print job containing a single page increments the counter by one and a duplex page by two. When the value has reached the rated life of the Roller Kit, it reminds the customer that scheduled maintenance is required.
Page 358: Print Quality
7463 To change the setting: From the Configuration Menu, navigate to USB Scan to Local. Select On or Off to change the setting. Depending on the printer model, press OK or touch to save the setting, or press X to return to the Configuration Menu without saving any changes.
Page 359: Size Sensing
7463 Size sensing This setting controls whether the printer automatically registers the size of paper installed in an input source with size sourcing. Paper source Size sensing 250‑sheet Tray 500‑sheet Tray 2100‑sheet Tray MP Feeder Duplex When set to Auto, a size-sensing input option automatically reports the size of media that it contains to the device. When Off, the printer ignores the size reported by the size sensing hardware.
Page 360: Safe Mode
7463 Safe Mode The settings for this menu item are On and Off (default). When enabled, Safe Mode lets the printer operate in a special limited mode in which it attempts to continue offering as much functionality as possible despite known issues. For more information about Safe Mode and the Safe Mode print behavior for this model, see “Using Safe Mode”...
Page 361: Min Copy Memory
7463 Min copy memory Values will only be displayed if the amount of installed DRAM is at least twice the amount of the value, that is, at least 200 MB of installed DRAM is required to display the 100 MB selection. To change this setting: Select Min Copy Memory from the Configuration Menu.
Page 362: Adf Edge Erase
7463 ADF edge erase This menu item sets the size, in millimeters, of the no-print area around an ADF scan job. All copy jobs have a minimum of a two millimeter border. Copy jobs will use the setting or two millimeters, whichever is larger. To adjust the ADF edge erase setting, perform the following steps: Select ADF Edge Erase from the Configuration Menu.
Page 363: Envelope Prompts
7463 When it is set to Auto, the emulator selected to print the job determines which of the installed input sources will receive the change prompt. When set to a value other than Auto, the selected source always receives this type of prompt. Envelope Prompts This controls which tray a change prompt is directed to when the envelopes are sensed to be the wrong size.
Page 364: Jobs On Disk
7463 Jobs on Disk This setting appears only if a hard disk is installed. It allows buffered jobs to be deleted from the disk. This does not affect Print and Hold or parked jobs. To change the setting: From the Configuration menu, navigate to Jobs on Disk. Select from the available options to change the setting: •...
Page 365: A4 Fuser
7463 A4 Fuser The A4 fuser cannot fuse the entire right side of any print job that uses media wider than 8.27” (for example: letter or legal). You can use the A4 Fuser setting to determine whether these images are clipped or compressed. Compression is only in the X direction;...
Page 366: Ui Automation
X to return to the Configuration Menu without saving any changes. LES Applications This setting enables or disables all installed Lexmark Embedded Solution applications. To change this setting: From the Configuration Menu, navigate to LES Applications.
Page 367: Key Repeat Rate
7463 Key Repeat Rate Note: This setting is available on the touch screen model only. This setting indicates the number of presses per second for repeating keys. The range is 0.5–100, with increments of 0.5. The default setting is 15 presses per second. To adjust this setting: From the Configuration Menu, navigate to Key Repeat Rate.
Page 368: Automatically Display Error Screens
7463 Automatically Display Error Screens If On, the panel automatically displays any existing printer-related message after the printer remains inactive on the home screen for a length of time equal to the Screen Timeout setting in the Timeouts section of the General Settings Menu.
Page 369: Erase Hard Disk
7463 Erase Hard Disk This setting performs a wipe of the printer hard disk, erasing all data. Warning—Potential Damage: This deletes all data on the printer hard disk, including downloaded fonts, macros, and held jobs. Do not initiate a disk wipe if you have information on the printer that you want to save. Available options: •...
Page 370: Service Engineer Menu
7463 Service Engineer menu Accessing the service engineer (SE) menu From a Web browser on a host PC, add /se to the printer IP address. Service engineer (SE) menu This menu should be used as directed by the next level of support. Top‑level menu Intermediate menu Print SE Menus...

This manual is also suitable for:

Mx81x Xm71xx Xm51xx

Lexmark MX71x Service Manual

Edition Notice

Notices and Safety Information

Preface

General Information

Repair Information

Diagnostic Information

Service Menus

Quick Links

Service Manual

Related Manuals for Lexmark MX71x

Summary of Contents for Lexmark MX71x
